Delivery valve partially open
A31
Local sprinkler pumps in operation
A32
Maximum number of pilot pump
A33
starts
Pilot pump failure
A34
Maximum pilot pump time
A35
Drainage pump failure
A36
Communication error
A37
Pressure switch test error
A38
Test valve open
A39
Power too low
A40
Power too high
A41
User Alarm 1
UA1
...
...
User Alarm 8
UA8
9.4.1 Description of alarms
CODE DESCRIPTION
Low mains voltage
A01
High voltage grid
A02
Low network frequency
A03
High frequency network
A04
Mains voltage asymmetry
A05
Phase failure
A06
Incorrect phase sequence
A07
Failure to start the pump
A08
Locked rotor
A09
Dry running
A10
Current too low
A11
Current too high
A12
Unbalanced currents
A13
Unexpected current
A14
Wrong CT connection
A15
System error xx
A16
Low pump room temperature
A17
High local pump temperature
A18
Water reserve
A19
Low tank level
A20
Empty tank
A21
Installation and operating instructions Wilo-SiFire FIRST
Electric pump switchgear
• • •
• • • •
• • •
• • •
• • •
• • •
• •
• •
• • •
• • •
• • •
•
•
CAUSE
Mains voltage below the threshold set in P05.01.
Grid voltage above the threshold set in P05.02.
Grid frequency below the threshold set in P05.03.
Grid frequency above the threshold set in P05.04.
Grid voltage asymmetry higher than the threshold set in P05.05.
Lack of one of the phases.
Incorrect phase sequence.
The motor has not started with a current greater than 10% of the rated current in the times
defined in the M05 menu or the input programmed with the pump pressure switch function
has not closed.
Motor current higher than 500% of the rated for a time longer than 5s.
Pump runs with vacuum. Measured power factor lower than the threshold set in P05.13
The motor current is below the threshold set in P05.06.
The motor current is higher than the threshold set in P05.07.
The maximum current asymmetry threshold set in P05.14 has been exceeded.
The printed circuit board detects a current greater than 5 % of the I
influence on the motor start
One or more current transformers are not connected correctly (negative active power is
measured). Check the connections at terminals 57, 58, 59, 60
Internal error. Contact Technical Support
The pump room temperature is below the threshold set in P04.02 for longer than P04.03.
The pump room temperature is above the threshold set in P04.04 for longer than P04.05.
Alarm generated by the input programmed with the Water Reserve function.
Water level in the tank below the threshold set in P02.18.
Water level in the tank below the threshold set in P02.19.
• • •
• •
• • •
• • •
• • •
• • •
• • •
• • •
• • •
• • •
• • •
