en
9.1.5 Access via password
Fig. 11.5
36
Electric pump switchgear
Password entry - Setting the numerical code that allows access to protected
1
functions (setting parameters, execution of commands)
Main page access
2
Electrical measurements
3
Motor power
4
Commissioning
5
Counters
6
Events list
7
Input/output status
8
Alert status
9
System information
10
Settings – Access point for parameter programming
11
Command menu – Access point to the command menu where authorised
12
users can perform a series of reset and restore actions
ƒ
The main menu consists of a set of graphic icons that allow quick access to meas-
urements and settings.
ƒ
Starting from the page display, press the button
quick menu.
ƒ
Press or to rotate clockwise/counterclockwise until the desired
function is selected. The selected icon is highlighted and the text in the central part
of the display indicates the description of the function.
ƒ
Press to activate the selected function.
ƒ
If some functions are not available, the corresponding icon will be disabled, i.e. dis-
played in light grey.
ƒ
The password is used to enable or block access to the setup menu and the command
menu.
ƒ
If the passwords have been enabled, you must first enter the relevant numerical ac-
cess code to gain access.
ƒ
To enable the use of passwords and define the access codes, refer to the relevant
setting menu.
ƒ
There are two levels of access, depending on the code entered:
–
User level access - allows you to reset the registered values and modify some
settings of the device.
–
Advanced level access - same rights as the user with the possibility to modify all
settings.
ƒ
From the main screen, press to call up the main menu, then select the password icon
and press it.
ƒ
The password setting window will appear in the figure:
ƒ
Use the and
ƒ
Use the and
ƒ
Enter all the digits of the password, then move to the key icon.
ƒ
When the password entered corresponds to the User Level Password or Advanced
Level Password, the corresponding unlock message appears.
ƒ
Once the password is unlocked, access will remain enabled until you unlock it:
–
the device is switched off.
–
the device is reset (after exiting the settings menu).
–
more than 2 minutes elapse without the operator touching any keys.
ƒ
Press the key to leave the password setting and exit.
. The display shows the
keys to change the value of the selected digit.
keys to move between digits.
