A B B M E A S U R E M E N T & A N A LY T I C S | U S E R G U I D E S U P P L E M E N T | I M/ W M P B S T– E N R E V. B
WaterMaster
Electromagnetic flowmeter
—
WaterMaster
electromagnetic
flowmeter
PROFIBUS FEX100-DP
Parameter Tables
Measurement made easy

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PROFIBUS FEX100-DP and is the answer not in the manual?

Questions and answers

Related Manuals for ABB PROFIBUS FEX100-DP

Summary of Contents for ABB PROFIBUS FEX100-DP

  • Page 1 A B B M E A S U R E M E N T & A N A LY T I C S | U S E R G U I D E S U P P L E M E N T | I M/ W M P B S T– E N R E V. B WaterMaster Electromagnetic flowmeter PROFIBUS FEX100-DP Parameter Tables Measurement made easy —...
  • Page 2 For more information Further publications for the WaterMaster electromagnetic flowmeter are available for free download from: www.abb.com/measurement or by scanning this code: Search for or click on Data Sheet DS/WM-EN WaterMaster | Electromagnetic flowmeter User Guide IM/WM WaterMaster | Electromagnetic flowmeter...

  • Page 3: Table Of Contents

    WaterMaster Electromagnetic flowmeter Contents Contents 1 Introduction ..............2 Acronyms and Abbreviations ........2 2 Parameter Tables ............2 Slot 0 – Physical Block ..........3 Slot 1 – Analog Input 1 – Volume Flow ..... 9 Slot 2 – Totalizer 1 – Volume Flow ......13 Slot 3 –...

  • Page 4: Introduction

    WaterMaster Electromagnetic flowmeter 1 Introduction 1 Introduction 2 Parameter Tables ® This user guide identifies PROFIBUS slot and index parameter Table 2.1 contains a description for the legends in tables 2.2 to tables for WaterMaster FEX100-DP series flowmeters that are 2.14.

  • Page 5: Slot 0 - Physical Block

    WaterMaster Electromagnetic flowmeter 2 Parameter Tables 2.1 Slot 0 – Physical Block Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport BLOCK_OBJECT 16 / 0 DS-32 r / C / a –...
  • Page 6 WaterMaster Electromagnetic flowmeter 2 Parameter Tables Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport SOFTWARE_REVISION 24 / 8 VisibleString r / C / a ’? ’ Revision number of the device firmware. HARDWARE_REVISION 25 / 9 VisibleString...
  • Page 7 WaterMaster Electromagnetic flowmeter 2 Parameter Tables Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport DEVICE_INSTAL_DATE 38 / 22 OctetString r,w / C / a ’ ’ Device installation date text. LOCAL_OP_ENA Local Operation 39 / 23...
  • Page 8 WaterMaster Electromagnetic flowmeter 2 Parameter Tables Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport DIAG_SIMUL_STATUS Enables / Disables diagnosis simulation. 52 / 36 Unsigned 8 r,w / C / a Disabled 0: Disabled 1: Enabled...
  • Page 9 WaterMaster Electromagnetic flowmeter 2 Parameter Tables Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport DIAG_ALARM_SIMULATION Selects the device alarm to simulate. 0: Off 2: Logic simulation selected on OP1 3: Pulse simulation selected on OP1 4: Logic simulation selected on OP1 5: Pulse simulation selected on OP2...
  • Page 10 WaterMaster Electromagnetic flowmeter 2 Parameter Tables Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport MASK_OVERRANGE_103 Mask for the Overflow 103% alarm. 63 / 47 Unsigned 8 r,w / C / a Enabled 0: Disabled 1: Enabled...

  • Page 11: Slot 1 - Analog Input 1 - Volume Flow

    WaterMaster Electromagnetic flowmeter 2 Parameter Tables 2.2 Slot 1 – Analog Input 1 – Volume Flow Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport BLOCK_OBJECT 16 / 0 DS-32 r / C / a –...
  • Page 12 WaterMaster Electromagnetic flowmeter 2 Parameter Tables Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport UNUSED 25 / 9 – – – – – Unused parameter. The Function Block parameter OUT contains the current measurement value in a 26 / 10 r,w / O / cyc vendor-specific or configuration-adjusted engineering unit and the belonging state in...
  • Page 13 WaterMaster Electromagnetic flowmeter 2 Parameter Tables Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport FSAFE_VALUE 34 / 18 Float r,w / C / a – Default value for the OUT parameter, if a sensor or sensor electronic fault is detected. The unit of this parameter is the same as that for OUT.
  • Page 14 WaterMaster Electromagnetic flowmeter 2 Parameter Tables Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport HI_ALM 47 / 31 The state of the upper limit of an alarm and the related time stamp. The time stamp DS-39 r / C / a –...

  • Page 15: Slot 2 - Totalizer 1 - Volume Flow

    WaterMaster Electromagnetic flowmeter 2 Parameter Tables 2.3 Slot 2 – Totalizer 1 – Volume Flow Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport BLOCK_OBJECT 16 / 0 DS-32 r / C / a Contains the characteristics of the blocks.
  • Page 16 WaterMaster Electromagnetic flowmeter 2 Parameter Tables Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport SET_TOT Setting this parameter to Reset assigns a value of 0 to the totalizer. When set to Preset, the value of parameter PRESET_TOT is assigned to the totalizer.
  • Page 17 WaterMaster Electromagnetic flowmeter 2 Parameter Tables Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport HI_HI_ALM 38 / 22 The state of the upper limit of an alarm and the related time stamp. The time stamp DS-39 r / C / a expresses the time the measured variable has been equal or higher than the upper limit...

  • Page 18: Slot 3 - Totalizer 2 - Volume Flow

    WaterMaster Electromagnetic flowmeter 2 Parameter Tables 2.4 Slot 3 – Totalizer 2 – Volume Flow Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport BLOCK_OBJECT 16 / 0 DS-32 r / C / a –...
  • Page 19 WaterMaster Electromagnetic flowmeter 2 Parameter Tables Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport SET_TOT Setting this parameter to Reset assigns a value of 0 to the totalizer. When set to Preset, the value of parameter PRESET_TOT is assigned to the totalizer.
  • Page 20 WaterMaster Electromagnetic flowmeter 2 Parameter Tables Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport HI_HI_ALM 38 / 22 The state of the upper limit of an alarm and the related time stamp. The time stamp DS-39 r / C / a –...

  • Page 21: Slot 4 - Analog Input 2 - Internal Volume Forward Totalizer

    WaterMaster Electromagnetic flowmeter 2 Parameter Tables 2.5 Slot 4 – Analog Input 2 – Internal Volume Forward Totalizer Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport BLOCK_OBJECT 16 / 0 DS-32 r / C / a –...
  • Page 22 WaterMaster Electromagnetic flowmeter 2 Parameter Tables Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport OUT_SCALE Scale of the Process Variable. 28 / 12 DS-36 r,w / C / a –...
  • Page 23 WaterMaster Electromagnetic flowmeter 2 Parameter Tables Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport UNUSED 40 / 24 – – – – – Unused parameter. LO_LIM 41 / 25 Lower limit value for alarms with the same engineering unit as that of the OUT parameter.

  • Page 24: Slot 5 - Analog Input 3 - Internal Volume Reverse Totalizer

    WaterMaster Electromagnetic flowmeter 2 Parameter Tables 2.6 Slot 5 – Analog Input 3 – Internal Volume Reverse Totalizer Access / Abs. Idx Variable Name / Brief Description Data Type Size Store Usage / Default / Rel. Idx Transport BLOCK_OBJECT 16 / 0 DS-32 r / C / a –...
  • Page 25 WaterMaster Electromagnetic flowmeter 2 Parameter Tables Access / Abs. Idx Variable Name / Brief Description Data Type Size Store Usage / Default / Rel. Idx Transport OUT_SCALE Scale of the Process Variable. 28 / 12 DS-36 r,w / C / a –...
  • Page 26 WaterMaster Electromagnetic flowmeter 2 Parameter Tables Access / Abs. Idx Variable Name / Brief Description Data Type Size Store Usage / Default / Rel. Idx Transport UNUSED 40 / 24 – – – – – Unused parameter. LO_LIM 41 / 25 Lower limit value for alarms with the same engineering unit as that of the OUT parameter.

  • Page 27: Slot 6 - Analog Input 4 - Diagnostic Signal

    WaterMaster Electromagnetic flowmeter 2 Parameter Tables 2.7 Slot 6 – Analog Input 4 – Diagnostic Signal Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport BLOCK_OBJECT 16 / 0 DS-32 r / C / a –...
  • Page 28 WaterMaster Electromagnetic flowmeter 2 Parameter Tables Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport OUT_SCALE Scale of the Process Variable. 28 / 12 DS-36 r,w / C / a –...
  • Page 29 WaterMaster Electromagnetic flowmeter 2 Parameter Tables Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport HI_LIM 39 / 23 Upper limit value for alarms with the same engineering unit as that of the OUT parameter. Float r,w / C / a –...

  • Page 30: Slot 7 - Analog Output 1 - Display Value

    WaterMaster Electromagnetic flowmeter 2 Parameter Tables 2.8 Slot 7 – Analog Output 1 – Display Value Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport BLOCK_OBJECT 16 / 0 DS-32 r / C / a –...
  • Page 31 WaterMaster Electromagnetic flowmeter 2 Parameter Tables Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport UNUSED 29 / 13 – – – – – Unused parameter. RCAS_IN 30 / 14 r,w / C / a –...
  • Page 32 WaterMaster Electromagnetic flowmeter 2 Parameter Tables Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport UNUSED 44 / 28 – – – – – Unused parameter. UNUSED 45 / 29 –...

  • Page 33: Slot 8 - Transducer Block 1 - Flow

    WaterMaster Electromagnetic flowmeter 2 Parameter Tables 2.9 Slot 8 – Transducer Block 1 – Flow Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport BLOCK_OBJECT 16 / 0 DS-32 r / C / a –...
  • Page 34 WaterMaster Electromagnetic flowmeter 2 Parameter Tables Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport ZERO_POINT User zero velocity value. 28 / 12 Float r,w / C / a Min: -50 Max: 50 Unit: mm/s...
  • Page 35 WaterMaster Electromagnetic flowmeter 2 Parameter Tables Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport VOLUME_FLOW_HI_LIMIT Absolute value of the upper range value (volume flow) of the sensor. 36 / 20 Float r,w / C / a Min: TB1.VOLUME_FLOW_RANGE_LOWER...
  • Page 36 WaterMaster Electromagnetic flowmeter 2 Parameter Tables Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport SAMPLING_FREQ 57 / 41 r,w / C / a Parameter unused by WaterMaster, implemented for Profile compliance only. SAMPLING_FREQ_UNITS 58 / 42 Parameter unused by WaterMaster, implemented for Profile compliance only.
  • Page 37 WaterMaster Electromagnetic flowmeter 2 Parameter Tables Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport UNUSED 79 / 63 – – – – – Unused parameter. UNUSED 80 / 64 –...
  • Page 38 WaterMaster Electromagnetic flowmeter 2 Parameter Tables Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport LOW_FLOW_CUTOFF_HYSTERESIS Hysteresis for flow cutoff in percent. 95 / 79 Float r,w / C / a Min: 0 Max: 50 Unit: %...
  • Page 39 WaterMaster Electromagnetic flowmeter 2 Parameter Tables Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport FACTORY_SENSOR_ZERO 106 / 90 Factory-set zero value. Float r / C / a Unit: mm/s TRIM_ST 107 / 91 Trim factor.
  • Page 40 WaterMaster Electromagnetic flowmeter 2 Parameter Tables Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport VOLUME_FLOW_RANGE_UPPER 115 / 99 Dynamic upper limit for flow values. Float r / C / a Unit: TB1.VOLUME_FLOW_UNITS FLOW_VELOCITY_RANGE_LOWER 116 / 100...

  • Page 41: Slot 9 - Transducer Block 2 - Device Info

    WaterMaster Electromagnetic flowmeter 2 Parameter Tables 2.10 Slot 9 – Transducer Block 2 – Device Info Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport BLOCK_OBJECT 16 / 0 DS-32 r / C / a –...
  • Page 42 WaterMaster Electromagnetic flowmeter 2 Parameter Tables Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport SENSOR_TYPE Type of sensor in use. 0: Probe 1: Process 2: Hygienic 28 / 12 Unsigned 8 r / C / a 3: WM Reduced Throat...
  • Page 43 WaterMaster Electromagnetic flowmeter 2 Parameter Tables Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport SENSOR_ID 33 / 17 Unsigned 32 r / C / a Sensor ID number. SENSOR_SAP_ERP_NUMBER 34 / 18 VisibleString...
  • Page 44 WaterMaster Electromagnetic flowmeter 2 Parameter Tables Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport LINING_MATERIAL Material type of the sensor lining. 0: PTFE 1: Tefzel ETFE 2: PEEK 3: Hard Rubber 4: Linatex 5: Elastomer...
  • Page 45 WaterMaster Electromagnetic flowmeter 2 Parameter Tables Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport TRANSMITTER_FIRST_CAL_DATE 56 / 40 VisibleString r / C / a ’? ’ Initial date of transmitter calibration. TRANSMITTER_LAST_CAL_DATE 57 / 41 VisibleString...

  • Page 46: Slot 10 - Transducer Block 3 - Special Function

    WaterMaster Electromagnetic flowmeter 2 Parameter Tables 2.11 Slot 10 – Transducer Block 3 – Special Function Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport BLOCK_OBJECT 16 / 0 DS-32 r / C / a –...
  • Page 47 WaterMaster Electromagnetic flowmeter 2 Parameter Tables Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport RESET_ALL_VOLUME 30 / 14 Unsigned 8 r,w / C / a – Resets all volume totalizers. DO1_PULSES 31 / 15 Output frequency of Digital Output 1.
  • Page 48 WaterMaster Electromagnetic flowmeter 2 Parameter Tables Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport DO1_LOGIC_ACTION_STATE Action state for Logic Output 1. 42 / 26 Unsigned 8 r,w / C / a Normally Open 0: Normally Open 1: Normally Closed...
  • Page 49 WaterMaster Electromagnetic flowmeter 2 Parameter Tables Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport DO3_LOGIC_ACTION_STATE Action state for Logic Output 3. 54 / 38 Unsigned 8 r,w / C / a Normally Open 0: Normally Open 1: Normally Closed...

  • Page 50: Slot 11 - Transducer Block 4 - Display

    WaterMaster Electromagnetic flowmeter 2 Parameter Tables 2.12 Slot 11 – Transducer Block 4 – Display Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport BLOCK_OBJECT 16 / 0 DS-32 r / C / a –...
  • Page 51 WaterMaster Electromagnetic flowmeter 2 Parameter Tables Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport LANGUAGE Local display language. 0: English 24 / 8 Unsigned 8 r,w / C / a English 1: German 2: French...
  • Page 52 WaterMaster Electromagnetic flowmeter 2 Parameter Tables Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport MAIN_OPERATOR_VIEW_1_3 Local display Operator Page 1 3 line. 0: Volume Flowrate 29 / 13 1: Q% Unsigned 8 r,w / C / a...
  • Page 53 WaterMaster Electromagnetic flowmeter 2 Parameter Tables Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport MAIN_OPERATOR_VIEW_3_DISPLAY_MODE Local display Operator Page 3 mode. 0: Off 5: 1 x 6 34 / 18 Unsigned 8 r,w / C / a 6: 1 x 6 + Bargraph...
  • Page 54 WaterMaster Electromagnetic flowmeter 2 Parameter Tables Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport DECIMAL_PLACES_FLOWRATE Local display volume flowrate decimal point format. 0: x 38 / 22 Unsigned 8 r,w / C / a x.xx 1: x.x...

  • Page 55: Slot 12 - Transducer Block 5 - Diagnostics

    WaterMaster Electromagnetic flowmeter 2 Parameter Tables 2.13 Slot 12 – Transducer Block 5 – Diagnostics Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport BLOCK_OBJECT 16 / 0 DS-32 r / C / a –...
  • Page 56 WaterMaster Electromagnetic flowmeter 2 Parameter Tables Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport SIMULATION_MODE Internal parameter for simulation. 0: Off 1: Flow Velocity 24 / 8 2: Q Unsigned 8 r,w / C / a 3: Q%...
  • Page 57 WaterMaster Electromagnetic flowmeter 2 Parameter Tables Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport SIMULATION_LOGIC_3 State to simulate on Logic Output 3. 31 / 15 Unsigned 8 r,w / C / a 0: Off 1: On ELECTRODE_RESISTANCE_ALARM_MAX_EP...
  • Page 58 WaterMaster Electromagnetic flowmeter 2 Parameter Tables Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport SIMULATION_VOLUME_FLOW_RANGE_UPPER 41 / 25 Float r / C / a Upper limit for internal simulated volume flowrate values. SIMULATION_FLOW_VELOCITY_RANGE_LOWER 42 / 26 Float...
  • Page 59 WaterMaster Electromagnetic flowmeter 2 Parameter Tables Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport UNUSED 54 / 38 – – – – – Unused parameter. UNUSED 55 / 39 –...
  • Page 60 WaterMaster Electromagnetic flowmeter 2 Parameter Tables Access / Abs. Idx / Variable Name / Brief Description Data Type Size Store Usage / Default Rel. Idx Transport UNUSED 72 / 56 – – – – – Unused parameter. ELECTRODE_2_RESISTANCE 73 / 57 Resistance of electrode 2.

  • Page 61: Appendix A - Profibus-Pa Block Structure Diagrams

    WaterMaster Electromagnetic flowmeter Appendix A – PROFIBUS-PA Block Structure Diagrams Appendix A – PROFIBUS-PA Block Structure Diagrams The following diagrams illustrate the relationship and data flow in PROFIBUS-PA Function Blocks and Flow Transducer Block used in WaterMaster. A.1 Analog Input Function Block Standard Parameters CHANNEL...

  • Page 62: Totalizer Function Block

    WaterMaster Electromagnetic flowmeter Appendix A – PROFIBUS-PA Block Structure Diagrams PV (Primary FB-Algorithm Value) from Transducer Block Field_Val Field_Val = (PV – EU 0%) / (EU 100% – EU 0%) PV_SCALE PV_SCALE PV_SCALE PV_SCALE LIN_TYPE Field_Val Linearization TV = Field_Val * (EU 100% – EU 0%) + EU 0% OUT_SCALE OUT_SCALE OUT_SCALE...

  • Page 63: Analog Output Function Block

    WaterMaster Electromagnetic flowmeter Appendix A – PROFIBUS-PA Block Structure Diagrams Channel t Totalizer Function Block Status Value Last good value Logic FAIL_TOT Balanced: 1; POS_ONLY: if a > 0 then 1 else 0; MODE_TOT NEG_ONLY: if a < 0 then 1 else 0; HOLD: 0;...
  • Page 64 WaterMaster Electromagnetic flowmeter Appendix A – PROFIBUS-PA Block Structure Diagrams Analog Output Function Block Status MODE- and Status Status STATUS- Handling to Remote station RCAS_OUT Value Status from Remote RCas Station RCAS_IN Value Status RCas Algorithms Auto from Operator Auto to Transducer Value (Out_Channel)

  • Page 65: Flow Transducer Block

    WaterMaster Electromagnetic flowmeter Appendix A – PROFIBUS-PA Block Structure Diagrams FB-Algorithms Temp = (SP – EU 0%) / (EU 100% – EU 0%) PV_SCALE PV_SCALE PV_SCALE OUT = Temp (EU 100% – EU 0%) + EU 0% OUT_SCALE OUT_SCALE OUT_SCALE PV_SCALE OUT_SCALE Temp = (PV –...

  • Page 66: Appendix B - Profibus Data Structures

    WaterMaster Electromagnetic flowmeter Appendix B – PROFIBUS Data Structures Appendix B – PROFIBUS Data Structures The following PROFIBUS and WaterMaster-specific data structures are used in the WaterMaster blocks. Element Name Data Type Size Element Name Data Type Size Reserved Unsigned8 Current OctetString Block_Object...
  • Page 67 Acknowledgments Profibus and Profibus DP are registered trademarks of the Profibus Organization. Sales Service Software...
  • Page 68 We reserve the right to make technical changes or modify the contents of this document without prior notice. With regard to purchase orders, the agreed particulars shall prevail. ABB does not accept any responsibility whatsoever for potential errors or possible lack of information in this document.
