Abbreviations

Abbreviations
CSN
CSIx
CSOx
DC
EN
GH1-8
GL-8
GND
GUI
MOSFET
N.C.
OC
OV
PWM1-3
SCLK
SDI
SDO
SPI
TJ
UV
VBAT
VCP
VDD
VDH
VS
VSP
User Manual
Chip Select
Current Sense Input x
Current Sense Output
Direct Current or Duty Cycle
TLE92108 enable pin
Gate high side MOSFET for half-bridge 1-8
Gate low side MOSFET for half-bridge 1-8
Ground
Graphic User Interface
Metal-Oxide-Semiconductor Field-Effect Transistor
Not connected
Over current
Over voltage
Pulse Width Modulation channel 1-3
Serial Clock
Serial Data In
Serial Data Out
Serial periphery interface
Junction temperature
Under voltage
Battery supply voltage
Charge pump voltage
Logic supply voltage
Voltage drain of high-side MOSFET
Battery supply voltage
Half-bridge supply volltage
