14.6.14 Language

 Width: 1
 Range: 0–3
 Format: A single numeric character representing a language as follows:
 0—English
 1—French
 2—Spanish
 3—German

15. Response Messages

Response messages are sent from the pump to the PC in response to request messages.

15.1 Status response

A status response message is the default response of the pump to most commands,
indicating a success or failure of the command.
Response Message: Status
Status
Fields
Char Width 1
 Status: A single ASCII character indicating the execution status of the requested command.
 * (0x2a)—The command was executed successfully.
# (0x23)—The command was not executed successfully.

 – (0x2d)—A negative response used for some commands, with different meanings
for each. See individual direct-addressed command definitions for context.
 + (0x2b)—A positive response used for some commands, with different meanings
for each. See individual direct-addressed command definitions for context.

15.2 Data response

A data response is sent when parameter values must be provided in response to a request
message. Each data response is composed of one or more data parameter values which are
delimited by spaces.
Response Message: Data
Data
Parameter
Fields
1
Char. Width Variable
 Data Parameter N—A data value returned by the pump. The format of each data
parameter is defined by the request message that a data response message is sent in
response to. See each request message definition for the definition associated data
response messages.
REGLO ICC - ENGLISH , REV. D, 14-036-E
Data
[SP] Parameter
2
1 (optional) Variable (optional)
Data
[SP] Parameter
1 (optional) Variable (optional)
[CR]
n
1
[LF]
