en
M10 – Motor temperature 2
MIN Alarm limit temperature
P10.07
Heater activation threshold
P10.08
Heater deactivation threshold
P10.09
Faulty temperature sensor alarm delay
P10.10
M11 – Fuel level
Source measure.
Specifies from which source the fuel level meas-
urement is taken. OFF= not managed. RES3 =
taken from the resistive sensor with analogue in-
P11.01
put on terminal RES3. AINx = taken from the ana-
logue input of an EXP expansion module. RES
AN= taken from the resistive input of an EXP ex-
pansion module.
Channel number.
P11.02
Channel number (x) to be specified if AINx has
been selected in the previous parameter.
Resistive sensor type.
If a resistive sensor is used, select which curve to
P11.03
use. Characteristic curves can be set freely using
the Xpress software.
Resistive sensor offset.
If a resistive sensor is used, it allows to add or re-
move an offset in Ohm to the set the curve to
compensate, for example, the cable length. This
P11.04
value can also be set without entering setup us-
ing the quick function in the command menu
which allows you to see the measurements while
performing calibration.
Capacity unit of measurement
P11.05
Tank capacity
P11.06
Rated hourly motor consumption
P11.07
MIN Pre-alarm fuel
P11.08
MIN Fuel level
P11.09
Start level fuel topping up pump
P11.10
Fuel filler pump stop level
P11.11
MAX Pre-alarm fuel
P11.12
MAX fuel level alarm
P11.13
M12 – Motor start
Battery charger alternator voltage threshold
With the motor running and the voltage below
the set threshold, the A42 battery charger altern-
P12.01
ator failure alarm is generated. In the event of ab-
sence of the signal W there is the recognition
threshold of the motor in motion by the battery
charger alternator voltage (D+/AC).
Threshold started by motor speed.
P12.02
Threshold recognition of motor running by speed
signal 'W' or pick-up
Glow plugs preheating time
P12.03
Number of start-up attempts
P12.04
Start attempt duration
P12.05
Pause between start-up attempts
P12.06
60
Switchgear of diesel pump
Unit
°
°
°
Min.
Unit
Ohm
(P11.05)/h
%
%
%
%
%
%
Unit
VDC
%
S
S
S
S
Standard Area
OFF OFF/ 20-300
OFF OFF/ 20-300
OFF OFF/ 20-300
OFF OFF/1–60
Standard Area
OFF OFF
RES3
AINx
RES AN
1 1 ... 4
VDO VDO / DATCON / VEGLIA /
MURPHY
0 -30.0 ... +30.0
% % / l /gal
OFF OFF / 1-30000
OFF OFF / 0.0-200.0
OFF OFF / 1-100
66 OFF / 1-100
OFF OFF / 1-100
OFF OFF / 1-100
90 OFF / 1-100
95 OFF / 1-100
Standard Area
10.0 OFF/3.0-30
30 OFF/10-100
OFF OFF/1-60
6 1-30
8 1-60
8 1-60
