Led Diagnostics; Terminal Identification; Maintenance - Altronix EFLOW eFlow104NK8 Installation Manual

eFlow104NB Power Supply/Charger
Red (DC)
ON
ON
OFF
OFF
PDS8(CB):
LED
Green
Green and Red
eFlow104NB Power Supply/Charger
Terminal Legend
L, N
– DC +
Trigger EOL
Supervised
NO, GND RESET
+ AUX –
AC Fail
NC, C, NO
Bat Fail
NC, C, NO
– BAT +
PDS8(CB):
Terminal Legend
+ INP1 –
+ INP2 –
P [OUT1-OUT8]
N [OUT1-OUT8]
Use 18 AWG or larger for all low voltage power connections.
Note: Take care to keep power-limited circuits separate from non power-limited wiring (120VAC, Battery).
Unit should be tested at least once a year for the proper operation as follows:
Output Voltage Test: Under normal load conditions, the DC output voltage should be checked for proper
voltage level eFlow104NB: 24VDC nominal rated @ 10A max.
Battery Test: Under normal load conditions check that the battery is fully charged, check specified voltage
(24VDC @ 26.4) both at battery terminal and at the board terminals marked [– BAT +] to ensure that there is no
break in the battery connection wires.
Note: Maximum charging current under discharges is 1.54A.
Note: Expected battery life is 5 years, however it is recommended changing batteries in 4 years or less if needed.
- 6 -

LED Diagnostics:

Green (AC/AC1)
ON
OFF
ON
OFF
ON
12VDC Output.
24VDC Output.

Terminal Identification:

Function/Description
Connect 120VAC 60Hz to these terminals: L to hot, N to neutral (non power-limited)
(Fig. 2a, pg. 5).
24VDC nominal @ 10A continuous output (power-limited output) (Fig. 2h, pg. 5).
Fire Alarm Interface trigger input from a short or FACP. Trigger inputs can be normally
open, normally closed from an FACP output circuit (power-limited input) (Fig. 2d, pg. 5).
FACP interface latching or non-latching (power-limited) (Fig. 2e, pg. 5).
Auxiliary Class 2 power-limited output rated @ 1A (unswitched) (Fig. 2f, pg. 5).
Indicates loss of AC power, e.g. connect to audible device or alarm panel.
Relay normally energized when AC power is present.
Contact rating 1A @ 30VDC (power-limited) (Fig. 2b, pg. 5).
Indicates low battery condition, e.g. connect to alarm panel. Relay normally energized
when DC power is present. Contact rating 1A @ 30VDC.
A removed battery is reported within 5 minutes.
Battery reconnection is reported within 1 minute (power-limited) (Fig. 2b, pg. 5).
Stand-by battery connections. Maximum charge current 1.54A (non power-limited)
(Fig. 2g, pg. 5).
Function/Description
Factory connected to eFlow104NB. Do not use these terminals.
Factory connected to eFlow104NB. Do not use these terminals.
Positive DC power outputs.
Negative DC power outputs.
Power Supply Status
Normal operating condition.
Loss of AC. Stand-by battery is supplying power.
No DC output.
Loss of AC. Discharged or no stand-by battery. No DC output.
Wiring:

Maintenance:

eFlow104NK8(D)
