3 Connections

3 Connections
Several external connections are available on the TLE92108 APPKIT.
Figure 3 Connections
uIO-stick interface
The uIO-stick interface can be used to establish communication with the TLE92108 for programming of the SFRs
and motor control. Setting up the interface can be found in
Figure 4 Pin configuration of uIO-stick
User Manual
SPI
header
OUT 1
OUT 2
OUT 3
OUT 4
Ground
VBAT
SDI SDO SCLK CSN
15 13 11
16 14 12
CSOx EN PWM3 PWM2 PWM1 N.C.
uIO-stick
interface
APPKIT setup. The pinout is shown in
N.C. N.C. N.C.
9 7 5 3
10 8 6 4
VDD GND
