4 Hardware description
4.1

Hardware features

The SPC58XCADPT176S mini module board has the following features:
• Connector for external power supplies input (5 V, 3.3 V, 1.25 V) used in stand-alone mode.
• Reset button with driver and led indicator
• Socket for device in eLQFP176 package with exposed pad down
• Debug ports:
– 12-pin SAMTEC connector for SIPI interface
– 14-pin header connector for JTAG port
– 12-pin header connector for LFAST interface
• 40 MHz crystal main oscillator with jumpers to optionally disconnect it
• 8 MHz oscillator with jumpers to optionally disconnect it
• Clock input through SMA connector to optionally disconnect it
• Jumper for boot configuration
• 2 X Samtec QSH series, 240 way connector to connect mini module to motherboard
4.2

Hardware dimension

The mini module has the following dimensions:
• PCB area: 127 mm X 114.3 mm
• Top components height: 19.4 mm max
• Bottom components height: 3.5 mm max
• PCB thickness: 1.6 mm
