Installation and operating instructions Wilo-SiFire FIRST
Electric pump switchgear
Code MENU
PROTECTIONS
M05
AUDIBLE ALARMS
M06
AUTOMATIC TEST
M07
MAINTENANCE
M08
DIGITAL INPUTS
M09
DIGITAL OUTPUTS
M10
COMMUNICATION
M11
LIMITED THRESHOLDS
M12
CONTACTORS
M13
REMOTE ALARMS
M14
TIMER
M15
ANALOGUE INPUTS
M16
USER ALARMS
M18
ALARM TABLE
M19
Select the sub-menu and press the key
ers are displayed with code, description, current value.
ƒ
If you want to change the value of a parameter, after selecting it press
If you have not entered the Advanced level password, you will not be able to access the
edit page and you will see a denied login message. If you are logged in, the edit page
will be displayed. When in edit mode, the value can be changed with the
keys. A bar graph will also be displayed indicating the setting range, the min-
imum possible values, the previous value and the default value.
ƒ
Pressing +
+ sets the maximum possible. Pressing
eously returns the setting to the default value.
When entering text, use the
acter and use and
+ simultaneously positions the alphanumeric selection directly on the "A" char-
acter.
ƒ
Press to return to parameter selection. The value entered remains stored.
Press STOP to save the changes and exit the settings. The switchgear performs a reset
and returns to normal operation. If no keys are pressed for 2 consecutive minutes, the
setup menu is automatically exited and the system returns to normal operation without
saving parameters.
You can make a back-up copy to the EEPROM memory, for keyboard editable set-up
data only. These can be restored to the working memory. Backup and restore data com-
mands are available in the command menu.
DESCRIPTION
Protection alarm thresholds
Internal buzzer and external siren control
Period, duration, automatic test mode
Maintenance intervals
Programmable digital input functions
Programmable digital output functions
Address, format, protocol
Programmable limit thresholds on measures
Generic programmable counters
Alarm/Status indication on external relays
Programmable timers for PLC logic
Voltage/current/temperature inputs
Programmable alarms
Enabling and effect of alarms
to display the parameters. All paramet-
sets the value to the minimum possible and pressing
and keys to select the alphanumeric char-
to move the cursor within the text. Pressing
en
.
and
+ simultan-
