11.7 Diagnosing Digital Output Issues

1. Touch
DIGITAL OUTPUTS panel displays.
2. Refer to
NOTE: Depending on the type of thermal management unit, included components, and control settings of your
system, all of the options listed may not be available on your iCOM display.
11.7.1 Diagnostics—Digital Output Options
Alarm Relay
Enables/disables alarms during manual/diagnostic mode.
Q15 Output State
Enables/disables Q15 output during manual/diagnostic mode.

11.8 Diagnosing Analog Output Issues

1. Touch
ANALOG OUTPUTS panel displays.
2. Refer to
NOTE: Depending on the type of thermal management unit, included components, and control settings of your
system, all of the options listed may not be available on your iCOM display.
11.8.1 Diagnostics—Analog Output Options
Analog Output N
Controls analog outputs during manual/diagnostic mode. (where N is the analog output number)

11.9 Diagnosing Customer Input Issues

1. Touch
CUSTOMER INPUTS panel displays.
2. Refer to
NOTE: Depending on the type of thermal management unit, included components, and control settings of your
system, all of the options listed may not be available on your iCOM display.
11.9.1 Diagnostics—Customer Input Options
Input N
Status and description of customer-input sensors (where N is the input number).
11 Performing Diagnostics
, then > Diagnostic/Service > Diagnostics > Digital Outputs in the Category list. The
Diagnostics—Digital Output Options
, then > Diagnostic/Service > Diagnostics > Analog Outputs in the Category list. The
Diagnostics—Analog Output Options
, then > Diagnostic/Service > Diagnostics > Customer Inputs in the Category list. The
Diagnostics—Customer Input Options
below for descriptions of diagnostic options.
below, for descriptions of diagnostic options.
below, for descriptions of diagnostic options.
