ETC Installation Guide
D1 & D2 Series Drivers
Note:
and has wiring that runs to the driver board in the back panel of the driver. Be careful when
handling. It may help to nest the back panel of the driver inside the cover as shown in
HO Driver on
Note:
to NEC 700.10(B).
Note:
Connect Sense Input
Connect the mains sense input to a normal branch circuit. For D1 Emergency Drivers, see
page 14
for factory wire colors.
1. Make sure power is off at the main circuit breaker.
2. Loosen the three screw terminals for NEUTRAL (N), GROUND (
3. Insert the ground wire (typically green) into the GROUND (
4. Insert the neutral wire (typically white) into the NEUTRAL (N) terminal and tighten the screw.
5. Connect the line wire (typically black) into the LINE (L) terminal and tighten the screw.
6. Tug gently on the wires to ensure they are secure.
Connect Maintained Input
Connect maintained input to a normal/emergency branch circuit with upstream UL 1008 automatic
transfer switch. For D1 Emergency Drivers, see
1. Loosen the three screw terminals for NEUTRAL (N), GROUND (
2. Insert the ground wire (typically green) into the GROUND (
3. Insert the neutral wire (typically white) into the NEUTRAL (N) terminal and tighten the screw.
4. Connect the line wire (typically black) into the LINE (L) terminal and tighten the screw.
5. Tug gently on the wires to ensure they are secure.
Complete Installation
Now that you have completed wiring the power to your emergency system driver, standard
installation procedures can be completed. Refer to the following sections once power wiring is
completed:
Luminaire Connection to Driver on page 14
•
DMX In and DMX Thru on page 15
•
Installing One-Cell Recessed Luminaires on page 10
•
Installing One-Cell Yoke-Mounted Luminaires on page 11
•
D1 & D2 Series Drivers
If you are installing a D1 High Output driver, the power supply is inside the cover
page 13.
Normal and emergency wiring cannot be contained in the same conduit according
Use suitable conduit where required by local or national code.
Power on page 14
Page 18 of 25
), and LINE (L) connections.
) terminal and tighten the screw.
for factory wire colors.
), and LINE (L) connections.
) terminal and tighten the screw.
D1
Power on
