10.1.3 Procedure for commissioning
Fig. 12.3
10.1.4 Main menu
Fig. 12.4
Installation and operating instructions Wilo-SiFire FIRST
Switchgear of diesel pump
ƒ
The alarm can only be reset if the start is successful.
ƒ
From this page, by pressing the key
on the front panel.
ƒ
From this page, pressing the key
of signal from the pressure switch. The duration and pause of the starting attempts
are those foreseen by the standard in the commissioning test on site.
ƒ
Each time the tests are performed, the date of execution is saved and shown on the
display.
ƒ
Detection of the motor speed: The setting is protected by the extended password
when activated. Start the motor. When the motor reaches the RPM with a constant
speed, press and
acquisition procedure. During the procedure it is still possible to increase and de-
crease the motor RPM value. By pressing
creases.
NOTICE
This procedure is also useful for checking the state of the batteries: In the event that
a correct value voltage is measured at the ends of a battery due to the voltage gen-
erated by the battery charger, it may happen that this value drops sharply during
start-up.
Description
Password entry - Setting the numerical code that allows access to protected
1
functions (setting parameters, execution of commands)
Main page access
2
Battery status
3
Commissioning
4
Fuel tank status
5
Counters
6
Events list
7
Input/output status
8
Alert status
9
System information
10
Settings – Access point for parameter programming
11
Command menu – Access point to the command menu where authorised
12
users can perform a series of reset and restore actions
ƒ
The main menu consists of a set of graphic icons that allow quick access to meas-
urements and settings.
ƒ
Starting from the page display, press the button
quick menu.
ƒ
Press or to rotate clockwise/counterclockwise until the desired
function is selected. The selected icon is highlighted and the text in the central part
of the display indicates the description of the function.
, it is possible to test the signalling LEDs
, will start the motor by simulating the lack
simultaneously to start the automatic motor RPM
it decreases and with
. The display shows the
