- Page 1 ECM-MTL Intel® Core™ Ultra 5 Processor 125U 125H 3.5” Micro Module User’s Manual Ed – 11 March 2025 Copyright Notice Copyright © 2025 Avalue Technology Inc., ALL RIGHTS RESERVED. Part No: E2047396600R...
-
Page 2: Document Amendment History
ECM-MTL User’s Manual Document Amendment History Revision Date Comment March 2025 Avalue Initial Release 2 ECM-MTL User’s Manual... -
Page 3: Declaration Of Conformity
For detailed information, please always refer to the electronic user's manual. Copyright Notice © 2025 by Avalue Technology Inc. All rights are reserved. No parts of this manual may be copied, modified, or reproduced in any form or by any means for commercial use without the prior written permission of Avalue Technology Inc. -
Page 4: A Message To The Customer
ㆍDescription of your software (operating system, version, application software, etc.) ㆍA complete description of the problem ㆍThe exact wording of any error messages To receive the latest version of the user’s manual; please visit our Web site at: www.avalue.com 4 ECM-MTL User’s Manual... - Page 5 On the other hand, if the new product defect is resulting from incorrect configuration or erroneous use by the user instead of any problem of the hardware itself, the customer will also be requested to pay for relevant handling fees. ECM-MTL User’s Manual...
- Page 6 Lacking detailed statement of fault steps also makes the problem hard to be identified, sometimes resulting in second-time repairs. 6 ECM-MTL User’s Manual...
- Page 7 • Product has been altered or its label of the serial number has been torn off. • Product functionality issues resulting from improper use by the user, unauthorized dismantle or alteration, unfit operation environment, improper maintenance, accident ECM-MTL User’s Manual...
- Page 8 If the customer demands an additional maintenance analysis report, a service fee of various level will be charged depending on the warranty status. In case the analysis result shows that the defect attributes to Avalue’s faulty design or process, the analysis fee will be exempted. 8 ECM-MTL User’s Manual...
-
Page 9: Safety Instructions
9. Position the power cord so that people cannot step on it. Do not place anything over the power cord. 10. All cautions and warnings on the equipment should be noted. 11. If the equipment is not used for a long time, disconnect it from the power source to ECM-MTL User’s Manual... - Page 10 The equipment has obvious signs of breakage. 14. CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. 15. Equipment intended only for use in a RESTRICTED ACCESS AREA. 10 ECM-MTL User’s Manual...
-
Page 11: Explanation Of Graphical Symbols
A NOTE provides additional information intended to avoid Note inconveniences during operation. Direct current. Alternating current Stand-by, Power on FCC Certification CE Certification Follow the national requirements for disposal of equipment. Stacking layer limit This side up ECM-MTL User’s Manual 11... - Page 12 ECM-MTL User’s Manual Fragile Packaging Beware of water damage, moisture-proof Carton recyclable Handle with care Follow operating instructions of consult instructions for use. 12 ECM-MTL User’s Manual...
-
Page 13: Disposing Of Your Old Product
EXPLOSION ou une fuite de liquide ou de gaz inflammable. - UNE BATTERIE soumise à une pression d'air extrêmement basse pouvant entraî ner une EXPLOSION ou une fuite de liquide ou de gaz inflammable. ECM-MTL User’s Manual 13... -
Page 14: Table Of Contents
LED connector (JLED1) ......................40 2.3.23 Audio connector (JAUDIO1) ...................... 40 Signal Description – Audio connector (JAUDIO1) ..............40 2.3.23.1 2.3.24 PD JTAG connector (JPDFW1) ....................41 2.3.25 ACT LED connector (JACT_LED1) ................... 41 2.3.26 SIM card connector (J_N_SIM1)....................42 14 ECM-MTL User’s Manual... - Page 15 4.6.2.5.5 PCI Express Root Port PXPC(M.2 KeyM) ................67 4.6.2.6 PCH-IO Configuration ......................68 4.6.2.6.1 SATA Configuration ....................... 68 4.6.2.6.2 HD Audio Configuration ......................69 4.6.2.7 PCH-FW Configuration ......................69 4.6.2.7.1 Firmware Update Configuration ..................... 70 ECM-MTL User’s Manual 15...
- Page 16 4.6.5.2 Discard Changes and Reset ....................84 4.6.5.3 Restore Defaults ........................85 4.6.5.4 Launch EFI Shell from filesystem device ................85 4.6.6 MEBx ............................85 5. Mechanical Drawing ....................86 6. Maintenance & Troubleshooting ................89 16 ECM-MTL User’s Manual...
-
Page 17: Getting Started
Before installation, please ensure all the items listed in the following table are included in the package. Item Description Q’ty ECM-MTL 3.5” Micro Module Serial ATA cable (7-pin, standard) Wire SATA power cable (15-pin, 4P/2.0mm) Flat Cable 9P(M)-PHD (10P/2.0mm) CPU Heatsink/Cooler set M.2 screws... -
Page 18: Manual Objectives
We strongly recommend that you study this manual carefully before attempting to set up ECM-MTL or change the standard configurations. Whilst all the necessary information is available in this manual we would recommend that unless you are confident, you contact your supplier for guidance. -
Page 19: System Specifications
2 x USB 3.2 Gen 2 x1 +1 x USB 3.2 Gen 1 x1 Type A +5VSB/0.9A + 1 x USB Type-C 5V3A (with USB 3.2 Gen 2x2 & DP 1.4a signal display output) 1 x DP 1.4a ECM-MTL User’s Manual 19... - Page 20 Note: This resolution is actual test result: 1 x DP 1.4a: 7680 x 4320@30 Hz Spec. & Resolution 1 x USB Type C support DP: 4096 x 2160@60Hz 1 x HDMI 2.0b: 3840 x 2160@60Hz Intel resolution as below: 20 ECM-MTL User’s Manual...
- Page 21 DC in +12V~ +24V ACPI Single power ATX Support S0, S4, S5, ACPI 5.0 compliant Power Mode HW: AT (AT / ATX mode Switchable Through Jumper) Operating Temp. 0~60°C (32~140°F) with 0.5m/s air flow Storage Temp. -40~ +75°C ECM-MTL User’s Manual 21...
- Page 22 3. Test Frequency : 5-500Hz 4. Test Axis : X,Y and Z axis 5. 30 minutes per each axis 6. IEC 60068-2-64 Test:Fh Packing Drop Drop Test Reference ISTA 2A, Method : IEC-60068-2-32 Test: Ed Drop Test 22 ECM-MTL User’s Manual...
- Page 23 If may need 28W CPU with higher power application, may use 2Px2 Wafer connector instead of DC Jack. 4. Intel Sightings report alerts for DDR5 memory instability during Power Cycle Test and may affect booting. ECM-MTL User’s Manual 23...
-
Page 24: Architecture Overview-Block Diagram
ECM-MTL User’s Manual 1.5 Architecture Overview—Block Diagram The following block diagram shows the architecture and main components of ECM-MTL. 24 ECM-MTL User’s Manual... -
Page 25: Hardware Configuration
User’s Manual 2. Hardware Configuration ECM-MTL User’s Manual 25... -
Page 26: Product Overview
ECM-MTL User’s Manual 2.1 Product Overview 26 ECM-MTL User’s Manual... -
Page 27: Jumper And Connector List
4 x 1 wafer, pitch 2.54mm JCOM1 Serial port 1 connector 5 x 2 header, pitch 2.00mm JCOM2 Serial port 2 connector 5 x 2 header, pitch 2.00mm JCOM3 Serial port 1 connector 5 x 2 header, pitch 2.00mm ECM-MTL User’s Manual 27... - Page 28 ACT LED connector 2 x 2 header, pitch 2.00mm JPDFW1 PD JTAG connector 4 x 1 header, pitch 2.00mm J_N_SIM1 SIM card connector 10 x 1 wafer, pitch 0.50mm JPC1 PC connector 6 x 1 wafer, pitch 1.00mm 28 ECM-MTL User’s Manual...
-
Page 29: Setting Jumpers & Connectors
User’s Manual 2.3 Setting Jumpers & Connectors 2.3.1 AT/ATX Input power select (JAT1) * Default 2.3.2 Clear CMOS (JRTC1) Normal* Clear CMOS * Default ECM-MTL User’s Manual 29... -
Page 30: Key Power Select (Jm2B_Pwr1)
ECM-MTL User’s Manual 2.3.3 M.2 Key power select (JM2B_PWR1) +3.3V* +3.8V * Default 2.3.4 CPU fan connector (CPU_FAN1) Signal FAN_PWM0 EC_TACH0 +12V 30 ECM-MTL User’s Manual... -
Page 31: Bios Spi Connector (Jbios1)
BIOS SPI connector (JBIOS1) Signal PIN PIN Signal +1.8VSB SPI0_CS0# SPI0_BIOS_CLK SPI0_BIOS_MISO SPI0_BIOS_MOSI SPI0_HOLD# BIOS_WP# EC_SMCLK_DEBUG 10 EC_SMDAT_DEBUG 2.3.6 ESPI connector (JESPI1) Signal PIN PIN Signal ESPI_IO0_80P +3.3VSB ESPI_IO1_80P RST_SOCKET# ESPI_IO2_80P ESPI_CS# ESPI_IO3_80P ESPI_CLK_80P ESPI_CS1# ESPI_RST# ESPI_ALERT1# ECM-MTL User’s Manual 31... -
Page 32: Edp/Lvds Connector (Edp_Lvds1)
ECM-MTL User’s Manual 2.3.7 eDP/LVDS connector (EDP_LVDS1) Signal PIN PIN Signal +12V +12V LVDS_CLK2N LVDS_CLK1N/eDPAUXN LVDS_CLK2P LVDS_CLK1P/eDPAUXP LVDS_DATAN7 LVDS_DATAN6 LVDS_DATAP7 LVDS_DATAP6 LVDS_DATAN5 LVDS_DATAN4 LVDS_DATAP5 LVDS_DATAP4 LVDS_DATAN3 LVDS_DATAN2/eDPN0 LVDS_DATAP3 LVDS_DATAP2/eDPP0 LVDS_DATAN1/eDPN1 11 LVDS_DATAN0 LVDS_DATAP1/eDPP1 10 LVDS_DATAP0/eDP_HPD +3.3V +3.3V +3.3V 32 ECM-MTL User’s Manual... -
Page 33: Serial Port 1 Connector (Jcom1)
2.3.8 Serial port 1 connector (JCOM1) Signal PIN PIN Signal COM_RXD_TXP_1 COM_DCD#_TXN_1 COM_DTR#_RXN_1 COM_TXD_RXP_1 COM_DSR#_1 COM_CTS#_1 COM_RTS#_1 COM_RI#_1 2.3.9 Serial port 2 connector (JCOM2) Signal PIN PIN Signal COM_RXD_TXP_2 COM_DCD#_TXN_2 COM_DTR#_RXN_2 COM_TXD_RXP_2 COM_DSR#_2 COM_CTS#_2 COM_RTS#_2 COM_RI#_2 ECM-MTL User’s Manual 33... -
Page 34: Serial Port 3 Connector (Jcom3)
2.3.10 Serial port 3 connector (JCOM3) Signal PIN PIN Signal NRXDC NDCDC# NDTRC# NTXDC NDSRC# NCTSC# NRTSC# NRIC# 2.3.11 Serial port 4 connector (JCOM4) Signal PIN PIN Signal NRXDD NDCDD# NDTRD# NTXDD NDSRD# NCTSD# NRTSD# NRID# 34 ECM-MTL User’s Manual... -
Page 35: General Purpose I/O Connector (Jdio1)
User’s Manual 2.3.12 General purpose I/O connector (JDIO1) Signal PIN PIN Signal SMB_SCL_S0_3P3EXT 10 SMB_SDA_S0_3P3EXT 2.3.13 LCD inverter backlight connector (JBKL1) Signal +12V BKLEN VBRIGHT ECM-MTL User’s Manual 35... -
Page 36: Usb2.0 Connector (Jusb1)
ECM-MTL User’s Manual 2.3.14 USB2.0 connector (JUSB1) Signal PIN PIN Signal +5VSB +5VSB USB2_DN5_HDR USB2_DN6_HDR USB2_DP5_HDR USB2_DP6_HDR 2.3.15 USB2.0 connector (JUSB2) Signal PIN PIN Signal +5VSB +5VSB USB2_DN7_HDR USB2_DN8_HDR USB2_DP7_HDR USB2_DP8_HDR 36 ECM-MTL User’s Manual... -
Page 37: Speaker Connector (Spk1)
User’s Manual 2.3.16 Speaker connector (SPK1) Signal SPK_L+ SPK_L- SPK_R+ SPK_R- 2.3.17 PC Buzzer connector (JBZ1) Signal SPKR- ECM-MTL User’s Manual 37... -
Page 38: Battery Connector (Jbat1)
ECM-MTL User’s Manual 2.3.18 Battery connector (JBAT1) Signal +RTCBATT_R 2.3.19 Front Panel connector (JFP1) Signal PIN PIN Signal +HD_LED +PWR_LED -HD_LED -PWR_LED +Reset +PWR_BNT -Reset -PWR_BNT 38 ECM-MTL User’s Manual... -
Page 39: Sata Power Connector (Jsata_Pwr1)
User’s Manual 2.3.20 SATA Power connector (JSATA_PWR1) Signal +12V 2.3.21 Power connector (PWR1) Signal Signal +VIN_12-24V +VIN_12-24V ECM-MTL User’s Manual 39... -
Page 40: Led Connector (Jled1)
GND_AUD GND_AUD LINEIN_R LINEIN_L MICIN_R MICIN_L LINEOUT1_JD LINE1-JD MIC1_JD GND_AUD 2.3.23.1 Signal Description – Audio connector (JAUDIO1) Signal Signal Description LINE1-JD AUDIO IN (LINE_RIN/LIN)sense pin LINEOUT1_JD AUDIO Out(ROUT/LOUT) sense pin MIC1_JD MIC IN (MIC_RIN/LIN) sense pin 40 ECM-MTL User’s Manual... -
Page 41: Pd Jtag Connector (Jpdfw1)
User’s Manual 2.3.24 PD JTAG connector (JPDFW1) Signal LDO_3V3 EEPROM_I2C_SCL EEPROM_I2C_SDA 2.3.25 ACT LED connector (JACT_LED1) Signal PIN PIN Signal LAN2_LED_ACT# LAN1_LED_ACT_P_3 LAN1_LED_ACT# LAN1_LED_ACT_P_1 ECM-MTL User’s Manual 41... -
Page 42: Sim Card Connector (J_N_Sim1)
ECM-MTL User’s Manual 2.3.26 SIM card connector (J_N_SIM1) Signal +VCC_SIM UIM_RESET# +VPP_SIM_1 UIM_CLK UIM_DATA N_SIM_CD_R 2.3.27 PC connector (JPC1) Signal +3.3VSB VCCCORE_PMSCL VCCCORE_PMSDA VCCCORE_nPMALERT 42 ECM-MTL User’s Manual... -
Page 43: Drivers Installation
HID touch digitizer built-in driver in Windows 7 or later. (For reference only) Note: Installation procedures and screen shots in this section are for your reference and may not be exactly the same as shown on your screen. ECM-MTL User’s Manual 43... -
Page 44: Install Chipset Driver
Windows 10 operation system. If the warning message appears while the installation process, click Continue to go on. Step 3. Click Install. Step1. Click Next. Step 4. Click Finish to complete setup. Step 2. Click Accept. 44 ECM-MTL User’s Manual... -
Page 45: Install Vga Driver
Windows 10 operation system. Step 3. Click Start. Step 4. Installing. Step 1. Click Begin installation. Step 2. Click I agree. Step 5. Click Finish to complete setup. ECM-MTL User’s Manual 45... -
Page 46: Install Ethernet Driver
All drivers can be found on the Avalue Official Website: www.avalue.com. Step 3. Setup completed. Note: The installation procedures and screen shots in this section are based on Windows 10 operation system. Step 1. Click Install Drivers. Step 2. Click OK. 46 ECM-MTL User’s Manual... -
Page 47: Install Me Driver
Windows 10 operation system. Step 3. Click Next. Step 1. Click Next to continue installation. Step 4. Click Next. Step 2. Click Next. Step 5. Click Finish to complete setup. ECM-MTL User’s Manual 47... -
Page 48: Install Serial Io Driver
Note: The installation procedures and screen shots in this section are based on Windows 10 operation system. Step 3. Click Next. Step 1. Click Next to continue installation. Step 4. Click Next. Step 2. Click Next. Step 5. Installing. 48 ECM-MTL User’s Manual... - Page 49 User’s Manual Step 6. Click Finish to complete setup. ECM-MTL User’s Manual 49...
-
Page 50: Install Pci Device Driver
Windows 10 operation system. Step 3. Click Browse my computer for drivers. Step 4. Installing. Step 1. Click Update driver. Step 2. Click Search automatically for Step 5. Setup completed. drivers. 50 ECM-MTL User’s Manual... -
Page 51: Bios Setup
User’s Manual 4.BIOS Setup ECM-MTL User’s Manual 51... -
Page 52: Introduction
If the message disappears before you respond and you still wish to enter Setup, restart the system to try again by turning it OFF then ON or pressing the "RESET" button on the system case. You may also restart by simultaneously pressing <Ctrl>, <Alt>, and <Delete> keys. 52 ECM-MTL User’s Manual... -
Page 53: Using Setup
Note: Some of the navigation keys differ from one screen to another. • To Display a Sub Menu Use the arrow keys to move the cursor to the sub menu you want. Then press <Enter>. A “➢” pointer marks all sub menus. ECM-MTL User’s Manual 53... -
Page 54: Getting Help
BIOS Vendor and your systems manufacturer to provide the absolute maximum performance and reliability. Even a seemingly small change to the chipset setup has the potential for causing you to use the override. 54 ECM-MTL User’s Manual... -
Page 55: Bios Setup
<Enter> to accept and enter the sub-menu. 4.6.1 Main Menu This section allows you to record some basic hardware configurations in your computer and set the system clock. ECM-MTL User’s Manual 55... -
Page 56: System Language
Visit the Avalue website (www.avalue.com) to download the latest product and BIOS information. 4.6.2 Advanced Menu This section allows you to configure your CPU and other system devices for basic operation through the following sub-menus. 56 ECM-MTL User’s Manual... -
Page 57: Connectivity Configuration
Auto Detection[Default] [Disable Integrated] disables Integrated Solution. NOTE: When CNVi is present, the GPIO pins that are used for radio. 4.6.2.2 CPU Configuration Use the CPU configuration menu to view detailed CPU specification and configure the CPU. ECM-MTL User’s Manual 57... -
Page 58: Efficient-Core Information
All[Default] Number of E-cores to enable in each processor package. Note: Number of Cores and E-cores are Active Efficient-cores looked at together. When both are {0,0}, Pcode will enable all cores. 4.6.2.2.1 Efficient-core Information 58 ECM-MTL User’s Manual... -
Page 59: Performance-Core Information
User’s Manual 4.6.2.2.2 Performance-core Information 4.6.2.3 Power & Performance ECM-MTL User’s Manual 59... -
Page 60: Cpu - Power Management Control
Intel® Speed Shift Enabled[Default], support. Enabling will expose the CPPC v2 interface to Technology Disabled allow for hardware controlled P-states. Enabled[Default], Turbo Mode Enable/Disable processor Turbo Mode. Disabled Enabled[Default], C States Enable/Disable CPU Power Management. Disabled 60 ECM-MTL User’s Manual... -
Page 61: System Agent (Sa) Configuration
User’s Manual 4.6.2.3.1.1 View/Configure Turbo Options 4.6.2.4 System Agent (SA) Configuration ECM-MTL User’s Manual 61... -
Page 62: Memory Configuration
Graphis Device connected otherwise external Auto[Default], Primary Display Graphics Device detected on first PCIe port will be IGFX Primary Display or Select IFGX for IGD to be Primary Display Or Select HG for Hybrid Gfx. 62 ECM-MTL User’s Manual... -
Page 63: Pcie Configuration
PCI Express Root Port PXPA2 Control the PCI Express Root Port. Disabled Disabled[Default], Set the ASPM Level: Force L0s – Force all links to L0s State AUTO – BIOS auto ASPM configure DISABLE – Disables ASPM. L0sL1 Auto ECM-MTL User’s Manual 63... -
Page 64: Pci Express Root Port Pxpa3(Lan1-I226)
ASPM configure DISABLE – Disables ASPM. L0sL1 Auto Disabled L1 Substates L1.1 PCI Express L1 Substates settings. L1.1 & L1.2[Default] Disabled[Default], Enable/Disable Precision Time Enabled Measurement. Auto[Default] Gen1 PCIe Speed Gen2 Configure PCIe Speed. Gen3 Gen4 64 ECM-MTL User’s Manual... -
Page 65: Pci Express Root Port Pxpa4(Lan2-I226)
ASPM configure DISABLE – Disables ASPM. L0sL1 Auto Disabled L1 Substates L1.1 PCI Express L1 Substates settings. L1.1 & L1.2[Default] Disabled[Default], Enable/Disable Precision Time Enabled Measurement. Auto[Default] Gen1 PCIe Speed Gen2 Configure PCIe Speed. Gen3 Gen4 ECM-MTL User’s Manual 65... -
Page 66: Pci Express Root Port Pxpb(M.2 Keye)
L0s State AUTO – BIOS auto ASPM configure DISABLE – Disables ASPM. L0sL1 Auto Disabled L1 Substates L1.1 PCI Express L1 Substates settings. L1.1 & L1.2[Default] Auto[Default] Gen1 PCIe Speed Gen2 Configure PCIe Speed. Gen3 Gen4 66 ECM-MTL User’s Manual... -
Page 67: Pci Express Root Port Pxpc(M.2 Keym)
L0s State AUTO – BIOS auto ASPM configure DISABLE – Disables ASPM. L0sL1 Auto Disabled L1 Substates L1.1 PCI Express L1 Substates settings. L1.1 & L1.2[Default] Auto[Default] Gen1 PCIe Speed Gen2 Configure PCIe Speed. Gen3 Gen4 ECM-MTL User’s Manual 67... -
Page 68: Pch-Io Configuration
ECM-MTL User’s Manual 4.6.2.6 PCH-IO Configuration 4.6.2.6.1 SATA Configuration Item Options Description Enabled[Default] SATA Controller(s) Enable/Disable SATA Device. Disabled, Enabled[Default] Port 0 Enable or Disable SATA Port. Disabled Enabled[Default] Port 1 Enable or Disable SATA Port. Disabled 68 ECM-MTL User’s Manual... -
Page 69: Hd Audio Configuration
User’s Manual 4.6.2.6.2 HD Audio Configuration Item Option Description Control Detection of the HD-Audio device. Disable = HDA Disabled HD Audio will be unconditionally disabled Enabled = HDA will be Enabled[Default] unconditionally enabled. 4.6.2.7 PCH-FW Configuration ECM-MTL User’s Manual 69... -
Page 70: Firmware Update Configuration
TPM Device Selection Warning! PTT/dTPM will be disabled and all data saved on it will be lost. 4.6.2.7.1 Firmware Update Configuration Item Option Description Disabled[Default], ME FW Image Re-Flash Enable/Disable Me FW Image Re-Flash function. Enabled 70 ECM-MTL User’s Manual... -
Page 71: Trusted Computing
Enable[Default] and INT1A interface will not be available. 4.6.2.9 APCI Settings Item Options Description Enables or Disables System ability to Disabled Hibernate (OS/S4 Sleep State). This Enable Hibernation Enabled[Default], option may not be effective with some ECM-MTL User’s Manual 71... -
Page 72: Board & Panel Configuration
Select Panel(eDP/LVDS) back light Frequency PWM Frequency. traditional S5 Power Off mode(EU 2013/617). Off Power Off mode(EU 2013/617) Off mode with WOLan1[Default] mode with WOLan : Wakeup from Off mode w/o WOL(ErP) Lan1/PWR button. Off mode w/o 72 ECM-MTL User’s Manual... -
Page 73: Show Dmi Info
Enable/Disabled USB Standby USB Standby Power Enabled[Default] Power during S4/S5. Disabled[Default] Enable/Disabled M.2 KeyB 5G M.2 KeyB 5G Workaround Enabled Card Workaround. Low[Default] Set M.2 KeyB Pin38(DEVSLP) as M.2 KeyB P38 Setting High Low/High. 4.6.2.10.1 SHOW DMI INFO ECM-MTL User’s Manual 73... -
Page 74: It5782 Super Io Configuration
Serial Port 2 Configuration Set Parameters of Serial Port 2 (COMB). Serial Port 3 Configuration Set Parameters of Serial Port 3 (COMC). Serial Port 4 Configuration Set Parameters of Serial Port 4 (COMD). 4.6.2.11.1 Serial Port 1 Configuration 74 ECM-MTL User’s Manual... -
Page 75: Serial Port 2 Configuration
Change the Serial Port as RS232/422/485. UART 485 Auto[Default] Non INT+EXT R INT_EXT R mode EXT R Enable switches for internal and external resistors. INT R INT+EXT R Low[Default] Low:RS232/422/485 = 250kbps. High:RS232 = Slew Rate High 3Mbps, RS422/485 = 20Mbps. ECM-MTL User’s Manual 75... -
Page 76: Serial Port 3 Configuration
4.6.2.11.3 Serial Port 3 Configuration Item Option Description Enabled[Default], Serial Port Enable or Disable Serial Port (COM). Disabled 4.6.2.11.4 Serial Port 4 Configuration Item Option Description Enabled[Default], Serial Port Enable or Disable Serial Port (COM). Disabled 76 ECM-MTL User’s Manual... -
Page 77: Ec 5782 Hw Monitor
Enable or disable System wake on alarm event. Select Disabled[Default], Fixed Time, system will wake on the hr::min::sec specified. Wake system from S5 Fixed Time Select Dynamic Time, System will wake on the current time Dynamic Time + Increase minute(s). ECM-MTL User’s Manual 77... -
Page 78: Serial Port Console Redirection
Options Description Disabled[Default], Console Redirection Console Redirection Enable or Disable. Enabled Disabled[Default], Console Redirection EMS Console Redirection Enable or Disable. Enabled 4.6.2.15 USB Configuration The USB Configuration menu helps read USB information and configures USB settings. 78 ECM-MTL User’s Manual... -
Page 79: Network Stack Configuration
‘Auto’ uses default value: for a Root port it is Device power-up delay Manual 100ms, for a Hub port the delay is taken form Hub descriptor. 4.6.2.16 Network Stack Configuration Item Options Description Enabled Network Stack Enable/Disable UEFI Network Stack. Disabled[Default] ECM-MTL User’s Manual 79... -
Page 80: Nvme Configuration
ECM-MTL User’s Manual 4.6.2.17 NVMe Configuration 4.6.3 Security ⚫ Administrator Password Set setup Administrator Password ⚫ User Password Set User Password 80 ECM-MTL User’s Manual... -
Page 81: Secure Boot
User’s Manual 4.6.3.1 Secure Boot ECM-MTL User’s Manual 81... -
Page 82: Key Management
Custom mode Secure Boot Variables can be configured Custom[Default] without authentication. 4.6.3.1.1 Key Management Item Option Description Disabled Install factory default Secure Boot keys after the Factory Key Provision Enabled[Default] platform reset and while the System is in Setup mode. 82 ECM-MTL User’s Manual... -
Page 83: Boot
Setup Prompt Timeout 1~ 65535 key. 65535(0xFFFF) means indefinite waiting. On[Default] Bootup NumLock State Select the keyboard NumLock state Disabled[Default] Quiet Boot Enables or disables Quiet Boot option Enabled Boot Option #1/2 Set the system boot order. ECM-MTL User’s Manual 83... -
Page 84: Save And Exit
Reset the system after saving the changes. 4.6.5.2 Discard Changes and Reset Any changes made to BIOS settings during this session of the BIOS setup program are discarded. The setup program then exits and reboots the controller. 84 ECM-MTL User’s Manual... -
Page 85: Restore Defaults
BIOS setting. 4.6.5.4 Launch EFI Shell from filesystem device Attempts to Launch EFI Shell application (Shellx64.efi) from one of the available filesystem devices. 4.6.6 MEBx ⚫ Intel® ME Password MEBx Login ECM-MTL User’s Manual 85... -
Page 86: Mechanical Drawing
ECM-MTL User’s Manual 5. Mechanical Drawing 86 ECM-MTL User’s Manual... - Page 87 User’s Manual Unit: mm ECM-MTL User’s Manual 87...
- Page 88 ECM-MTL User’s Manual User may find the Graphene sheet in package, if need to apply on DDR5 SO-DIMM: 88 ECM-MTL User’s Manual...
-
Page 89: Maintenance & Troubleshooting
System Maintenance Introduction If the components of the product fail they must be replaced. Please contact the system reseller or vendor to purchase the replacement parts. Please follow the safety precautions outlined in the sections that follow ECM-MTL User’s Manual 89... -
Page 90: General Safety Precautions
This equipment is not suitable for use in locations where children are likely to be present. DO NOT: ⚫ Drop the device. ⚫ In a site where the ambient temperature exceeds the rated temperature. 90 ECM-MTL User’s Manual... -
Page 91: Anti - Static Precautions
This reduces the possibility of ESD damage. ⚫ Only handle the edges of the electrical component. When handling the electrical component, hold the electrical component by its edges. Please ensure the following safety precautions are adhered to at all times. ECM-MTL User’s Manual 91... -
Page 92: Maintenance And Cleaning
Never drop any objects or liquids through the openings of the device. ⚫ Be cautious of any possible allergic reactions to solvents or chemicals used when cleaning the device. ⚫ Avoid eating, drinking and smoking within vicinity of the device. 92 ECM-MTL User’s Manual... -
Page 93: Basic Troubleshooting
No Console Input Devices are found Flash update is failed Typically for development use. The beep code is generated when platform cannot be reset because reset protocol is not available. Platform PCI resource requirements cannot be met ECM-MTL User’s Manual 93...
