Installation with DMX Bypass Controller
ArcSystem Pro D1, D1 HO, and D2 Series emergency drivers and ArcSystem multi-cell emergency
luminaires that are installed in a system with a DMX bypass controller can have their Maintained
and Sense inputs fed from an emergency lighting transfer switch (UL1008 ATS).
Note:
or ArcSystem ArcLamp Drivers.
DMX
Bypass
Controller
UL1008
ATS by others

Before You Begin Installation

Review the following sections before beginning your ArcSystem installation. ArcSystem products
should only be installed by a qualified installer or electrician.
Power Disconnect Device
Before installation, make sure you have a readily accessible input power disconnect device installed
ahead of your ArcSystem products.
WARNING:
power to the system before installation, maintenance, cleaning, or any other
system modification could result in serious injury or death.
AVERTISSEMENT :
de débrancher toutes les sources d'alimentation du système avant l'installation,
l'entretien, le nettoyage ou toute autre modification du système peut causer
des blessures graves ou la mort.
De-energize main feed to ArcSystem and follow appropriate Lockout/Tagout
procedures as mandated by NFPA 70E. It is important to note that electrical
equipment such as breaker panels can present an arc flash hazard if improperly
serviced. This is due to the high amounts of short-circuit current available on
the electrical supply to this equipment. Any work must comply with OSHA Safe
Working Practices.
WARNING:
device cannot be serviced or operated safely.
AVERTISSEMENT :
installés sans qu'un dispositif de déconnexion de l'alimentation ne soit
accessible.
D1 & D2 Series Drivers
The installation shown below is not approved for ArcSystem Pro D4 Series Drivers
DMX/Emergency Bypass DMX
Normal/Emergency Power
Normal/Emergency Power
RISK OF DEATH BY ELECTRIC SHOCK! Failure to disconnect all
RISQUE DE MORT PAR DÉCHARGE ÉLECTRIQUE! Négliger
Circuits that are installed without an accessible power disconnect
Il est imprudent d'utiliser ou de réparer les circuits
DMX In
ArcSystem Pro
multi-cell emergency
luminaire or
ArcSystem Pro
One-Cell luminaire
Sense
with D1, D1 HO, or
D2 series emergency
driver
Maintained
