Figure 12.8 Termination Jumper on 2T Circuit Board
114
Item
Description
1
Position 1 (P3 jumper)
2
Position 2 (P3 jumper)
3
Position 3 (P3 jumper)
4
Unterminated
5
Terminated
6
Rear of sensor, cover removed
7
P3 termination jumper
Vertiv™ | Liebert® iCOM™ Installer/User Guide
