TLE92108 APPKIT

6 Bill of material

6 Bill of material
Table 1 Bill of material
Designator
C1, C2
C3, C4, C8
C5, C7
C6
C9, C10, C11, C12, C13, C14, C15, C16
C_DCLINK1, C_DCLINK2
CDM_VS1, CDM_VS2
CMN_VS1, CMN_VS2, CMP_VS1, CMP_VS2
D1
D2
J1, J2, J3, J4, J5
Q1, Q2, Q3, Q4, Q5, Q6, Q7, Q8, Q9, Q10, Q11, Q12, Q13, Q14, Q15, Q16
Q17
Q18
R1, R2, R3, R4, R5, R7, R8, R9, R10, R11
R6
R12
R13, R14
R15
R16
R17
R18
R_SHUNT1, R_SHUNT2
RDIS1, RDIS2
RFN_VS1, RFN_VS2, RFP_VS1, RFP_VS2
U1
X1
X2, X4, X6, X7, X8, X9, X10, X11, X12
X3
X5
User Manual
Value
100 pF
100 nF
220 nF
470 nF
22 nF
560 uF
1.50 nF
22 nF
BZX84C16LT1G
BAS21
20020316-G021B01LF
IPZ40N04S5-3R1
BCR141
IPZ40N04S5L-2R8
1 kR
47 kR
2 R
10 R
2.20 R
100 kR
4.7 kR
47 kR
5 mR
15 kR
4.70 R
TLE92108
Header 3
connector_1_f
Header 8X2
Header 3X2A
