5.8
Debug configuration jumpers
The mini module has 2 jumpers that can be used for the debug configuration/standard configuration mode
described in the following table:
Connectors
J41
J42
UM2763 - Rev 1
Table 8.
Description
EVTO/ESR0 configuration jumper:
•
Configuration 1-2 allowed
•
Configuration 2-3 reserved
PORST/ESR0 configuration jumper:
•
Configuration 1-2 allowed
•
Configuration 2-3 reserved
Debug configuration jumpers
Figure 4. SPC58XCADPT176S top mini module view
Figure 4. SPC58XCADPT176S top mini module view
UM2763
Debug configuration jumpers
Position
- A3
- A3
page 10/24
