6.5.2 Diesel motor: Connecting the bat-
teries
6.5.3 Diesel motor: Installing the heat-
ing
6.5.4 Jockey pump
7

Commissioning

Installation and operating instructions Wilo-SiFire FIRST
Commissioning
ƒ
Secure the mains connection only against short-circuit and fault current.
Earth the system!
WARNING! Protection against overload is strictly prohibited!
ƒ
Use single, continuously running cables.
ƒ
Select and lay cables to ensure that the system functions in the event of fire:
–
Use flame-resistant cables. Min. fire resistance: 180 min!
–
Laid underground with a covering of at least 70 cm
–
Laid in non-flammable materials with sufficient covering
–
Laid in rooms with sprinklers
ƒ
Connect the system as specified in the wiring diagrams in the switchgear.
DANGER
Risk of fatal electrical shock from pre-charged batteries!
The installed batteries are pre-charged. There is a risk of fatal injury caused by elec-
tric shock. Do not touch or short circuit both poles.
DANGER
Diesel motor: Risk of personal injury due to inadvertent start!
After the starter batteries have been connected, the system may activate inadvert-
ently. Danger of serious injuries! After the batteries have been connected, check
whether the main switch is switched off. Secure the main switch against being ac-
tivated inadvertently.
‡
Main switch switched off. Secure against being activated inadvertently.
1. Connect battery to the switchgear.
▶ Batteries connected. Once the switchgear has been activated, the batteries begin
charging.
To heat the motor oil and diesel fuel, connect an appropriate heating element as re-
quired.
CAUTION
Systems with jockey pump: Jockey pump starts immediately!
When the mains plug is inserted into the socket, the jockey pump starts. The jockey
pump fills the system with water and establishes the holding pressure.
Before plugging in the mains plug, read the notes on commissioning!
ƒ
The jockey pump comes pre-assembled and pre-wired.
ƒ
Provide a shock-proof socket on-site for the mains connection. Fuse protection:
16 A.
For correct operation and safety, the pump unit in question requires the installation of
other mandatory system components for compliance with the applicable directives and
standards.
Therefore, according to the Machinery Directive 2006/42/EC Annex II-1B, the commis-
sioning of the pump unit is PROHIBITED before the entire system in which it has been
installed has been completed and declared to be in conformity with the applicable dir-
ectives and standards.
For initial commissioning, we recommend that you contact your local Wilo service agent
or our service call centre. The commissioning of the pressure-boosting system must be
carried out by qualified personnel.
