ETC Installation Guide
D1 & D2 Series Drivers
Updating the Luminaire Firmware
When commissioning a system installation, check all ArcSystem drivers and multi-cell luminaires to
ensure that the latest firmware is present. If the firmware is not up to date, upgrade it following the
instructions below for your luminaire type.
Wireless ArcMesh Luminaires
Upgrade luminaire firmware using the ArcSystem Configuration Software. The fixture firmware file
and ArcSystem Configuration Software are available for free at etcconnect.com.
RDM Luminaires
Upgrade luminaire firmware using ETC Concert and ETC UpdaterAtor software before
commissioning is completed. For more information on UpdaterAtor, download the UpdaterAtor
Software Quick Guide for free at etcconnect.com.
Commissioning a Wireless ArcSystem
Initial programming of a wireless ArcSystem requires a USB commissioning tool (ARC-CT), and
existing hardware such as a laptop or desk top computer that is connected to ArcSystem. This
programming will be carried out by an ETC certified technician at the time of system commissioning
and training.
The following is a list of procedures included in the configuration process:
patching groups of luminaires to specific DMX channels
•
assigning minimum and maximum dimming levels per group
•
assigning power fail/recovery options per group
•

Maintenance

WARNING:
power to the system before installation, maintenance, cleaning, or any other
system modification could result in serious injury or death.
AVERTISSEMENT :
de débrancher toutes les sources d'alimentation du système avant l'installation,
l'entretien, le nettoyage ou toute autre modification du système peut causer
des blessures graves ou la mort.
De-energize main feed to ArcSystem and follow appropriate Lockout/Tagout
procedures as mandated by NFPA 70E. It is important to note that electrical
equipment such as breaker panels can present an arc flash hazard if improperly
serviced. This is due to the high amounts of short-circuit current available on
the electrical supply to this equipment. Any work must comply with OSHA Safe
Working Practices.
WARNING:
device cannot be serviced or operated safely.
AVERTISSEMENT :
installés sans qu'un dispositif de déconnexion de l'alimentation ne soit
accessible.
D1 & D2 Series Drivers
RISK OF DEATH BY ELECTRIC SHOCK! Failure to disconnect all
RISQUE DE MORT PAR DÉCHARGE ÉLECTRIQUE! Négliger
Circuits that are installed without an accessible power disconnect
Il est imprudent d'utiliser ou de réparer les circuits
