8.1.1 Configuring BMS Communication with IntelliSlot Card

Modbus, BACnet, SNMP, SMS and HTTP communication cannot be configured via iCOM. To set up third-party protocols,
refer to the appropriate Liebert® IntelliSlot Card user manual available at https://www.vertiv.com/en-us/support/.
NOTICE
Risk of loss of communication with Liebert® IntelliSlot cards. Can cause operational problems.
Do not change the monitoring address of the IntelliSlot card (set at 3) unless directed by a technical support
representative.
To Set Up Communication with a Card
1. Touch
2. Select IntelliSlot Card Settings and refer to
3. Touch Save.
NOTE: Depending on the type of thermal management unit, included components, and control settings of your
system, all of the options listed may not be available on your iCOM display.
IntelliSlot Options
Monitoring Address
Address used by an optional, installed IntelliSlot card. The factor default is 3.
• Do not modify the monitoring address unless directed to do so by Vertiv™ technical support.
Monitoring Protocol
Protocol used for communication with BMS. Options are:
• Velocity V3: Legacy Velocity communication card
• IGM: IGMNet communication cards
• Velocity V4: Liebert IS-UNITY card.
• Embedded: Embedded IS-UNITY function
• Embedded & IS V4 Both Embedded Unity function and Velocity V4 for an optionally installed IS-UNITY card

8.1.2 Setting BMS Control Settings

1. Touch
secondary panel opens.
2. Adjust the settings, and touch Save. The settings are configured.
NOTE: Use Configure Timeout to configure the setpoints used in the event of an outage and BMS takes control. See
Setting BMS Backup Setpoints
80
, then > BMS & Teamwork > BMS Setup. The BMS SETUP panel opens.
, then > BMS & Teamwork > BMS Setup > Control Settings. The CONTROL SETTINGS
on the facing page.
IntelliSlot Options below, to make selections.
