5.6

Test points

The mini module has several test points. Below all test point description:
Test Point
TP3 JCOMP_RxDATA_N test point
TP4 TCK test point
TP5 TMS_TxDATA_P test point
TP6 TDI_TxDATA_N test point
TP7 TDO_RxDATA_P test point
TP9 SIPI_RXN test point
TP11 SIPI_TXN test point
TP13 SIPI_RXP test point
TP15 SIPI_TXP test point
TP24 J16A, QSH connector, pin19 (PA14) test point
TP22 J16A, QSH connector, pin10 (PA5) test point
TP28 J16A, QSH connector, pin11 (PA6) test point
TP25 J16A, QSH connector, pin12 (PA7) test point
TP26 J16A, QSH connector, pin13 (PA8) test point
TP23 J16A, QSH connector, pin14 (PA9) test point
5.7

Connectors

The mini module has other connectors described in the below table.
Connectors
J20 12-pin header connector for SIPI interface
J18 14-pin header connector for JTAG port
12-pin SAMTEC connector for JTAG/LFAST
CN1
LVDS interface
J36, J37 DC-DC Regulator Module
2 X Samtec QSH series, 240 way connector to
J16, J17
connect mini module to motherboard
UM2763 - Rev 1
Table 6. Test points
Description
Table 7. Other connectors
Description
Position
Figure 4. SPC58XCADPT176S top mini module view
Figure 4. SPC58XCADPT176S top mini module view
Figure 4. SPC58XCADPT176S top mini module view
Figure 4. SPC58XCADPT176S top mini module view
Figure 4. SPC58XCADPT176S top mini module view
Figure 4. SPC58XCADPT176S top mini module view
Figure 4. SPC58XCADPT176S top mini module view
Figure 4. SPC58XCADPT176S top mini module view
Figure 4. SPC58XCADPT176S top mini module view
Figure 4. SPC58XCADPT176S top mini module view
Figure 4. SPC58XCADPT176S top mini module view
Figure 4. SPC58XCADPT176S top mini module view
Figure 4. SPC58XCADPT176S top mini module view
Figure 4. SPC58XCADPT176S top mini module view
Figure 4. SPC58XCADPT176S top mini module view
Position
Figure 4. SPC58XCADPT176S top mini module view
Figure 4. SPC58XCADPT176S top mini module view
Figure 4. SPC58XCADPT176S top mini module view
Figure 4. SPC58XCADPT176S top mini module view
Figure 5. SPC58XCADPT176S bottom mini module view
UM2763
Test points
- A3
- A2
- A3
- A3
- A3
- C2
- C2
- C2
- C2
- A4
- A4
- A4
- B4
- A4
- B4
- C2
- A4
- A3
- A1/A2
