5.7 BEARING REPLACEMENT
1. Turn housing upside down. The bearing can be removed by using a round
slug thru bore, and applying pressure. The seal should be removed at this
time.
FIGURE 20
Bearing Housing
Round slug
Block
Block
Bearing
2. The housing needs to be inspected. If bearing spins in housing, or if there
are other signs of severe damage, such as heavy gouging or cracks, housing
needs to be replaced. Bearing housing bore tolerance is 3.5426in-3.5417in
(89.9820mm-89.9592mm).
| SPONGE-JET 70P 70E USER MANUAL
30
