Avalue Technology ECM-CX700 User Manual

3.5" via eden v4 1 ghz/500mhz micro module with vga, 2-ch lvds, dvi, tv-out, 5.1 ch audio, dual lan, cf, pci-104, 2 sata, 2 com, 4 usb 2.0 & 8-bit gpio
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ECM-CX700
3.5" VIA Eden V4 1 GHz/500MHz Micro Module with VGA,
2-CH LVDS, DVI, TV-out, 5.1 CH Audio, Dual LAN, CF,
PCI-104, 2 SATA, 2 COM, 4 USB 2.0 & 8-bit GPIO
User's Manual
rd
3
Ed – 22 February 2008
Part No. E2047371402R

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ECM-CX700 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Avalue Technology ECM-CX700

Summary of Contents for Avalue Technology ECM-CX700

  • Page 1 ECM-CX700 3.5" VIA Eden V4 1 GHz/500MHz Micro Module with VGA, 2-CH LVDS, DVI, TV-out, 5.1 CH Audio, Dual LAN, CF, PCI-104, 2 SATA, 2 COM, 4 USB 2.0 & 8-bit GPIO User’s Manual Ed – 22 February 2008 Part No. E2047371402R...
  • Page 2 For detailed information, please always refer to the electronic user's manual. Copyright Notice Copyright © 2007 Avalue Technology Inc., ALL RIGHTS RESERVED. No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of the original manufacturer.
  • Page 3 User’s Manual Disclaimer Avalue Technology Inc. reserves the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance. Avalue Technology assumes no responsibility or liability for the...
  • Page 4 Suite A, South 5F, No. 829, 200 Tornillo Way, Suite 210, Yisan Road, Caohejing Hi-tech Park, Tinton Falls, NJ 07712, USA Shanghai 200233, China Tel: +1-732-578-0200 Tel : +86-21-5426-3399 Fax: +1-732-578-0250 Fax : +86-21-6495-0370 http://www.avalue-usa.com http://www.avalue.com.tw E-mail: service.usa@avalue-usa.com E-mail: service.china@avalue.com.tw 4 ECM-CX700 Series User’s Manual...
  • Page 5 A product returned without proof of the purchase date is not eligible for warranty service. 5. Write the RMA number visibly on the outside of the package and ship it prepaid to your dealer. ECM-CX700 Series User’s Manual 5...

  • Page 6: Table Of Contents

    Primary IDE Connector (JIDE1)....................39 2.4.13 LCD Inverter Connector (JINV1)....................41 2.4.14 IrDA Connector (JIR1) ....................... 42 2.4.15 PS/2 Keyboard & Mouse Connector (JKB1)................43 2.4.16 RJ-45 Ethernet (JLAN1, JLAN2)....................43 2.4.17 LVDS Connector (JLVDS1) ....................... 44 6 ECM-CX700 Series User’s Manual...
  • Page 7 Install Touch Panel Driver (For PenMount DMC6000) ..........88 Mechanical Drawing ....................90 Appendix A: BIOS Revisions ..................92 Appendix B: AWARD BIOS POST Messages ..............93 Overview..........................94 Post Beep ..........................94 Error Messages .........................94 CMOS BATTERY HAS FAILED ......................94 ECM-CX700 Series User’s Manual 7...
  • Page 8 Keyboard is locked out - Unlock the key..................98 Keyboard error or no keyboard present..................98 Manufacturing POST loop......................98 BIOS ROM checksum error - System halted................. 98 Memory test fail..........................98 POST Codes ..........................99 8 ECM-CX700 Series User’s Manual...

  • Page 9: Getting Started

    Before you begin installing your single board, please make sure that the following materials have been shipped: 1 x ECM-CX700 VIA Eden V4 Micro module 1 x Quick Installation Guide for ECM-CX700 1 x DVD-ROM or CD-ROM contains the followings: —...

  • Page 10: Document Amendment History

    5. JTV1’s pin definition modified 6. Audio driver installation modified Feb. 2008 Lingo Tsai 1. P.13, 14 specification modified (weight, size,..) 2. Address/Phone/Email modified for China/USA branch 2. P.25 product overview modified(JFAN2) 3. Mechanical drawing modified on P.91 10 ECM-CX700 Series User’s Manual...

  • Page 11: Manual Objectives

    We strongly recommend that you study this manual carefully before attempting to interface with ECM-CX700 series or change the standard configurations. Whilst all the necessary information is available in this manual we would recommend that unless you are confident, you contact your supplier for guidance.

  • Page 12: System Specifications

    Resolution LCD/Simultaneous mode: 1600 x 1200 @ 24 bpp (60 Hz) LVDS Dual-channel 18/24-bit LVDS VIA CX700M DVI interface VIA CX700M HDTV encoder supports both NTSC/PAL TV-out Supports both S-video, composite video, and component YPb(Cb)Pr(Cr) 12 ECM-CX700 Series User’s Manual...
  • Page 13 SDRAM) Power Type AT/ATX Operation Temperature 0~60® C (32~140® F) Operating Humidity 0%~90% relative humidity, non-condensing Size ( L x W ) 5.7" x 4" (146 mm x 101 mm) Weight 0.44 lbs (0.23 kg) ECM-CX700 Series User’s Manual 13...

  • Page 14: Architecture Overview

    ECM-CX700 1.6 Architecture Overview 1.6.1 Block Diagram The following block diagram shows the architecture and main components of ECM-CX700 Series. The following sections provide detail information about the functions provided onboard. 14 ECM-CX700 Series User’s Manual...

  • Page 15: Via Cx700M

    These include integrated MPEG-2 decoding, for flawless digital video playback with ultra-low CPU-utilization, and advanced rendering tools such as Adaptive De-Interlacing and Video Deblocking, which ensure clearer playback of digital content on all display devices. ECM-CX700 Series User’s Manual 15...
  • Page 16 533MB/sec Front Side Bus • Supports up to 4GB DDR2 533/400MHz or DDR400/333/266MHz SDRAM • Integrated VIA UniChrome Pro Graphics Integrated VIA UniChrome Pro Graphics • Built in HDTV Encoder • Chromotion™ video engine • 16 ECM-CX700 Series User’s Manual...
  • Page 17 • Support for VIA Vinyl HD Audio • Serial ATA support for up to 2 devices • Parallel ATA133/100/66 support for up to 2 devices • Support for up to 6 USB 2.0 ports • ECM-CX700 Series User’s Manual 17...

  • Page 18: Realtek Alc883 Ac'97 Codec

    Ten DAC channels support 16/20/24-bit PCM format for 7.1 sound playback, plus 2 • channels of independent stereo sound output (multiple streaming) through the front panel output 2 stereo ADCs support 16/20/24-bit PCM format, one for stereo microphone, the • other for legacy mixer recording 18 ECM-CX700 Series User’s Manual...
  • Page 19 Microphone Acoustic Echo Cancellation (AEC), Noise Suppression (NS), and • Beam Forming (BF) technology for voice application ALC883D features optional Dolby® Digital Live output for consumer equipment • ALC883DTS features optional DTS® Connect software • ECM-CX700 Series User’s Manual 19...

  • Page 20: Via Vt1211 Super I/O

    Duty cycle resolution of 1/256 — Flash-ROM Interface • Supports up to 4MB flash ROM — SmartGuardian Controller • Provides automatic temperature to fan speed control — Supports mix-and-match for temperature inputs and fan speed control outputs — 20 ECM-CX700 Series User’s Manual...
  • Page 21 Times out the system, based on a user-programmable time-out period — Time resolution 1 minute, maximum 255 minutes — Dedicated Infrared pins • Compliant with IrDA 1.4 for VFIR — Single 48MHz Clock Input • Single 3.3V Power Supply • 128-pin LPQF • ECM-CX700 Series User’s Manual 21...

  • Page 22: Ethernet-Realtek Rtl8101L Ethernet Controller

    “glue” logic or external memory. The RTL8101L includes a PCI and Expansion Memory Share Interface (Realtek patent) for a boot ROM and can be used in diskless workstations, providing maximum network security and ease of management. 22 ECM-CX700 Series User’s Manual...

  • Page 23: Compact Flash Interface

    PC card, PDA, and Smart Cellular Phones, allowing simple use for the end user. The Compact Flash storage card is O/S independent, thus offering an optimal solution for embedded systems operating in non-standard computing environments. The Compact Flash storage card is IDE compatible and offers various capacities. ECM-CX700 Series User’s Manual 23...

  • Page 24: Hardware Configuration

    ECM-CX700 2. Hardware Configuration 24 ECM-CX700 Series User’s Manual...

  • Page 25: Product Overview

    User’s Manual 2.1 Product Overview JFAN2 ECM-CX700 Series User’s Manual 25...

  • Page 26: Installation Procedure

    7. If TFT panel display is to be utilized, make sure the panel voltage is correctly set before connecting the display cable and turning on the power. 2.2.1 Main Memory ECM-CX700 series provides one 200-pin SODIMM sockets to support DDR2 SDRAM. The maximum memory size is 1GB. SODIMM1 (Rear Side) Make sure to unplug the power supply before adding or removing SODIMM or other system components.
  • Page 27 (2) Static electricity can damage the electronic components of the computer or optional boards. Before starting these procedures, ensure that you are discharged of static electricity by touching a grounded metal object briefly. ECM-CX700 Series User’s Manual 27...

  • Page 28: Jumper And Connector List

    2 x 1 header, pitch 2.00mm AT/ATX power select JSUS1 3 x 1 header, pitch 2.54mm JCMOS1 Clear CMOS 3 x 1 header, pitch 2.00mm JVIO1 PCI 104 voltage select 3 x 2 header, pitch 2.54mm 28 ECM-CX700 Series User’s Manual...
  • Page 29 USB connector 2 & 3 5 x 2 header, pitch 2.0mm JUSB2 JVGA1 VGA connector D-sub 15-pin, Female JVR1 LCD backlight brightness adjustment 3 x 1 header, pitch 2.54mm LED1 Power & HDD indicator Reset button ECM-CX700 Series User’s Manual 29...

  • Page 30: Setting Jumpers & Connectors

    ECM-CX700 2.4 Setting Jumpers & Connectors 2.4.1 AT/ATX Power Select (JAT1, JSUS1) JAT1 * Default JSUS1 Signal PWR_ON VCCSB Note: The default sets 2-3 closed for AT power used. 30 ECM-CX700 Series User’s Manual...

  • Page 31: Clear Cmos (Jcmos1)

    User’s Manual 2.4.2 Clear CMOS (JCMOS1) Protect * Clear CMOS * Default 2.4.3 PCI-104 Voltage Select (JVIO1) +5V* +3.3V * Default ECM-CX700 Series User’s Manual 31...

  • Page 32: Audio Connector (Jaud1)

    The MIC signal is used for microphone input. This input is fed to the left microphone channel. CEN-OUT Center Out channel (im-amplified) SURR-OUT L/R Surround Out Feft and Right channel SPDIF OUT PCM Non-Audio Sony/Philips Digital I/F Output (Internal pulled high). 32 ECM-CX700 Series User’s Manual...

  • Page 33: Cd-Rom Audio Input Connector (Jcd1)

    User’s Manual 2.4.5 CD-ROM Audio Input Connector (JCD1) Signal CD_L CD_R 2.4.5.1 Signal Description – CD-ROM Audio Input Connecter (JCD1) Signal Signal Description CD_R Right CD-IN signal CD_L Left CD-IN signal. ECM-CX700 Series User’s Manual 33...

  • Page 34: Serial Port 1 Connector (Jcom1)

    Clear To Send. This signal indicates that the modem or data set is ready to exchange data. Data Carrier Detect. This signal indicates that the modem or data set has detected the data carrier. Ring Indicator. This signal indicates that the modem has received a telephone ringing signal. 34 ECM-CX700 Series User’s Manual...

  • Page 35: Serial Port 2 Connector In Rs-232 Mode (Jcom2)

    User’s Manual 2.4.7 Serial Port 2 Connector in RS-232 Mode (JCOM2) Signal Signal 2.4.8 Serial Port 2 Connector in RS-422 Mode (JCOM2) Signal Signal RxD- TxD+ RxD+ TxD- ECM-CX700 Series User’s Manual 35...

  • Page 36: Serial Port 2 Connector In Rs-485 Mode (Jcom2)

    ECM-CX700 2.4.9 Serial Port 2 Connector in RS-485 Mode (JCOM2) Signal Signal DATA+ DATA- 36 ECM-CX700 Series User’s Manual...
  • Page 37 The data and control signal pairs should be terminated in each end of the communication line with a resistor matching the cable impedance (typical 100-120 Ω). Stubs to substations should be avoided. ECM-CX700 Series User’s Manual 37...

  • Page 38: General Purpose I/O Connector (Jdio1)

    GP12 GP15 GP11 GP14 GP10 2.4.10.1 Signal Description – General Purpose I/O Connecter (JDIO1) Signal Signal Description GP [10:17] Digital Input/Output Data Bit 0 to Bit 8 2.4.11 System Fan Connector (JFAN1&2) JFAN1 Signal JFAN2 38 ECM-CX700 Series User’s Manual...

  • Page 39: Primary Ide Connector (Jide1)

    Primary IDE Connector (JIDE1) Signal Signal RESET# PDD7 PDD8 PDD6 PDD9 PDD5 PDD10 PDD4 PDD11 PDD3 PDD12 PDD2 PDD13 PDD1 PDD14 PDD0 PDD15 PDREQ PDIOW# PDIOR# PIORDY PDACK# IRQ15 PDA1 PDA0 PDA2 PDCS1# PDCS3# HD_LED1 ECM-CX700 Series User’s Manual 39...
  • Page 40 DMA Acknowledge. The DACK# acknowledges the DREQ request to initiate DMA transfers. PDACT# Signal from hard disk indicating hard disk activity. The signal level depends on the hard disk type, normally active low. The signal is routed directly to the LED1. 40 ECM-CX700 Series User’s Manual...

  • Page 41: Lcd Inverter Connector (Jinv1)

    LCD brightness through the VR signal controlled by JVR1. Please see the JVR1 section for detailed circuitry information. 2.4.13.1 Signal Description – LCD Inverter Connector (JINV1) Signal Signal Description Vadj = 0.75V ~ 4.25V (Recommended: 4.7K , >1/16W) ENBKL LCD backlight ON/OFF control signal ECM-CX700 Series User’s Manual 41...

  • Page 42: Irda Connector (Jir1)

    ECM-CX700 2.4.14 IrDA Connector (JIR1) Signal IRTX IRRX 2.4.14.1 Signal Description – IrDA Connector (JIR1) Signal Signal Description IRRX Infrared Receiver input IRTX Infrared Transmitter output 42 ECM-CX700 Series User’s Manual...

  • Page 43: Ps/2 Keyboard & Mouse Connector (Jkb1)

    Bi-directional serial data line used to transfer data from or commands to the PS/2 MDAT mouse. 2.4.16 RJ-45 Ethernet (JLAN1, JLAN2) Port Description Allows connection to a Local RJ-45 Area Network (LAN) through a network hub. ECM-CX700 Series User’s Manual 43...

  • Page 44: Lvds Connector (Jlvds1)

    C interface for panel parameter EEPROM. This EERPOM is mounted on the LVDS receiver. The data in the EEPROM allows the EXT module to automatically C_DAT, I C_CLK set the proper timing parameters for a specific LCD panel. 44 ECM-CX700 Series User’s Manual...

  • Page 45: Atx Power Switch Connector (Jps1)

    User’s Manual 2.4.18 ATX Power Switch Connector (JPS1) Signal PW_BN 2.4.19 Power Connector (JPWR1) Signal +12V ECM-CX700 Series User’s Manual 45...

  • Page 46: Tv Connector (Jtv1)

    ECM-CX700 2.4.20 TV Connector (JTV1) Signal R/Pr/C B/Pb/CVBS DAC Output Mode AV-signal CVBS S-video TV-Signal Y Pb Pr Y Cb Cr 2.4.21 USB Connector 0 & 1 (JUSB1) Signal Signal 46 ECM-CX700 Series User’s Manual...
  • Page 47 User’s Manual ECM-CX700 Series User’s Manual 47...

  • Page 48: Usb Connector 2 & 3 (Jusb2)

    NRZI encoding. The signalling bit rate is up to 12 Mbs. Differential bi-directional data signal for USB channel 1, 3. Clock is transmitted D1+/-, D3+/- along with the data using NRZI encoding. The signalling bit rate is up to 12 Mbs. 48 ECM-CX700 Series User’s Manual...

  • Page 49: Vga Connector (Jvga1)

    Analog output carrying the red colour signal to the CRT. For 75 cable impedance. Analog output carrying the green colour signal to the CRT. For 75 cable GREEN impedance. Analog output carrying the blue colour signal to the CRT. For 75 cable BLUE impedance. ECM-CX700 Series User’s Manual 49...

  • Page 50: Lcd Backlight Brightness Adjustment Connector (Jvr1)

    ECM-CX700 2.4.24 LCD Backlight Brightness Adjustment Connector (JVR1) Signal JVR1 JINV1 pin 4 Variation Resistor (Recommended: 4.7K , >1/16W) 50 ECM-CX700 Series User’s Manual...

  • Page 51: Bios Setup

    User’s Manual 3. BIOS Setup ECM-CX700 Series User’s Manual 51...

  • Page 52: Starting Setup

    If you do not press the keys at the correct time and the system does not boot, an error message will be displayed and you will again be asked to. Press F1 to Continue, DEL to enter SETUP 52 ECM-CX700 Series User’s Manual...

  • Page 53: Using Setup

    Save all the CMOS changes, only for Main Menu Navigating Through The Menu Bar • Use the left and right arrow keys to choose the menu you want to be in. Note: Some of the navigation keys differ from one screen to another. ECM-CX700 Series User’s Manual 53...

  • Page 54: Getting Help

    Award and your systems manufacturer to provide the absolute maximum performance and reliability. Even a seemingly small change to the chipset setup has the potential for causing you to use the override. 54 ECM-CX700 Series User’s Manual...

  • Page 55: Main Menu

    Note: The BIOS setup screens shown in this chapter are for reference purposes only, and may not exactly match what you see on your screen. Visit the Avalue website (www.avalue.com.tw) to download the latest product and BIOS information. ECM-CX700 Series User’s Manual 55...

  • Page 56: Standard Cmos Features

    CGA 80 MONO All Errors No Errors Select the situation in which you want the BIOS Halt On All, but Keyboard to stop the POST process and notify you All, but Diskette All, but Disk/Key 56 ECM-CX700 Series User’s Manual...
  • Page 57 **** Warning: Setting a value of 65535 means Precomp Max = 65535 no hard disk Min = 0 Landing zone **** Max = 65535 Min = 0 Sector Number of sectors per track Max = 255 ECM-CX700 Series User’s Manual 57...

  • Page 58: Advanced Bios Features

    16 Min, 32 Min Thermal. Thermal Monitor 1 Allow you to choose the thermal management Thermal Management Thermal Monitor 2 method of your monitor. To stop buffer overflow attacks against the Execute Disable Bit Enabled, Disabled operating system. 58 ECM-CX700 Series User’s Manual...
  • Page 59 This category speeds up Power On Self Test (POST) after you power up the computer. If it is set to Enable, BIOS will shorten or skip some check items during POST. Item Description Enabled Enable quick POST Disabled Normal POST ECM-CX700 Series User’s Manual 59...
  • Page 60 Note: To disable security, select PASSWORD SETTING at Main Menu and then you will be asked to enter password. Do not type anything and just press <Enter>, it will disable security. Once the security is disabled, the system will boot and you can enter Setup freely. 60 ECM-CX700 Series User’s Manual...
  • Page 61 3.5.2.17 Small Logo (EPA) Show This item allows you enabled/disabled the small EPA logo show on screen at the POST step. Item Description Enabled EPA Logo show is enabled Disabled EPA Logo show is disabled ECM-CX700 Series User’s Manual 61...

  • Page 62: Advanced Chipset Features

    Such a scenario might well occur if your system had mixed speed DRAM chips installed so that greater delays may be required to preserve the integrity of the data held in the slower memory chips. 62 ECM-CX700 Series User’s Manual...
  • Page 63 SODIMM in the system. 2T Command DRAM Command Rate Allows to set the DRAM Command Rate. 1T Command Manual RDSAIT Mode Allows to select RSDAIT Mode. Auto RDSAIT Selection Allows to set RSDAIT selectiion. ECM-CX700 Series User’s Manual 63...
  • Page 64 1600x1200 2x18B 1280x800 1x18B Select Panel Resolution that will be displayed Panel Type 800x480 1x18B depending on the LCD Panel (LFP) 1024x768 2x18B 1024x768 1x24B 1024x768 2x24B 1280x768 1x24B 1280x1024 2x24B 1400x1050 2x24B 1600x1200 2x24B 64 ECM-CX700 Series User’s Manual...
  • Page 65 You can reserve this area of system memory for ISA adapter ROM. When this area is reserved it cannot be cached. The user information of peripherals that need to use this area of system memory usually2 discussed their memory requirements. The choices: Disabled, 15M-16M. ECM-CX700 Series User’s Manual 65...
  • Page 66 It enables or disables the caching of the video RAM at A0000h-AFFFFh. This greatly speeds up the video performance. Item Description Enabled Cacheable Disabled Non-Cacheable 3.5.3.7 Init Display First This item allows you to decide to active whether PCI Slot or Onboard/AGP first. The choices: PCI Slot, AGP. 66 ECM-CX700 Series User’s Manual...

  • Page 67: Integrated Peripherals

    User’s Manual 3.5.4 Integrated Peripherals Use this menu to specify your settings for integrated peripherals. 3.5.4.1 VIA OnChip IDE Device ECM-CX700 Series User’s Manual 67...
  • Page 68 If the IDE hard drive supports block Enabled IDE HDD Block Mode mode (most new drives do), select Enabled for Disabled automatic detection of the optimal number of block read/writes per sector the drive can support. 68 ECM-CX700 Series User’s Manual...
  • Page 69 User’s Manual 3.5.4.2 VIA OnChip PCI Device Item Options Description This item allows decide Auto AC97 Audio Codec enable/disable the VIA chipset family to support Disabled AC97 Audio. 3.5.4.3 Super IO Device ECM-CX700 Series User’s Manual 69...
  • Page 70 Select EPP port type 1.7 or 1.9. EPP1.7 ECP Mode Use DMA Select a DMA channel for the port. Disabled Watch Dog Timer Select 10, 20, 30, 40 Sec. This option will determine watch dog timer. 1, 2, 4 Min 70 ECM-CX700 Series User’s Manual...
  • Page 71 USB keyboard support. Enabled This item allows you to enable or disable the USB Mouse Function Disabled USB mouse support. Enabled This item allows you to enable or disable the USB Storage Function Disabled USB storage support. ECM-CX700 Series User’s Manual 71...

  • Page 72: Power Management Setup

    HDD Power Down There are three selections for Power Management Option; both of them have fixed mode settings. The choices: Disabled, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15 Min. 72 ECM-CX700 Series User’s Manual...
  • Page 73 Select whether to run VGA BIOS if resuming from S3 state. This is only necessary for older VGA drivers.. The choices: Auto, Yes, No. 3.5.5.10 Ac Loss Auto Restart: This item is to set whether to run Ac Loss Auto Restart. The choices: Off, On, Former-Sts. ECM-CX700 Series User’s Manual 73...
  • Page 74 This item allows the modem ring to wake up the Modem Ring Resume Enabled computer system from a power saving mode. Enabled Sets scheduled time and/or date RTC Alarm Resume Disabled automatically power on the system. 74 ECM-CX700 Series User’s Manual...

  • Page 75: Pnp / Pci Configuration

    Plug and Play operating system such as Windows®95. If you set this field to “manual” choose specific resources by going into each of the sub menu that follows this field (a sub menu is preceded by a “ ”). The choices: Auto(ESCD), Manual. ECM-CX700 Series User’s Manual 75...
  • Page 76 The choices: Enabled, Disabled. 3.5.6.8 Maximum ASPM Supported This field is used to control the maximum level of supported ASPM on the given PCI Express link on the system The choices: L0, Los, L1, L0s&L1. 76 ECM-CX700 Series User’s Manual...

  • Page 77: Pc Health Status

    This field is used to select the maximum TLP payload size of the PCI Express devices. The unit is byte. The choices: 128, 256, 512, 1024, 2048, 4096. 3.5.7 PC Health Status This section shows the status of your CPU, Fan & System. ECM-CX700 Series User’s Manual 77...

  • Page 78: Frequency / Voltage Control

    Load Fail-Safe Defaults Use this menu to load the BIOS default values for the minimal/stable performance for your system to operate. Press <Y> to load the BIOS default values for the most stable, minimal-performance system operations. 78 ECM-CX700 Series User’s Manual...

  • Page 79: Load Optimized Defaults

    Press <Y> to load the default values setting for optimal performance system operations. 3.5.11 Set Supervisor / User Password You can set either supervisor or user password, or both of them. Supervisor Password: able to enter/change the options of setup menus. ECM-CX700 Series User’s Manual 79...
  • Page 80 Features Setup Menu and its Security option (see Section 3). If the Security option is set to “System”, the password will be required both at boot and at entry to Setup. If set to “Setup”, prompting only occurs when trying to enter Setup 80 ECM-CX700 Series User’s Manual...

  • Page 81: Save & Exit Setup

    Setup selection stored in CMOS when boot the computer next time. The system is restarted after saving the values. 3.5.13 Exit Without Save Abandon all CMOS value changes and exit setup, and the system is restarted after exiting. ECM-CX700 Series User’s Manual 81...

  • Page 82: Drivers Installation

    ECM-CX700 4. Drivers Installation Note: Installation procedures and screen shots in this section are for your reference and may not be exactly the same as shown on your screen. 82 ECM-CX700 Series User’s Manual...

  • Page 83: Install Chipset Driver (For Via Cx700M)

    Step 3. Click Next to run the setup. Step 4. Click Next to run another Step 1. Locate「\Driver_Chipset\VIA\CX700\ installation procedure. VIA_HyperionPro_V510A\setup.exe」. Step 2. Click Next to run the setup. Step 5. Click Finish to restart the PC. ECM-CX700 Series User’s Manual 83...

  • Page 84: Install Display Driver (For Via Cx700)

    Note: The installation procedures and screen shots in this section are based on Windows XP operation system. Step1. Locate 「\Driver_Chipset\VIA \CX700\cx700_xp_16-94-44-64_VGA \VT3324_WinXP_16-94-44-64_wIShld \wIShld\Setup.exe」. Step 2. Setup will run the installation automatically, then click Finish to restart the PC.. 84 ECM-CX700 Series User’s Manual...

  • Page 85: Install Audio Driver (For Realtek Alc883/ 7.1 Ch With S/Pdif)

    Windows XP operation system. Step 3. Select Next to the next step. Step 1. Locate 「\Driver_Audio\Realtek\ Step 4. Click Finish to complete the setup. ALC883\Windows XP\WDM_R145\ 5288_PG215_R145_UAAV10a-5013」. Step 2. The program executes the Setup automatically. ECM-CX700 Series User’s Manual 85...

  • Page 86: Install Audio Driver (For Realtek Alc883/ 5.1Ch)

    You can enable 5.1CH by choosing 6CH Speaker from it. Step 1. Locate 「\Driver_Audio\Realtek\ ALC883\Windows XP\」and copy 3 files: HDACfg.dat, HDACfg.txt, rtkhdaud.dat . Step 2. Locate 「\WINDOWS\system32\drivers\」and paste 3 files under this folder . 86 ECM-CX700 Series User’s Manual...

  • Page 87: Install Ethernet Driver (For Realtek Rtl8111B)

    Step 3. Click Next to run the installation. based on Windows XP operation system. Step 1. Locate 「\Driver_Gigabit\Realtek\ Step 4. Click Finish to complete the setup. RTL8111B\PCIE_InstallShield_5646 \Setup.exe」. Step 2. Click Next. ECM-CX700 Series User’s Manual 87...

  • Page 88: Install Touch Panel Driver (For Penmount Dmc6000)

    Step 3. Select I Agree and click Next to based on Windows XP operation the following step. system. Step 4. Click Install to run the setup. Step 1. Locate「\Driver_TouchPanel\ PenMount\DMC6000\setup.exe」. Step 2. Click Next. Step 5. Click Continue Anyway. 88 ECM-CX700 Series User’s Manual...
  • Page 89 User’s Manual Step 6. Click Continue Anyway and the installation will complete automatically. ECM-CX700 Series User’s Manual 89...

  • Page 90: Mechanical Drawing

    ECM-CX700 5. Mechanical Drawing 90 ECM-CX700 Series User’s Manual...
  • Page 91 User’s Manual (Unit: mm) ECM-CX700 Series User’s Manual 91...

  • Page 92: Appendix A: Bios Revisions

    ECM-CX700 Appendix A: BIOS Revisions BIOS Rev. New Features Bugs/Problems Solved Known Problems 92 ECM-CX700 Series User’s Manual...

  • Page 93: Appendix B: Award Bios Post Messages

    User’s Manual Appendix B: AWARD BIOS POST Messages ECM-CX700 Series User’s Manual 93...

  • Page 94: Overview

    Then reboot the system. DISKETTE DRIVES OR TYPES MISMATCH ERROR - RUN SETUP Type of diskette drive installed in the system is different from the CMOS definition. Run Setup to reconfigure the drive type correctly. 94 ECM-CX700 Series User’s Manual...

  • Page 95: Display Switch Is Set Incorrectly

    Cannot find or initialize the floppy drive controller. Make sure the controller is installed correctly and firmly. If there are no floppy drives installed, be sure the Diskette Drive selection in Setup is set to NONE. ECM-CX700 Series User’s Manual 95...

  • Page 96: Invalid Eisa Configuration Please Run Eisa Configuration Utility

    ERROR messages when the segment that has caused the problem cannot be isolated. 19. OFFENDING SEGMENT: This message is used in conjunction with the I/O CHANNEL CHECK and RAM PARITY ERROR messages when the segment that has caused the problem has been isolated. 96 ECM-CX700 Series User’s Manual...

  • Page 97: Press A Key To Reboot

    EISA Configuration Utility. 26. SYSTEM HALTED, (CTRL-ALT-DEL) TO REBOOT ... Indicates the present boot attempt has been aborted and the system must be rebooted. Press and hold down the CTRL and ALT keys and press DEL. ECM-CX700 Series User’s Manual 97...

  • Page 98: Wrong Board In Slot Please Run Eisa Configuration Utility

    This is also used for M/B burn in test. 38. BIOS ROM checksum error - System halted. The checksum of ROM address F0000H-FFFFFH is bad. 39. Memory test fail. BIOS reports the memory test fail if the onboard memory is tested error. 98 ECM-CX700 Series User’s Manual...

  • Page 99: Post Codes

    Use walking 1’s algorithm to check out interface in CMOS circuitry. Also set real-time clock power status, and then check for override. Reserved Program chipset default values into chipset. Chipset default values are MODBINable by OEM customers. ECM-CX700 Series User’s Manual 99...
  • Page 100 1. Program CPU internal MTRR (P6 & PII) for 0-640K memory address. 2. Initialize the APIC for Pentium class CPU. 3. Program early chipset according to CMOS setup. Example: onboard IDE controller. 4. Measure CPU speed. 5. Invoke video BIOS. Reserved Reserved Reserved 100 ECM-CX700 Series User’s Manual...
  • Page 101 3. Initialize the APIC for P6 class CPU. 4. On MP platform, adjust the cacheable range to smaller one in case the cacheable ranges between each CPU are not identical. Reserved Initialize USB ECM-CX700 Series User’s Manual 101...
  • Page 102 1. Assign resources to all ISA PnP devices. 2. Auto assign ports to onboard COM ports if the corresponding item in Setup is set to “AUTO”. Reserved 1. Initialize floppy controller 2. Set up floppy related fields in 40:hardware. Reserved Reserved Reserved 102 ECM-CX700 Series User’s Manual...
  • Page 103 5. Invoke ISA adapter ROMs 6. Assign IRQs to PCI devices 7. Initialize APM 8. Clear noise of IRQs. Reserved Reserved Reserved Reserved Reserved Reserved Reserved Read HDD boot sector information for Trend Anti-Virus code ECM-CX700 Series User’s Manual 103...
  • Page 104 1. Update keyboard LED & typematic rate 1. Build MP table 2. Build & update ESCD 3. Set CMOS century to 20h or 19h 4. Load CMOS time into DOS timer tick 5. Build MSIRQ routing table. Boot attempt (INT 19h) 104 ECM-CX700 Series User’s Manual...
