  • Page 1 Getting Started Guide for MOTIX Evaluation Kit - TLE9879 Eval Kit...
  • Page 2 3 Steps to Successful Operation Install Required Run Example Code Run Example Code Toolchain to Blink LEDs to Spin a Motor 2024-03-19 restricted Copyright © Infineon Technologies AG 2024. All rights reserved.
  • Page 3 You will need to install 4 elements of the toolchain. All aspects related to the Toolchain installation apply to both the TLE9879 and TLE9893 Eval Kits. Infineon Developer Keil μVision5 Segger Center J-Link Driver Config Wizard 2024-03-19 restricted Copyright © Infineon Technologies AG 2024. All rights reserved.
  • Page 4 2024-03-19 restricted Copyright © Infineon Technologies AG 2024. All rights reserved.
  • Page 5 Infineon Developer Center 2024-03-19 restricted Copyright © Infineon Technologies AG 2024. All rights reserved.
  • Page 6 2024-03-19 restricted Copyright © Infineon Technologies AG 2024. All rights reserved.
  • Page 7 ‒ Note that they should select the check box that says to Install the USB Legacy drivers Ensure this box is checked https://www.segger.com/downloads/jlink/JLink_Win dows.exe 2024-03-19 restricted Copyright © Infineon Technologies AG 2024. All rights reserved.
  • Page 8 If you are using the TLE9879 EVK, then install the pack “Infineon::TLE987x_DFP” 2024-03-19 restricted Copyright © Infineon Technologies AG 2024. All rights reserved.
  • Page 9 After the Pack File is installed, you will want to ensure that the TLE987x Pack File along with the Generic ARM packs are up to date. If they require an Update, please Update them by clicking on the Update button. 2024-03-19 restricted Copyright © Infineon Technologies AG 2024. All rights reserved.
  • Page 10 TLE9879 Eval Kit Install and Run Example to Blink LED...
  • Page 11 STEP 2: Install and Run Example Code to Blink LED - TLE9879 Eval Kit 2024-03-19 restricted Copyright © Infineon Technologies AG 2024. All rights reserved.
  • Page 12 Install and Run Example Code to Blink LED - TLE9879 Eval Kit 2024-03-19 restricted Copyright © Infineon Technologies AG 2024. All rights reserved.
  • Page 13 Install and Run Example Code to Blink LED - TLE9879 Eval Kit 2024-03-19 restricted Copyright © Infineon Technologies AG 2024. All rights reserved.
  • Page 14 Install and Run Example Code to Blink LED - TLE9879 Eval Kit 2024-03-19 restricted Copyright © Infineon Technologies AG 2024. All rights reserved.
  • Page 15 Install and Run Example Code to Blink LED - TLE9879 Eval Kit NOTE: Version number of Config Wizard may be different than what is shown here. 2024-03-19 restricted Copyright © Infineon Technologies AG 2024. All rights reserved.
  • Page 16 Install and Run Example Code to Blink LED - TLE9879 Eval Kit 2024-03-19 restricted Copyright © Infineon Technologies AG 2024. All rights reserved.
  • Page 17 Install and Run Example Code to Blink LED - TLE9879 Eval Kit 2024-03-19 restricted Copyright © Infineon Technologies AG 2024. All rights reserved.
  • Page 18 Install and Run Example Code to Blink LED - TLE9879 Eval Kit 2024-03-19 restricted Copyright © Infineon Technologies AG 2024. All rights reserved.
  • Page 19 Install and Run Example Code to Blink LED - TLE9879 Eval Kit NOTE: VBAT can be 13VDC 2024-03-19 restricted Copyright © Infineon Technologies AG 2024. All rights reserved.
  • Page 20 Install and Run Example Code to Blink LED - TLE9879 Eval Kit 2024-03-19 restricted Copyright © Infineon Technologies AG 2024. All rights reserved.
  • Page 21 Install and Run Example Code to Blink LED - TLE9879 Eval Kit 2024-03-19 restricted Copyright © Infineon Technologies AG 2024. All rights reserved.
  • Page 22 Install and Run Example Code to Blink LED - TLE9879 Eval Kit 2024-03-19 restricted Copyright © Infineon Technologies AG 2024. All rights reserved.
  • Page 23 TLE9879 Eval Kit Install and Run Example to Spin Motor Using Block Commutation...
  • Page 24 STEP 3: Install and Run Example to Spin a Motor - TLE9879 Eval Kit STEP 1: Copy example code Within μVision, click on the Pack Installer Icon. Click on the Examples tab and find the item that says “BLDC_BEMF (TLE9879 EvalKit)”.
  • Page 25 Install and Run Example to Spin a Motor - TLE9879 Eval Kit STEP 2: Load Example Configuration with Config Wizard Within μVision, click on Tools and then select Config Wizard. This will launch the Config Wizard. Within Config Wizard, select File, then Save.
  • Page 26 Install and Run Example to Spin a Motor - TLE9879 Eval Kit STEP 3: Compile code and connect Eval Kit Within μVision, click on the Build icon (F7). The code will then compile and you should have 0 errors and 0 warnings.
  • Page 27 Install and Run Example to Spin a Motor - TLE9879 Eval Kit STEP 4: Setup and connect the debugger 2024-03-19 restricted Copyright © Infineon Technologies AG 2024. All rights reserved.
  • Page 28 Install and Run Example to Spin a Motor - TLE9879 Eval Kit STEP 5: Load code to the Eval Kit and execute demo Now click on the Load icon within μVision. The code will now be flashed to the Eval Kit and you should see a message that says it finished successfully.
  • Page 29 TLE9879 Eval Kit Install and Run Example to Spin Motor Using Field Oriented Control...
  • Page 30 Demo with TLE987x Request the Demo Code for Version:v1.3.0. You should get approval to download within 24hrs. Download the Demo Code and remember where you stored the file on your harddrive. 2024-03-19 restricted Copyright © Infineon Technologies AG 2024. All rights reserved.
  • Page 31 The other two files within the folder are an Application Note and Getting Started document. Please reference these documents for further details related to the FOC example. 2024-03-19 restricted Copyright © Infineon Technologies AG 2024. All rights reserved.
  • Page 32 Select the TLE9879QXA40 device on the left- hand side Click on the “Examples” on the right-hand side tab At the very bottom, “TLE9879QXA40_eSL- BAS-EVAL” should show up. Click copy and the project should open. 2024-03-19 restricted Copyright © Infineon Technologies AG 2024. All rights reserved.
  • Page 33 Spin Motor with FOC Example STEP 4: Load Example Configuration with Config Wizard Within μVision, click on Tools and then select Config Wizard. This will launch the Config Wizard. 2024-03-19 restricted Copyright © Infineon Technologies AG 2024. All rights reserved.
  • Page 34 Getting Started guide documents that were included in the FOC demo download. 2. After configuring the settings, click on File and then Save. 3. Close the Config Wizard. 2024-03-19 restricted Copyright © Infineon Technologies AG 2024. All rights reserved.
  • Page 35 Eval Kit. Connect the Eval Kit to your PC and power supply. Motor Connect the 3 larger gauge wires from the motor to the EVK (red, yellow and black wires) 2024-03-19 restricted Copyright © Infineon Technologies AG 2024. All rights reserved.
  • Page 36 Spin Motor with FOC Example STEP 7: Setup and connect the debugger 2024-03-19 restricted Copyright © Infineon Technologies AG 2024. All rights reserved.
  • Page 37 The code will now be flashed to the Eval Kit and you should see a message that says it finished successfully. Start a Debug Session Click the Run icon 2024-03-19 restricted Copyright © Infineon Technologies AG 2024. All rights reserved.
  • Page 38 Within the Watch Window, Change Enable Control to 1 and set the Reference Speed to 1000 (or whatever suits your motor). The motor should now be spinning. 2024-03-19 restricted Copyright © Infineon Technologies AG 2024. All rights reserved.
