en
Maintenance request 3
A60
Partially open suction valve
A69
Delivery valve partially open
A70
Local sprinkler pumps
A71
Jockey pump starts alarm
A72
Thermal alarm jockey pump
A73
Drainage pump alarm
A74
Fuel liquid leakage
A75
Communication error
A76
Jockey pump timeout
A77
Open test valve
A78
User alarm 1
UA1
...
...
User alarm 8
UA8
10.4.1 Description of alarms
CODE DESCRIPTION
Motor temperature pre-alarm 1 (analogue sensor)
A01
High temperature motor 1 (analogue sensor)
A02
Temperature sensor fault 1 (analogue sensor)
A03
Low motor temperature 1 (analogue sensor)
A04
Pre-alarm motor temperature 2 (analogue sensor)
A05
High temperature motor 2 (analogue sensor)
A06
Analogue temperature sensor fault 2
A07
Low temperature motor 2 (analogue sensor)
A08
High motor temperature (digital sensor)
A09
Motor temperature too low (digital). Heater failure. (Motor tem-
A10
perature too low (digital), heater failure.)
Oil pressure pre-alarm (analogue sensor)
A11
Low oil pressure (analogue sensor)
A12
Analogue pressure sensor failure
A13
Low oil pressure (digital sensor)
A14
64
Switchgear of diesel pump
• • •
• • •
• • •
• • • •
• • •
• • •
• • •
• • •
• •
• • •
• • •
•
•
•
• •
• • •
• • •
• •
• • •
• • •
• • •
• • •
• • •
• • •
CAUSE
Motor temperature above the pre-alarm threshold set
with P09.05.
Motor temperature above the alarm threshold set with
P09.06.
The resistive temperature sensor is an open circuit (dis-
connected).
Motor temperature below the alarm threshold set by
P09.07.
Motor temperature above the pre-alarm threshold set by
P10.05.
Motor temperature above the alarm threshold set by
P10.06.
The resistive temperature sensor is an open circuit (dis-
connected).
Motor temperature below the alarm threshold set by
P10.07.
Motor excess temperature signalled by activation of the
digital input programmed with the appropriate function -
High motor temperature.
Alarm generated by the input programmed with the
function - Motor temperature too low.
Motor oil pressure lower than the pre-alarm threshold set
with P08.06.
Motor oil pressure lower than the alarm threshold set
with P08.07.
The resistive pressure sensor is an open circuit (discon-
nected).
Low oil pressure signalled by activation of the digital in-
put programmed with the appropriate function.
•
•
•
•
•
•
•
•
•
•
