Features

The OpenCom 100 communications
system is designed to be connected
to an ISDN basic access with the
DSS1 protocol. System access (point-
to-point access) and multi-terminal
access (point-to-multi-point access)
are both supported. The two forms
of access can be configured parallel.
For this purpose
the OpenCom 105 has a total of
four S ports (one external, one
0
internal, and two switchable be-
tween internal/external),
the OpenCom 110 has a total of
five S ports (two external, one
0
internal, and two switchable be-
tween internal/external), and
the OpenCom 120 has a total of
six S ports, all switchable be-
0
tween internal/external.
The firmware of the OpenCom 100
is designed for configuring up to
150 users.
You can connect to the
OpenCom 100:
Euro-ISDN terminals
DeTeWe system telephones
Features
DeTeWe RFP 21base stations
analogue terminals.
The S port requires Euro-ISDN ter-
0
minals in accordance with DSS1. The
U port is suitable for the Open-
pn
Phone range of DeTeWe system tele-
phones and for the DeTeWe RFP 21
base stations. The analogue port op-
erates with analogue standard ter-
minals.
The OpenCom 100 can be integrated
in an existing network (LAN), and
used by all client workstations as an
Internet access router and mail
client.
Configuration and programming of
the OpenCom 100 is performed by
means of a Web browser (Web con-
sole), which can be run on a con-
nected PC. The OpenCom 100 con-
figuration can also be prepared in
the Service Centre and maintained
by means of remote configuration.
A PC can be connected via a COM
port for the purpose of configuring
the system or transferring connec-
tion data.
In order to connect the OpenCom
100 with the existing hardware in
the building, there are two actor
ports (output) and one sensor port
(input).
