ETC ArcSystem Pro D1 Series Installation Manual page 22

ETC Installation Guide
D1 & D2 Series Drivers
Parameter
DMX Start Address
DMX Personality
Identify Device
Minimum Level
Maximum Level
Curve
Curve Description
Output Response Time
Output Response Time
Down
Output Response Time
Description
Modulation Frequency
Modulation Frequency
Description
Restore Factory Defaults
Software Version Label
Bootloader Version Label
D1 & D2 Series Drivers
RDM PID Value
0x00F0 Range = 001 to 512
0x00E0 1 or 2
0 for stop identify, 1 for start
0x1000
identify
Minimum Level - Increasing: 0
to 255
0x0341
Minimum Level - Decreasing: 0
to 255
0x0342 0 to 255
0x0343 1, 2, or 3
0x0344
0x01 1000 ms/100 steps
0x0345
•
0x02 900 ms/90 steps
•
0x03 800 ms/80 steps
•
0x04 700 ms/70 steps
•
0x05 600 ms/60 steps
•
0x06 500 ms/50 steps
•
0x8030
0x07 400 ms/40 steps
•
0x08 300 ms/30 steps
•
0x09 250 ms/25 steps
•
0x0A 200 ms/20 steps
•
0x0B 100 ms/10 steps
•
0x0C 50 ms/5 steps
•
0x0D 0 ms/0 steps
•
0x0346
1 for 300 Hz
0x0347
•
2 for 600 Hz
•
3 for 1.2 kHz
•
4 for 19.2 kHz
•
0x0348
0x0090
0x00C0
0x00C2
Page 22 of 25
Notes
Default is 001.
Default is 2.This parameter doesn't affect D1 and
D2 Series Drivers.
Set to 1 causes output(s) and LEDs of the unit to
blink in a one second on, one second off pattern.
Default is 99%. The luminaire will not accept a
Minimum Level that is higher than the Maximum
Level.
Minimum Level - Increasing and Minimum Level -
Decreasing need to be set to the same value.
Default is 100%. The luminaire will not accept a
Maximum Level that is lower than the Minimum
Level.
Set to 1 is the Default Tungsten Curve (aka
•
D04A)
Set to 2 is Linear
•
Set to 3 is Square Law
•
Get returns an ASCII text string.
Default is 500ms/50 steps. This parameter controls
dimming up in level.
Default is 500 ms/50 steps. This parameter controls
dimming down in level. Set 0x00 to set the Output
Response Time Down to the same setting as Output
Response Time.
Get returns an ASCII text string.
Default is 300 Hz.
Get returns an ASCII text string.
Set resets the luminaire configuration to default
settings.
Get returns the current software version as an
ASCII text string.
Get returns the current bootloader version as an
ASCII text string.
ETC
