Table B.2 Service Menu Setpoints by Line ID (continued)
Line Parameter
Range
ID Name
SP Pause time
at deadband 2 - 180 sec
maximum
SP Pulse Time
S194 2 - 15 sec
inside Deadband
0.010 - 1.003
Static Pressure
Prop Band inWC
inWC
S195
Static Pressure
2 - 250 Pa
Prop Band Pa
SP During Disabled
S196
Dehum Enabled
Static Pressure
Average
S197 Teamwork
Minimum
Mode
SP Sensors in
S198 1 - 32
Avg for TW
SP Off
Operation on
S199
Sensor Failure
Freeze Speed
Static Pressure
0.010 - 1.003
Upper Range
inWC
inWC
S1A1
Static Pressure
2.5 - 250.0 Pa
Upper Range Pa
Static Pressure
0.000 - 0.993
Lower Range
inWC
inWC
S1A2
Static Pressure
0.0 - 247.5 Pa
Lower Range Pa
Enable Static None Remote
S1A4 Pressure Control Sensor Return
Override Sensor
41 - 104 °F
SP Requested
S1A5
Speed up to
5.0 - 40.0 °C
41 - 104 °F
S1A6 STD Speed at
5.0 - 40.0 °C
Default
Description
Setting
60 sec%
3 sec Sets the pulse time that the speed filter will be performed to the fan analog output.
0.020
inWC
Sets the proportional band for which the fan speed modulation output calculation is based
upon in relation to the difference between the pressure reading the SP Setpoint.
5 Pa
Sets the use of static pressure control if dehumidification becomes active. It set to Disabled
then the static pressure routines will become inactive and the fan will be allowed to ramp to
Disabled
the dehumidification speed set in Fan speed Dehum/No Power. If set to "Enabled", then the
static pressure routines shall remain active during the call for dehumidification.
There are modes available for static pressure teamwork functionality: Average & Minimum.
When selecting "Average Mode", the average of the lowest static pressure sensor readings in
the system will be average to generate a shared static pressure value for all units in the team.
Average
The number of static pressure sensors to be averaged is set in line S198 SP Sensors in Avg for
TW. When this line is set to a value lower than the number of units in the team, the lowest
static pressure readings will be averaged.
2 Sets the number of sensors used when averaging sensors in the teamwork.
This parameter determines what action to take if the static pressure sensor fails (non-
teamwork). If "SP OFF" is selected, then the control will use S146 "Fan Control Sensor" to
SP Off control the fan when the sensor is lost. If "Freeze Speed" is selected, then the control will keep
the fan speed in its last known position. Situations that need to override the fan speed such as
Freeze Protection can still change the fan speed.
0.030
inWC
The control calculates the Upper Range by using S191 "SP Setpoint" and S192 "SP Deadband",
the results on lines show both values, inWC and Pa.
7.5 Pa
0.010
inWC
The control calculates the Lower Range by using S191 "SP Setpoint" and S192 "SP Deadband",
the results on lines show both values, inWC and Pa.
2.5 Pa
None
86 °F
30.0 °C
95 °F
35.0 °C
