M09 – Motor temperature 1
Source measure.
Specifies from which source the fuel level meas-
urement is taken. OFF= not managed. RES1 =
taken from the resistive sensor with analogue in-
P09.01
put on terminal RES1. AINx = taken from the ana-
logue input of an EXP expansion module. RES
AN= taken from the resistive input of an EXP ex-
pansion module.
Channel number.
P09.02
Channel number (x) to be specified if AINx has
been selected in the previous parameter.
Resistive sensor type.
If a resistive sensor is used, select which curve to
P09.03
use. Characteristic curves can be set freely using
the Xpress software.
Resistive sensor offset.
If a resistive sensor is used, it allows to add or re-
move an offset in Ohm to the set the curve to
compensate, for example, the cable length. This
P09.04
value can also be set without entering setup us-
ing the quick function in the command menu
which allows you to see the measurements while
performing calibration.
MAX Pre-alarm temperature
P09.05
MAX Alarm limit temperature
P09.06
MIN Alarm limit temperature
P09.07
Heater activation threshold
P09.08
Heater deactivation threshold
P09.09
Faulty temperature sensor alarm delay
P09.10
M10 – Motor temperature 2
Source measure.
Specifies from which source the fuel level meas-
urement is taken. OFF= not managed. RES2 =
taken from the resistive sensor with analogue in-
P10.01
put on terminal RES2. AINx = taken from the ana-
logue input of an EXP expansion module. RES
AN= taken from the resistive input of an EXP ex-
pansion module.
Channel number.
P10.02
Channel number (x) to be specified if AINx has
been selected in the previous parameter.
Resistive sensor type.
If a resistive sensor is used, select which curve to
P10.03
use. Characteristic curves can be set freely using
the Xpress software.
Resistive sensor offset.
If a resistive sensor is used, it allows to add or re-
move an offset in Ohm to the set the curve to
compensate, for example, the cable length. This
P10.04
value can also be set without entering setup us-
ing the quick function in the command menu
which allows you to see the measurements while
performing calibration.
MAX Pre-alarm temperature
P10.05
MAX Alarm limit temperature
P10.06
Installation and operating instructions Wilo-SiFire FIRST
Switchgear of diesel pump
Unit
Ohm
°
°
°
°
°
Min.
Unit
Ohm
°
°
Standard
Area
OFF
OFF
RES3
AINx
RES AN
1
1 ... 4
VDO
VDO / DATCON / VEGLIA /
MURPHY
0
-30.0 ... +30.0
90
20-300
100
20-300
OFF
OFF/ 20-300
OFF
OFF/ 20-300
OFF
OFF/ 20-300
OFF
OFF/1–60
Standard
Area
OFF
OFF
RES3
AINx
RES AN
1
1 ... 4
VDO
VDO / DATCON / VEGLIA /
MURPHY
0
-30.0 ... +30.0
90
20-300
100
20-300
