en
10.1.5 Access via password
Fig. 11.5
10.1.6 Scrolling display pages
52
Switchgear of diesel pump
ƒ
Press to activate the selected function.
ƒ
If some functions are not available, the corresponding icon will be disabled, i.e. dis-
played in light grey.
ƒ
The password is used to enable or block access to the setup menu and the command
menu.
ƒ
If the passwords have been enabled, you must first enter the relevant numerical ac-
cess code to gain access.
ƒ
To enable the use of passwords and define the access codes, refer to the relevant
setting menu.
ƒ
There are two levels of access, depending on the code entered:
–
User level access - allows you to reset the registered values and modify some
settings of the device.
–
Advanced level access - same rights as the user with the possibility to modify all
settings.
ƒ
From the main screen, press to call up the main menu, then select the password icon
and press it.
ƒ
The password setting window will appear in the figure:
ƒ
Use the and
ƒ
Use the and
ƒ
Enter all the digits of the password, then move to the key icon.
ƒ
When the password entered corresponds to the User Level Password or Advanced
Level Password, the corresponding unlock message appears.
ƒ
Once the password is unlocked, access will remain enabled until you unlock it:
–
the device is switched off.
–
the device is reset (after exiting the settings menu).
–
more than 2 minutes elapse without the operator touching any keys.
ƒ
Press the key to leave the password setting and exit.
ƒ
The and keys scroll through the measurement display pages one at a
time. The current page is recognisable by the title bar.
ƒ
Some of the measurements may not be displayed depending on the programming
and connection of the unit (e.g. if a fuel level sensor is not set, the relevant page is
not displayed).
ƒ
For some pages there are sub-pages accessible via the button
ƒ
The user has the possibility to specify on which page and on which sub-page the
display must return automatically after a time has elapsed without pressing any
keys.
ƒ
It is also possible to program the system so that the display always remains in the
position where it was left.
ƒ
For the setting of these functions, see the relevant menu.
Overview of display pages
Page
Main page
keys to change the value of the selected digit.
keys to move between digits.
Example
.
