ETC ArcSystem Pro D1 Series Installation Manual page 14

ETC Installation Guide
D1 & D2 Series Drivers
Power
Internal wire colors vary by model.
Factory Wire Colors
Model
North America
and Europe
North America black
North America white
Europe
Europe
Perform the following steps to wire power to the driver.
WARNING:
device cannot be serviced or operated safely.
AVERTISSEMENT :
installés sans qu'un dispositif de déconnexion de l'alimentation ne soit
accessible.
1. Make sure power is off at the main circuit breaker.
2. See Wire and Terminal Specifications on page 12
terminal torque ratings. Prepare the wires accordingly.
3. Loosen the three screw terminals for NEUTRAL (N), GROUND (
4. Insert the ground wire (typically green) into the GROUND (
5. Insert the neutral wire (typically white) into the NEUTRAL (N) terminal and tighten the screw.
6. Insert the line wire (typically black) into the LINE (L) terminal and tighten the screw.
7. Tug gently on the wires to ensure they are secure.
Luminaire Connection to Driver
ArcSystem Pro One-Cell luminaires connect to a driver using Molex receptacles labeled "LED Head"
for D1 and D2 Series Drivers. All D1 Series and D2 Series drivers have Molex receptacles for
ArcSystem Pro One-Cell luminaire connections.
Note:
D2 Series drivers is 15 m (49 ft, 3 in). Maximum supported wire length between a One-Cell
High Output luminaire and a D1 HO Series driver is 1 m (3 ft, 3 in).
1. Install the ceiling with the prepared mounting hole for the luminaire.
2. Run the luminaire cable through the previously installed screw-clamp conduit connector at one
of the driver knockouts.
3. Connect the luminaire cable to the driver output.
connect the four-pin luminaire cables to the Molex receptacles inside the driver. See
•
the Driver on the previous page
Support the luminaires. Do not let luminaires hang by their cables.
•
D1 & D2 Series Drivers
Color
green/yellow
brown
blue
Circuits that are installed without an accessible power disconnect
Il est imprudent d'utiliser ou de réparer les circuits
Maximum supported wire length between One-Cell luminaires and D1 Series and
Type
ground/earth
line/hot
neutral
live
neutral
for specification of wire, strip length, and
.
Page 14 of 25
), and LINE (L) connections.
) terminal and tighten the screw.
