FEP630, FEH630 ELECTROMAGNETIC FLOWMETER | CI/FEP630/FEH630-EN REV. D
... 6 Commissioning
... Parameterization via the menu function Easy Setup
Easy Setup
Pulse Width
30.00 ms
Next
22. Use
to call up the edit mode.
23. Use
/
to select the desired pulse width for the pulse
output..
24. Confirm the selection with
Easy Setup
Damping
30.00 ms
Next
25. Use
to call up the edit mode.
26. Use
/
to set the desired damping.
27. Confirm the selection with
Easy Setup
Dig.Out 41/42 Mode
Pulse
Next
28. Use
to call up the edit mode.
29. Use
/
to select the desired operating modeOff,
Logic, Pulse, Frequencyfor the digital output.
30. Confirm the selection with
Easy Setup
Curr.Out at Alarm
High Alarm
Next
31. Use
to call up the edit mode.
32. Use
/
to select the desired alarm mode.
33. Confirm the selection with
Edit
.
Edit
.
Edit
.
Edit
.
Easy Setup
Low Alarm
3.500 mA
Next
34. Use
to call up the edit mode.
35. Use
/
to set the desired current for Low Alarm.
36. Confirm the selection with
Easy Setup
High Alarm
21.800 mA
Next
37. Use
to call up the edit mode.
38. Use
/
to set the desired current for High Alarm.
39. Confirm the selection with
Edit
.
Edit
.
