ETC Installation Guide
D1 & D2 Series Drivers
Note:
TX1, you must use the ArcSystem comissioning tool software to add DMX fixtures.
ArcMesh Specifications
Use up to 100 devices per TX1 transmitter.
•
Patch up to 64 ArcMesh channels to 512 DMX channels.
•
Use up to 16 TX1 transmitters per system.
•
There are no system range limitations for transmitting data
between luminaires because each luminaire has the ability to
act as a repeater (see Re-Broadcast Mode below). ArcSystem
is self-regulating and continues to reconfigure the
communication "mesh" to establish the most successful path
of communication transmission.
Re-Broadcast Mode
By default all ArcSystem luminaires are shipped with Re-
broadcast Mode turned off to reduce the amount of wireless
activity. In areas of poor wireless reception, re-broadcast
mode may be enabled on a luminaire-by-luminaire basis to
improve the overall signal level of the system.
CAUTION:
required, use this feature in as few
luminaires as possible to avoid unnecessary
traffic on the network and possible system
performance issues.
Emergency System Overview
ArcSystem drivers and luminaires can be purchased in UL924 listed variants. Each of the luminaires
can be configured to be UL924 listed when wired into an existing emergency response system. See
Emergency System One-Cell Installation on page 16
Install the luminaire and ArcSystem D1, D2, or D4 Series driver in a location that is accessible by
qualified personnel for testing of the emergency operation.
Note:
UL924 certification.
Note:
the specifier and installer in order to achieve the minimum FC levels of NFPA101.
Installation scenarios should be evaluated by the AHJ to confirm illuminance and
performance requirements of ANSI/NFPA 101 and the IBC.
Note:
installed with a maximum mounting height of 23.2 ft (7.07 m).
D1 & D2 Series Drivers
By default the TX1 DMX output is disabled. If you require DMX output from the
If re-broadcast mode is
Luminaires must be hard-wired to emergency certified drivers to be considered for
The number of designated emergency lamps and their height is the responsibility of
ArcSystem Pro One-Cell Micro luminaires in emergency installations must be
.
