- Page 1 EBM-APL Intel® Pentium®/Celeron®/Atom™ SoC BGA Processor 5.25” Mini Module User’s Manual Ed – 17 April 2018 Part No. E2047582903R...
- Page 2 Disclaimer Avalue Technology Inc. reserves the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance. Avalue Technology assumes no responsibility or liability for the...
- Page 3 Applications that are described in this manual are for illustration purposes only. Avalue Technology Inc. makes no representation or warranty that such application will be suitable for the specified use without further testing or modification.
- Page 4 A product returned without proof of the purchase date is not eligible for warranty service. Write the RMA number visibly on the outside of the package and ship it prepaid to your dealer. 4 EBM-APL User’s Manual...
-
Page 5: Table Of Contents
Signal Description – Audio connector (JAUDIO1) ..............28 2.3.19.1 2.3.20 AMPLIFIER_R (JAMP_R1) ......................29 2.3.21 AMPLIFIER_L (AMP_L1) ......................29 2.3.22 LPC connector (JLPC1) ......................30 2.3.23 BIOS SPI connector (BIOS_SPI1) ..................... 30 2.3.24 EC Debug connector (JEC_ROM1) ................... 31 EBM-APL User’s Manual... - Page 6 Security Configuration ......................52 3.6.3 Chipset............................53 3.6.3.1 North Bridge ......................... 53 3.6.3.2 South Bridge ........................54 3.6.3.3 Uncore Configuration ......................54 3.6.3.4 South Cluster Configuration ....................56 3.6.4 Security ............................63 3.6.4.1 Secure Boot ......................... 64 6 EBM-APL User’s Manual...
- Page 7 Install Chipset Driver ....................69 Install Serial IO Driver ..................... 70 Install TXE Driver ....................71 Install VGA Driver ....................72 Install Audio Driver (For Realtek ALC892) .............. 73 Install Ethernet Driver ....................74 5. Mechanical Drawing ....................75 EBM-APL User’s Manual...
-
Page 8: Getting Started
1.2 Packing List Before you begin installing your single board, please make sure that the following materials have been shipped: 1 x EBM-APL Intel® Pentium®/Celeron®/Atom™ SoC Processor 5.25” Mini Module 1 x DVD-ROM or CD-ROM contains the followings: ... -
Page 9: Document Amendment History
1.3 Document Amendment History Revision Date Comment November 2016 Avalue Initial Release February 2017 Avalue Update Setting Jumpers & Connectors March 2017 Avalue Add JLVDS1 and JBKL1 matching connector April 2018 Avalue Update Jumper and Connector List EBM-APL User’s Manual... -
Page 10: Manual Objectives
We strongly recommend that you study this manual carefully before attempting to set up EBM-APL series or change the standard configurations. Whilst all the necessary information is available in this manual we would recommend that unless you are confident, you contact your supplier for guidance. -
Page 11: System Specifications
3. 1 x 1 x 3 pin header w/2.0mm pitch(DC/PWM)-- 1pin for PWM, 3pin for DC *1 x 6pin DIP Switch for COM1 & COM2(RS232/422/485 selection), AT/ATX, Touch on/off *1 x 2 x 5 pin wafer w/2.0mm pitch for Front Panel Display EBM-APL User’s Manual 11... - Page 12 4 x USB3.0 RJ-45 connectors for two GbE ports HDMI 1 x HDMI (HDMI type A connector) 1 x dual deck LED: Green indicator: power-on Yellow indicator: HDD active Others 1 x Reset button Mechanical & Environmental 12 EBM-APL User’s Manual...
- Page 13 (Please consult product engineers for the production feasibility if the size is larger Humidity than 410 x 360mm or smaller than 80 x 70mm) Size (L x W) 8" x 5.75" (203mm x 146mm) Weight 0.55lb (0.25kg) Note: Specifications are subject to change without notice. EBM-APL User’s Manual 13...
-
Page 14: Architecture Overview-Block Diagram
EBM-APL User’s Manual 1.6 Architecture Overview—Block Diagram The following block diagram shows the architecture and main components of EBM-APL. 14 EBM-APL User’s Manual... -
Page 15: Hardware Configuration
User’s Manual 2. Hardware Configuration EBM-APL User’s Manual 15... -
Page 16: Product Overview
EBM-APL User’s Manual 2.1 Product Overview 16 EBM-APL User’s Manual... -
Page 17: Jumper And Connector List
Serial port 1/2 – RS232/ 422/ 485 JCOM_SEL1/2 4 x 3 header, pitch 2.00mm mode select Multi-function select DIP switch 6pin Connectors Label Function Note CPU fan connector 4 x 1 wafer, pitch 2.54mm CPU_FAN1 SODIMM1 204-pin DDR3L SODIMM socket EBM-APL User’s Manual 17... - Page 18 4 x 2 header, pitch 2.00 mm JEDP1 eDP Panel connector 10 x 2 wafer, pitch 1.25 mm NGFF1 M.2 B key connector LCD Backlight VR/Push Up/Push JVR_BTN1 3 x 2 wafer, pitch 2.00 mm Down header 18 EBM-APL User’s Manual...
-
Page 19: Setting Jumpers & Connectors
Clear CMOS (JBAT1) Protect* Clear CMOS * Default 2.3.2 Multi-function select (SW1) In Serial Port 1 mode RS-232 RS-422 RS-485 In Serial Port 2 mode RS-232 RS-422 RS-485 AT SEL ATX SEL Touch off Touch on EBM-APL User’s Manual 19... -
Page 20: Serial Port 1/2 Pin9 Signal Select (Jri1/Jri2)
EBM-APL User’s Manual 2.3.3 Serial port 1/2 pin9 signal select (JRI1/JRI2) Ring* +12V JRI1 JRI2 * Default 2.3.4 LCD brightness DC/PWM mode select (JBKL_SEL1) PWM Mode* DC Mode * Default 20 EBM-APL User’s Manual... -
Page 21: Serial Port 1/2 - Rs232/ 422/ 485 Mode Select (Jcom_Sel1/2)
Serial port 1/2 – RS232/ 422/ 485 mode select (JCOM_SEL1/2) 2.3.5 RS-232* RS422/485 JCOM_SEL1 JCOM_SEL2 * Default 2.3.6 Serial port 3/4/5/6 connector (JCOM3/JCOM4/JCOM5/JCOM6) Signal PIN PIN Signal JCOM6 COM_RI# JCOM5 JCOM4 COM_CTS# COM_RTS# JCOM3 COM_DSR# COM_DTR# COM_TXD COM_RXD COM_DCD# EBM-APL User’s Manual 21... -
Page 22: Lcd Backlight Vr/Push Up/Push Down Header (Jvr_Btn1)
LCD Inverter connector (JBKL1) Signal +12V BKLEN VBRIGHT Note: For inverters with adjustable Backlight function, it is possible to control the LCD brightness through the VR signal controlled by JVR_BTN1. Please see the JVR_BTN1 section for detailed circuitry information. 22 EBM-APL User’s Manual... -
Page 23: Cpu Fan Connector (Cpu_Fan1)
CPU fan connector (CPU_FAN1) Signal +12V EC_TACH0 FAN_PWM0 2.3.10 General purpose I/O connector (JDIO1) Signal PIN PIN Signal SMB_SDA_S0 SMB_SCL_S0 DIO_GP27 DIO_GP17 DIO_GP26 DIO_GP16 DIO_GP25 DIO_GP15 DIO_GP24 DIO_GP14 DIO_GP23 DIO_GP13 DIO_GP22 DIO_GP12 DIO_GP21 DIO_GP11 DIO_GP20 DIO_GP10 EBM-APL User’s Manual 23... -
Page 24: Touch Panel Connector (Jtouch1)
EBM-APL User’s Manual 2.3.11 Touch panel connector (JTOUCH1) Signal THX+ THX- THPROBE_R THY+ THY- 2.3.12 SATA Power connector (SATA_PWR1) Signal SATA_PWR 24 EBM-APL User’s Manual... -
Page 25: Edp Panel Connector (Jedp1)
User’s Manual 2.3.13 eDP Panel connector (JEDP1) Signal PIN PIN Signal +V_EDP +V_EDP EDP_Panel_TXP2 17 EDP_Panel_HPD EDP_Panel_TXN2 15 14 EDP_Panel_AUXP EDP_Panel_TXP1 11 12 EDP_Panel_AUXN EDP_Panel_TXN1 EDP_Panel_TXP0 EDP_Panel_TXP3 EDP_Panel_TXN0 EDP_Panel_TXN3 2.3.14 Power connector (PWR1) Signal Signal +VIN +VIN EBM-APL User’s Manual 25... -
Page 26: Lvds Connector (Jlvds1)
LVDS_DATA1_N 11 12 LVDS_DATA0_N LVDS_DATA3_P 15 16 LVDS_DATA2_P LVDS_DATA3_N 17 18 LVDS_DATA2_N LVDS_DATA5_P 21 22 LVDS_DATA4_P LVDS_DATA5_N 23 24 LVDS_DATA4_N LVDS_DATA7_P 27 28 LVDS_DATA6_P LVDS_DATA7_N 29 30 LVDS_DATA6_N LVDS_CLK2_P LVDS_CLK1_P LVDS_ CLK2_N LVDS_ CLK1_N +12V +12V 26 EBM-APL User’s Manual... -
Page 27: Usb Connector (Jusb1)
User’s Manual 2.3.16 USB connector (JUSB1) Signal PIN PIN Signal USB_HUB_Z_DP_2 USB_HUB_Z_DP_1 USB_HUB_Z_DN_2 USB_HUB_Z_DN_1 +5VSB +5VSB 2.3.17 USB connector (JUSB2) Signal PIN PIN Signal USB_HUB_Z_DP_4 USB_HUB_Z_DP_3 USB_HUB_Z_DN_4 USB_HUB_Z_DN_3 +5VSB +5VSB EBM-APL User’s Manual 27... -
Page 28: Battery Connector (Bt1)
LINE1-JD FRONT-JD MIC1-L-IN MIC1-R-IN LINE1-L-IN LINE1-R-IN HD_AGND HD_AGND FRONT-L-OUT FRONT-R-OUT 2.3.19.1 Signal Description – Audio connector (JAUDIO1) Signal Signal Description LINE1_JD AUDIO IN (LINE_RIN/LIN)sense pin FRONT_JD AUDIO Out(ROUT/LOUT) sense pin MIC1_JD MIC IN (MIC_RIN/LIN) sense pin 28 EBM-APL User’s Manual... -
Page 29: Amplifier_R (Jamp_R1)
User’s Manual 2.3.20 AMPLIFIER_R (JAMP_R1) Signal SPK_R- SPK_R+ 2.3.21 AMPLIFIER_L (AMP_L1) Signal SPK_L- SPK_L+ EBM-APL User’s Manual 29... -
Page 30: Lpc Connector (Jlpc1)
EBM-APL User’s Manual 2.3.22 LPC connector (JLPC1) Signal PIN PIN Signal LPC_AD0 +3.3V LPC_AD1 PLT_RST_BUF# LPC_AD2 LPC_FRAME# LPC_AD3 LPC_PORT80_CLK LPC_SERIRQ 2.3.23 BIOS SPI connector (BIOS_SPI1) Signal PIN PIN Signal SPI_HOLD# SPI_MOSI SPI_MISO SPI_CLK SPI_CS#0 +1.8VSB 30 EBM-APL User’s Manual... -
Page 31: Ec Debug Connector (Jec_Rom1)
User’s Manual 2.3.24 EC Debug connector (JEC_ROM1) Signal EC_SMCLK_DEBUG EC_SMDAT_DEBUG 2.3.25 Miscellaneous setting connector (JFP1) Signal PIN PIN Signal 10 PWR_BTN_IN_EC# +5VSB LAN2_ACT#_LED +5VSB LAN1_ACT#_LED HDD_LED# +5VSB PWR_LED- EBM-APL User’s Manual 31... -
Page 32: Bios Setup
EBM-APL User’s Manual 3.BIOS Setup 32 EBM-APL User’s Manual... -
Page 33: Introduction
If you do not press the keys at the correct time and the system does not boot, an error message will be displayed and you will again be asked to. Press F1 to Continue, DEL to enter SETUP EBM-APL User’s Manual 33... -
Page 34: Using Setup
Note: Some of the navigation keys differ from one screen to another. To Display a Sub Menu Use the arrow keys to move the cursor to the sub menu you want. Then press <Enter>. A “” pointer marks all sub menus. 34 EBM-APL User’s Manual... -
Page 35: Getting Help
BIOS Vendor and your systems manufacturer to provide the absolute maximum performance and reliability. Even a seemingly small change to the chipset setup has the potential for causing you to use the override. EBM-APL User’s Manual 35... -
Page 36: Bios Setup
<Enter> to accept and enter the sub-menu. 3.6.1 Main Menu This section allows you to record some basic hardware configurations in your computer and set the system clock. 36 EBM-APL User’s Manual... -
Page 37: System Language
Visit the Avalue website (www.avalue.com.tw) to download the latest product and BIOS information. 3.6.2 Advanced Menu This section allows you to configure your CPU and other system devices for basic operation through the following sub-menus. EBM-APL User’s Manual 37... -
Page 38: Trusted Computing
Enable[Default] and INT1A interface will not be available. 1.2[Default], Select to Tell O.S. to support PPI Spec Version 1.2 or Physical Presence Spec Version 1.3. Note some HCK tests might not support 1.3. 3.6.2.2 APCI Settings 38 EBM-APL User’s Manual... - Page 39 Watch Dog Select WatchDog. 1 min 2 min 10 min 30 min Disabled Enabled/Disabled USB Standby Power USB Standby Power Setting Enabled[Default], during S3/S4/S5. Disabled Wake Up by Ring Wake Up by Ring from S3/S4/S5. Enabled[Default], EBM-APL User’s Manual 39...
-
Page 40: It8528 Super Io Configuration
Set Parameters of Serial Port 3 (COMC). Serial Port 4 Configuration Set Parameters of Serial Port 4 (COMD). Serial Port 5 Configuration Set Parameters of Serial Port 5 (COME). Serial Port 6 Configuration Set Parameters of Serial Port 6 (COMF). 40 EBM-APL User’s Manual... -
Page 41: Serial Port 1 Configuration
User’s Manual 3.6.2.3.1 Serial Port 1 Configuration Item Option Description Disabled Serial Port Enable or Disable Serial Port (COM). Enabled[Default], EBM-APL User’s Manual 41... -
Page 42: Serial Port 2 Configuration
EBM-APL User’s Manual 3.6.2.3.2 Serial Port 2 Configuration Item Option Description Disabled Serial Port Enable or Disable Serial Port (COM). Enabled[Default], 3.6.2.3.3 Serial Port 3 Configuration 42 EBM-APL User’s Manual... -
Page 43: Serial Port 4 Configuration
User’s Manual Item Option Description Disabled Serial Port Enable or Disable Serial Port (COM). Enabled[Default], 3.6.2.3.4 Serial Port 4 Configuration Item Option Description Disabled Serial Port Enable or Disable Serial Port (COM). Enabled[Default], EBM-APL User’s Manual 43... -
Page 44: Serial Port 5 Configuration
EBM-APL User’s Manual 3.6.2.3.5 Serial Port 5 Configuration Item Option Description Disabled Serial Port Enable or Disable Serial Port (COM). Enabled[Default], 3.6.2.3.6 Serial Port 6 Configuration 44 EBM-APL User’s Manual... -
Page 45: H/W Monitor
User’s Manual Item Option Description Disabled Serial Port Enable or Disable Serial Port (COM). Enabled[Default], 3.6.2.4 H/W Monitor Item Options Description Disabled[Default] Smart Fan Function Enables or Disables Smart Fan. Enabled EBM-APL User’s Manual 45... -
Page 46: S5 Rtc Wake Settings
Disabled[Default], Fixed Time, system will wake on the hr::min::sec Wake system from S5 Fixed Time specified. Select Dynamic Time, System will wake on Dynamic Time the current time + Increase minute(s). 3.6.2.6 Serial Port Console Redirection 46 EBM-APL User’s Manual... -
Page 47: Legacy Console Redirection Settings
Legacy Serial Redirection Port Enabled Legacy OS and Legacy OPROM Messages. 3.6.2.6.1 Legacy Console Redirection Settings Item Option Description Select a COM port to display redirection of Legacy Serial Redirection Port COM0[Default], Legacy OS and Legacy OPROM Messages. EBM-APL User’s Manual 47... -
Page 48: Cpu Configuration
PROCHOT# to throttle the processor. Disabled, Thermal Monitor Enable/Disable Thermal Monitor. Enabled[Default] Disabled, Monitor Mwait Enabled Enable/Disable Monitor Mwait. Auto[Default] HW_ALL[Default] P-STATE Coordination SW_ALL Change P-STATE Coordination type. SW_ANY Disabled[Default], Enable/Disable Digital Thermal Sensor. Enabled 48 EBM-APL User’s Manual... -
Page 49: Cpu Power Management Configuration
This option controls the Max Core C State that Max Core C State Core C7 cores will support. Core C6 Core C1 Unlimited Disabled, C-State Auto Demotion Configure C-State Auto Demotion. C1[Default] Disabled, C-State Un-demotion Configure C-State Un-demotion. C1[Default] EBM-APL User’s Manual 49... -
Page 50: Network Stack Configuration
EBM-APL User’s Manual 3.6.2.8 Network Stack Configuration Item Options Description Enabled Network Stack Enable/Disable UEFI Network Stack. Disabled[Default] 3.6.2.9 CSM Configuration Item Options Description Disabled[Default] CSM Support Enable/Disable CSM Support. Enabled 50 EBM-APL User’s Manual... -
Page 51: Nvme Configuration
DISABLE option will keep USB Auto devices available only for EFI applications. This is a workaround for OSew without XHCI Enabled[Default] XHCI Hand-off hand-off support. The XHCI ownership change Disabled should be claimed by XHCI driver. EBM-APL User’s Manual 51... -
Page 52: Security Configuration
Manual 100ms, for a Hub port the delay is taken form Hub descriptor. 3.6.2.12 Security Configuration Item Options Description Enabled, TXE HMRFPO TXE HMRFPO. Disabled[Default] Enabled[Default] TXE EOP Message Send EOP Message Before Enter OS. Disabled 52 EBM-APL User’s Manual... -
Page 53: Chipset
User’s Manual 3.6.3 Chipset 3.6.3.1 North Bridge Item Option Description 2 GB[Default] 2.25 GB Max TOLUD Maximum Value of TOLUD. 2.5 GB 2.75 GB EBM-APL User’s Manual 53... -
Page 54: South Bridge
EBM-APL User’s Manual 3.6.3.2 South Bridge Item Option Description Quiet Serial IRQ Moed Configure Serial IRQ Mode. Continuous[Default] Windows[Default] OS Selection Android Select the target OS. Intel Linux 3.6.3.3 Uncore Configuration 54 EBM-APL User’s Manual... - Page 55 BR Button Brightness Control Method 2.Brightness Button 3.Variable Resistor 4.OS Driver. OS driver LVDS Back Light PWM Select LVDS back light PWM duty. 100%[Default] 200[Default] LVDS Back Light PWM Select LVDS back light PWM Frequency. Frequency EBM-APL User’s Manual 55...
-
Page 56: South Cluster Configuration
EBM-APL User’s Manual 3.6.3.4 South Cluster Configuration 3.6.3.4.1 HD-Audio Configuration Item Option Description Disable HD-Audio Support Enable/Disable HD-Audio Support. Enable[Default], 20db AMP Gain Setting 26db[Default], Select AMP Gain db. 32db 56 EBM-APL User’s Manual... - Page 57 User’s Manual 36db 3.6.3.4.2 PCI Express Configuration Item Option Description Disabled[Default] Compliance Mode Compliance Mode Enable/Disable. Enabled, 3.6.3.4.2.1 PCI Express Root Port 3(i210/211) EBM-APL User’s Manual 57...
- Page 58 To disable unused root port automatically for PCI Express Root Port 4(i210/211) Enable the most optimum power savings. Enable: Auto[Default] Enable PCIe root port Disable: Disable PCIe root port. Disable[Default] PCI Express Active State Power ASPM Management settings. 58 EBM-APL User’s Manual...
- Page 59 Enable PCIe root port Disable: Disable PCIe root port. Disable[Default] PCI Express Active State Power ASPM Management settings. L0sL1 Auto Disabled[Default] L1.1 L1 Substates PCI Express L1 Substates settings. L1.2 L1.1 & L1.2 Auto[Default] PCIe Speed Gen1 Configure PCIe Speed. Gen2 EBM-APL User’s Manual 59...
- Page 60 Enable PCIe root port Disable: Disable PCIe root port. Disable[Default] PCI Express Active State Power ASPM Management settings. L0sL1 Auto Disabled[Default] L1.1 L1 Substates PCI Express L1 Substates settings. L1.2 L1.1 & L1.2 Auto[Default] PCIe Speed Gen1 Configure PCIe Speed. Gen2 60 EBM-APL User’s Manual...
- Page 61 Identify the SATA port is connected to Solid SATA Device Type Solid State Drive State Drive or Hard Disk Drive. Disabled[Default] Enable/Disable SATA Port 0/1 DevS1p. SATA Port 0/1 DevS1P Enabled Board rework for LP needed before enable. EBM-APL User’s Manual 61...
- Page 62 Disable[Default] support. Once disabled, XHCI controller would be function disabled, none of the USB devices Enable[Default] xHCI Mode are detectable and usable during boot and in Disable OS. Do not disable it unless for debug purpose. 62 EBM-APL User’s Manual...
-
Page 63: Security
User’s Manual 3.6.4 Security Setup Administrator Password Set setup Administrator Password User Password Set User Password EBM-APL User’s Manual 63... -
Page 64: Secure Boot
EBM-APL User’s Manual 3.6.4.1 Secure Boot Item Option Description Secure Boot activated when Platform Key(PK) Disabled Attempt Secure Boot is enrolled, System mode is User/Deployed, Enabled[Default] and CSM function is disabled. 64 EBM-APL User’s Manual... -
Page 65: Boot
Setup Prompt Timeout 1~ 65535 activation key. 65535(0xFFFF) means indefinite waiting. On[Default] Bootup NumLock State Select the Keyboard NumLock state Disabled[Default] Quiet Boot Enables or disables Quiet Boot option Enabled Boot Option #1 Set the system boot order. EBM-APL User’s Manual 65... -
Page 66: Save And Exit
3.6.6 Save and exit 3.6.6.1 Save Changes and Reset Reset the system after saving the changes. 3.6.6.2 Discard Changes and Reset Any changes made to BIOS settings during this session of the BIOS setup program are 66 EBM-APL User’s Manual... -
Page 67: Restore Defaults
This option restores all BIOS settings to the factory default. This option is useful if the controller exhibits unpredictable behavior due to an incorrect or inappropriate BIOS setting. 3.6.6.4 Launch EFI Shell from filesystem device Attempts to Launch EFI Shell application (Shellx64.efi) from one of the available filesystem devices. EBM-APL User’s Manual 67... -
Page 68: Drivers Installation
EBM-APL User’s Manual 4. Drivers Installation Note: Installation procedures and screen shots in this section are for your reference and may not be exactly the same as shown on your screen. 68 EBM-APL User’s Manual... -
Page 69: Install Chipset Driver
Windows 10 operation system. If the warning message appears while the installation process, click Continue Step 3. Click Install to complete setup. to go on. Step1. Click Next. Step 2. Click Accept. EBM-APL User’s Manual 69... -
Page 70: Install Serial Io Driver
Step 3. Click Next to proceed setup. process, click Continue to go on. Step1. Click Next to start installation. Step 4. Click Next. Step 2. Click Next. Step 5. Click Finish to complete setup. 70 EBM-APL User’s Manual... -
Page 71: Install Txe Driver
If the warning message appears while the installation Step 3. Click Next to continue installation. process, click Continue to go on. Step 4. Click Finish to complete setup. Step1. Click Next to start installation. Step 2. Click Next. EBM-APL User’s Manual 71... -
Page 72: Install Vga Driver
Windows 10 operation system. Step 3. Click Next. Step 1. Click Next to continue installation. Step 4. Click Next. Step 5. Click Finish to complete setup. Step 2. Click Yes to accept license agreement. 72 EBM-APL User’s Manual... -
Page 73: Install Audio Driver (For Realtek Alc892)
/Driver_Audio/Realtek/ALC892/EBM-APL_Audio. Note: The installation procedures and screen shots in this section are based on Windows 10 operation system. Step 1. Click Next to continue setup. Step 2. Click Finish to complete the setup. EBM-APL User’s Manual 73... -
Page 74: Install Ethernet Driver
Note: The installation procedures and screen shots in this section are based on Windows 10 operation system. Step 3. Click Next. Step 1. Click Next. Step 4. Click Install to complete the setup. Step 2. Click Next to accept license agreement. 74 EBM-APL User’s Manual... -
Page 75: Mechanical Drawing
User’s Manual 5. Mechanical Drawing EBM-APL User’s Manual 75... - Page 76 EBM-APL User’s Manual Unit: mm 76 EBM-APL User’s Manual...
- Page 77 User’s Manual Unit: mm EBM-APL User’s Manual 77...
