- Page 1 EMX-G41 Mini-ITX Intel® G41 LGA775 socket for Intel® Core™2 Quad User’s Manual Ed – 27 december 2010...
-
Page 2: Fcc Statement
Disclaimer Avalue Technology Inc. reserves the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance. Avalue Technology assumes no responsibility or liability for the... - Page 3 User’s Manual Life Support Policy Avalue Technology’s PRODUCTS ARE NOT FOR USE AS CRITICAL COMPONENTS IN LIFE SUPPORT DEVICES OR SYSTEMS WITHOUT THE PRIOR WRITTEN APPROVAL OF Avalue Technology Inc. As used herein: 1. Life support devices or systems are devices or systems which, (a) are intended for...
- Page 4 Avalue Technology Inc. Room 805, Building 9,No.99 Tianzhou Rd., 2F keduka-Bldg, 2-27-3 Taito, Caohejing Development Area, Taito-Ku, Tokyo 110-0016 Japan Xuhui District, Shanghai Tel: +81-3-5807-2321 Tel: +86-21-5169-3609 Fax:+86-21-5445-3266 Fax: +81-3-5807-2322 Information: sales.china@avalue.com.cn Information: sales.japan@avalue.com.tw Service: service@avalue.com.tw Service: service@avalue.com.tw 4 EMX-G41 User’s Manual...
- Page 5 (such as your sales receipt) in a shippable container. A product returned without proof of the purchase date is not eligible for warranty service. 5. Write the RMA number visibly on the outside of the package and ship it prepaid to your dealer. EMX-G41 User’s Manual 5...
-
Page 6: Table Of Contents
General purpose I/O connector (JDIO1) ..................25 2.3.9 Parallel port connector (LPT1) ....................... 26 2.3.10 SPI connector (SP1) ........................27 2.3.11 USB connector (USB45) ......................27 2.3.12 Low Pin Count Interface (80PORT1) ..................28 3. Mechanical Drawing ....................29 6 EMX-G41 User’s Manual... -
Page 7: Getting Started
Before you begin installing your single board, please make sure that the following parts have been shipped. 1 x EMX-G41 Intel® G41 Mini-ITX Module 1 x Quick Installation Guide DVD ROM containing Drivers and Utilities Sata cable kit(sata/power) Com 9p cable w/o bracket ph:2.00mm... -
Page 8: Document Amendment History
EMX-G41 1.3 Document Amendment History Revision Date Comment December Initial Release 2010 8 EMX-G41 User’s Manual... -
Page 9: Manual Objectives
We strongly recommend that you study this manual carefully before attempting to interface with EMX-G41 series or change the standard configurations. Whilst all the necessary information is available in this manual we would recommend that unless you are confident, you contact your supplier for guidance. -
Page 10: System Specifications
CPU overheats SmartFan Control Yes, CPU FAN (by SIO) Power Type ATX (20+4pin) Power Management ACPI S1/S3/S4 Internal I/O interface USB 1.1/2.0 x pin-header support 2 devices (2x5, pitch 2.54mm) LVDS LCD Inverter 10 EMX-G41 User’s Manual... - Page 11 Mechanical Form Factor Mini-ITX Size (L x W) 170x170mm Environmental Power Requirement T.B.D. Operating Temperature 0~60°C Operating Humidity 0%~90% Relative humidity (Non-condensing) Certifications CE/FCC Class A Supported OS Windows Windows XP / Windows 7 Linux T.B.D. EMX-G41 User’s Manual 11...
-
Page 12: Architecture Overview - Block Diagram
EMX-G41 1.6 Architecture Overview – Block Diagram The following block diagram shows the architecture and main components of EMX-G41. 12 EMX-G41 User’s Manual... -
Page 13: Hardware Configuration
User’s Manual 2. Hardware Configuration EMX-G41 User’s Manual 13... -
Page 14: Product Overview
EMX-G41 2.1 Product Overview 14 EMX-G41 User’s Manual... -
Page 15: Installation Procedure
Note: Make sure the heat sink and the CPU top surface are in total contact to avoid CPU overheating problem that would cause the system to hang or unstable EMX-G41 User’s Manual 15... -
Page 16: Main Memory
EMX-G41 2.2.1 Main Memory EMX-G41 provides 1 x 240 pin DDR DIMM socket that supports DDRII memories 667/800 MHz up to 2GB DIMM Make sure to unplug the power supply before adding or removing DIMMs or other system components. Failure to do so may cause severe damage to both the board and the components. - Page 17 (2) Static electricity can damage the electronic components of the computer or optional boards. Before starting these procedures, ensure that you are discharged of static electricity by briefly touching a grounded metal object. EMX-G41 User’s Manual 17...
-
Page 18: Jumper And Connector List
3 x 1 header, pitch 2.54mm CLRTC1 CHASSIS1 Chassis Intrusion Connector 4 x 1 header, pitch 2.54mm JCOMPWR1 Power Selector 3 x 2 header, pitch 2.0mm Ring /+5V/+12V JCOMPWR2 Power Selector 3 x 2 header, pitch 2.0mm Ring /+5V/+12V 18 EMX-G41 User’s Manual... - Page 19 System fan connector 3 x 1 wafer, pitch 2.54mm USB45 USB connector 5 x 2 header, pitch 2.54mm VGA1 VGA connector 1 & 2 D-sub 15-pin, female 80PORT1 Low Pin Count Interface 10 x 2 header, pitch 2.0mm EMX-G41 User’s Manual 19...
-
Page 20: Setting Jumpers & Connectors
EMX-G41 2.4 Setting Jumpers & Connectors 2.4.1 Clear CMOS (CLRTC1) Normal* Clear CMOS Default* 2.4.2 Chassis Intrusion Connector (CHASSIS1) +5V* Signal Chassis signal Default* 20 EMX-G41 User’s Manual... -
Page 21: Power Selector - Ring, +5V, +12V (Jcompwr1/ Jcompwr2)
User’s Manual 2.3.4 Power selector – Ring, +5V, +12V (JCOMPWR1/ JCOMPWR2) Ring* JCOMPWR2 +12V *Default EMX-G41 User’s Manual 21... -
Page 22: Atx Power Connector (Eatxpwr1)
EMX-G41 2.4.3 ATX power connector (EATXPWR1) Signal Signal +12V +5VSB ATX_PWR PSON# +3.3V -12V +3.3V +3.3V 2.4.4 VRM Power supply connector (ATX12V1) Signal Signal +12V +12V 22 EMX-G41 User’s Manual... -
Page 23: Front Panel Audio Connector (Aafp1)
User’s Manual 2.3.3 Front Panel Audio connector (AAFP1) Signal PIN PIN Signal SENSE2_RTN 10 PORT2 L SENSE_SEND SENSE1_RTN PORT2 R PRESENSE PORT1 R AGND PORT1 L 2.3.4 Amplifier connector (CN22) Signal AMP_L- AMP_L+ AMP_R- AMP_R+ EMX-G41 User’s Manual 23... -
Page 24: Cpu Fan Connector (Cpu_Fan1)
EMX-G41 2.3.5 CPU Fan Connector (CPU_FAN1) CPU_FAN1 Signal +12V FTAC2 FCTL2 2.3.6 System Fan Connector (SYS_FAN1) Signal +12V FTAC1 24 EMX-G41 User’s Manual... -
Page 25: Front Panel Connector (F_Panel1)
User’s Manual 2.3.7 Front Panel Connector (F_PANEL1) Signal PIN PIN Signal HDLED+ FP_LED+ HD_LED# FP_LED- PWRBTN#IN SYS_RESET# 2.3.8 General purpose I/O connector (JDIO1) Signal Signal DATA GPI3 GPO3 GPI2 GPO2 GPI1 GPO1 GPI0 GPO0 EMX-G41 User’s Manual 25... -
Page 26: Parallel Port Connector (Lpt1)
EMX-G41 2.3.9 Parallel port connector (LPT1) Signal Signal STB# AFD# ERR# INIT# SLIN# ACK# BUSY SLCT 26 EMX-G41 User’s Manual... -
Page 27: Spi Connector (Sp1)
User’s Manual 2.3.10 SPI connector (SP1) Signal Signal SPI_HOLD# SPI_MOSI SPI_MISO SPI_CLK SPI_CS# +3.3V 2.3.11 USB connector (USB45) Signal Signal +5V_DUAL +5V_DUAL USBP4-_C USBP5-_C USBP4+_C USBP5+_C EMX-G41 User’s Manual 27... -
Page 28: Low Pin Count Interface (80Port1)
EMX-G41 2.3.12 Low Pin Count Interface (80PORT1) Signal Signal PCICLKP80 LAD0 LFRAME# LAD2 LAD1 PLTRST# LAD3 +3.3V 28 EMX-G41 User’s Manual... -
Page 29: Mechanical Drawing
User’s Manual 3. Mechanical Drawing EMX-G41 User’s Manual 29... - Page 30 EMX-G41 30 EMX-G41 User’s Manual...
