Ref. # Command
3.0
3.15 v
3.16 v
3.17 xT
3.18 xT
3.19 xP
3.20 xP
3.21 "
3.22 "
3.23 ?
3.24 !
3.25 xv
3.26 xw
4.0
4.1 +
4.2 +
4.3 %
4.4 %
4.5 0
5.0
5.1 xR
5.2 xR
5.3 xU
5.4 xU
5.5 xV
5.6 xW
5.7 xW
5.8 xX
5.9 xY
5.10 xZ
6.0
6.1 (
6.2 xt
6.3 xs
6.4 xu
6.5 xN
6.6 xS
6.7 xS
6.8 xL
6.9 xL
6.10 xA
6.11 xA
6.12 xB
REGLO ICC - ENGLISH , REV. D, 14-036-E
Function
OPERATIONAL MODES AND SETTINGS
Get the current setting for volume in mL.
Set the current setting for volume in mL. Volume Type 2.
Get the current pump run time.
Set current pump run time using Time Type 2.
Get pumping pause time.
Set pumping pause time using Time Type 2.
Get pump cycle count.
Set pump cycle count Discrete Type 2.
Max flow rate achievable with current settings mL/min.
Max flow rate achievable with current settings using calibration.
Get time to dispense at a given volume at a given mL/min flow rate.
Vol, Volume Type 2; flow rate, Volume Type 2.
Get time to dispense at a given volume at a given RPM. mL,
Volume Type 2; flow rate, Discrete Type 3.
CONFIGURATION
Get the current tubing inside diameter in mm. 2 decimal places
are returned.
Set tubing inside diameter using Discrete Type 2.
Get the current backsteps setting.
Set the current backsteps setting using Discrete Type 2.
Resets all user configurable data to default values.
CALIBRATION
Get direction flow for calibration.
Set direction flow for calibration J or K using DIRECTION format.
Get the target volume to pump for calibrating, mL.
Set the target volume to pump for calibrating using Volume Type 2.
Set actual volume measured during calibration, mL Volume Type 2.
Get the current calibration time.
Set the current calibration time using Time Type 2.
Get the channel run time since last calibration.
Start calibration on a channel(s).
Cancel calibration.
SYSTEM
Returns the pump firmware version.
Change factory roller step volume for a particular roller count and
tubing size using roller count (6,8,12), Discrete Type 1; index of the
tubing diameter (see Table 1), Discrete Type 1; RSV. Volume Type 2.
Save set roller step settings.
Reset roller step volume table to defaults.
Set pump name for display under remote control–String.
Get pump serial number.
Set pump serial number–String.
Get the current pump language.
Set current pump language–Language.
Get number of pump channels.
Configure number of pump channels. Discrete Type 2.
Get number of rollers for channel.
Op Response
Get Volume Type 1
Set Volume Type 1
Get Time Type 1
Set *
Get Time Type 1
Set *
Get Discrete Type 1
Set *
Get Text
Get Text
Get Time Type 1 (0.1 sec)
Get Time Type 1 (0.1 sec)
Get 4 characters including decimal (mm).
Set *
Get Discrete Type 1
Set *
Set *
Get DIRECTION, J = CW K = CCW
Set *
Get Volume Type 1
Set Volume Type 1
Set Volume Type 1
Get Time Type 1
Set *
Get Time Type 2
Set *
Set *
Get Discrete Type 2
Set *
Set *
Set *
Set *
Get String
Set *
Get Language
Set *
Get Discrete Type 1
Set *
Get Discrete Type 1
