Function
Local ventilation
Topping up pump
Solenoid valve cooling
Boost charger
PLC flag(x)
Remote variable REM(x)
LIM limits (x)
TIMx
Partially open suction valve
Delivery valve partially open
Local pump sprinkler alarm
Drainage pump alarm
Low temperature alarm
Pump room
Pilot pump alarm (Jockey)
AUTOMATIC TEST start
Alarms A01-Axx
10.6

Command menu

CODE COMMAND
Reset maintenance interval 1
C01
Reset maintenance interval 2
C02
Reset maintenance interval 3
C03
Partial motor hour meter reset
C04
Reset generic CNTx counters
C05
Reset LIMx limits status
C06
Total motor hour counter reset
C07
Motor hour meter setting
C08
Start-up counter reset
C09
Reset event list
C10
Reset parameters to default
C11
Save parameters to backup
C12
memory
Installation and operating instructions Wilo-SiFire FIRST
Switchgear of diesel pump
Description
Output activated with motor running and for a set time at the end of operation.
Check the fuel topping up pump. See parameters P11.10 and P11.11.
Energised with motor stopped, de-energised with motor running.
Output activated after an interval defined in parameter P05.05 for a duration defined in para-
meter P05.06.
Output controlled by PLCx flag.
Output controlled by remote variable REMx.
Output controlled by LIM(x) limit threshold status.
Output controlled by TIMx timer variable.
Output active if the inlet function is programmed Partially open inlet valve and this inlet is act-
ive.
Output active if the inlet function is programmed Partially open inlet valve and this inlet is act-
ive.
Output active if the input function is programmed Pump local sprinkler alarm and this input is
active.
Output active if the drainage pump alarm input function is programmed and this input is active.
Output energised when Alarm A46 Ambient temperature too low is active.
Output active if the Pilot Pump Alarm input function is programmed and this input is active.
This output is activated during the first 20 seconds of the automatic test, see parameter P13.01
Output energised when alarm Axx is active (xx = 1 ... number of alarms)
Output energised when user alarm UAx is active.
The command menu allows you to perform occasional operations such as zeroing of
measurements, counters, alarms, etc. If you have entered the password for advanced
access, then you can also use the command menu to perform automatic operations
useful for configuring the instrument. The following table shows the functions available
with the command menu, divided according to the level of access required.
ACCESS DESCRIPTION
User Resets the MNT1 maintenance alarm and recharges the maintenance
counter at the set hours. Maintenance can only be reset if all of the fol-
lowing conditions have occurred in the previous 4 hours:
all attempts to start with both batteries have been made;
the motor must be started;
opening of the pressure switch;
no active alarm excluding the maintenance alarm.
User As above, referring to MNT2.
User As above, referring to MNT3.
User Resets the partial hour meter of the motor.
User Resets the generic CNTx counters
User Resets the status of the retention LIMx limits.
Advanced Resets the total hour counter of the motor.
Advanced Allows you to set the total motor hour counter to a desired value.
Advanced Resets the start attempt counter and the percentage of successful at-
tempts
Advanced Resets the event history list to zero.
Advanced Resets all set-up menu parameters to factory setting
Advanced Copies the currently set parameters to a backup area for future restora-
tion.
