TLE92108 APPKIT

4 Current Sense Output (CSO) jumper setting

4
Current Sense Output (CSO) jumper setting
The Current Sense Output jumper selects which IC current sense output is connected to the uIO interface. The
signal is routed to the uIO-stick interface pin 16. The pinout is shown in
Figure 8
Current Sense Output selection jumper
Figure 9
CSO selection jumper pinout
User Manual
CSO selection jumper
CSO2
CSOx
CSO1
8
Figure
9.
v1.0
2020-06-30
