Vertiv Liebert iCOM DP400/500 Installer/User Manual

Vertiv Liebert iCOM DP400/500 Installer/User Manual

Intelligent communication and monitoring for dse packaged solution dp060
Hide thumbs
Table of Contents

Advertisement

Quick Links

Liebert®
iCOM™
Installer/User Guide
Intelligent Communication and Monitoring for Liebert DSE Packaged Solution DP060,
DP400/500

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Liebert iCOM DP400/500 and is the answer not in the manual?

Questions and answers

Summary of Contents for Vertiv Liebert iCOM DP400/500

  • Page 1 Liebert® iCOM™ Installer/User Guide Intelligent Communication and Monitoring for Liebert DSE Packaged Solution DP060, DP400/500...
  • Page 2 The products covered by this instruction manual are manufactured and/or sold by Vertiv. This document is the property of Vertiv and contains confidential and proprietary information owned by Vertiv. Any copying, use or disclosure of it without the written permission of Vertiv is strictly prohibited.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS 1 Getting Started with iCOM™ 1.1 Touchscreen Display and User Interface 1.2 Touchscreen Status Dial 1.2.1 Dial Background Color Status Indication 1.3 Control Header 1.3.1 Powering On iCOM and Logging In/Unlocking Controls 1.3.2 Powering On the Thermal Management Unit 1.3.3 Powering Off the Thermal Management Unit 1.3.4 Logging Out 1.3.5 Calibrating the Touchscreen...
  • Page 4 6 Teamwork, Standby and Rotation for Cooling Units 6.1 Continuous Control with Virtual Master 6.2 Teamwork Modes 6.2.1 To Set Up Team Work 6.2.2 No Teamwork—Multiple Zones in One Room 6.2.3 Teamwork Mode 1—Parallel Operation 6.2.4 Teamwork Mode 2—Independent Operation Vertiv™ | Liebert® iCOM™ Installer/User Guide...
  • Page 5 6.2.5 Teamwork Mode 3—Optimized Aisle Operation 6.3 Assigning Cooling Units to Standby (Lead/Lag) 6.3.1 To Set up Lead/Lag Operation 6.4 Setting a Rotation Schedule 6.4.1 Unit Rotation Options 6.4.2 Manually Rotating the Operating and Standby Units 7 Configuring Economizer Operation 7.1 Fluid Economizers 7.1.1 Fluid Economizer Control Options 7.1.2 Overriding Fluid Economizer Operation 7.1.3 Setting Up Fluid Economizer Operation...
  • Page 6 13.1 Installing Wired Remote Sensors 13.1.1 Setting DIP Switches and Labeling 2T Sensors 13.1.2 Terminating the Last Sensor on the CANbus Link 13.1.3 Installing 2T Sensors in the Racks to Monitor 13.1.4 Connect the CANbus Cable and Ground Vertiv™ | Liebert® iCOM™ Installer/User Guide...
  • Page 7 13.2 Installing a Fluid Temperature Sensor 13.3 Installing Supply Control Sensors 13.3.1 Installing the Supply Air Temperature Sensor 13.3.2 Installing Aggregated Supply Air Temperature Sensors 13.4 Installing Analog Input Devices 13.5 Installing the Unit to Unit Network 13.5.1 Required Network Equipment 13.5.2 Planning Wiring Runs 13.5.3 U2U Wiring connection 13.5.4 Wiring Cooling Units without Wall Mount Displays...
  • Page 8 This page intentionally left blank Vertiv™ | Liebert® iCOM™ Installer/User Guide...

  • Page 9: Getting Started With Icom

    1 GETTING STARTED WITH iCOM™ The Liebert® iCOM offers the highest capability for unit control, communication, and monitoring of Liebert® Thermal Management units. It is available factory installed on new units and assemblies or may be retrofitted in existing units. NOTE: Your Liebert®...
  • Page 10 Lock/Unlock icon. Indicates whether or not the user and service options are accessible. • Locked icon: Display is read-only • Unlocked icon: User or service is logged-in and options are accessible. Powering On iCOM and Logging In/Unlocking Controls on page 6. Vertiv™ | Liebert® iCOM™ Installer/User Guide...

  • Page 11: Touchscreen Status Dial

    Table 1.1 Main Display controls and options (continued) Item Description Secondary-content panel. When accessing settings/configuration via the menus, the settings display in the right, secondary panel. Summary of current unit function. You can customize to show fan speed, cooling, percentages from any installed device, and any physical (sensor) values.
  • Page 12 If the sensor selected for fan control is the same as that selected for temperature control, the dial displays the fan-control sensor and setpoint, as shown in Figure 1.2 above. Single or multiple sensor readings. Cycle through readings by touching the displayed reading. Vertiv™ | Liebert® iCOM™ Installer/User Guide...

  • Page 13: Dial Background Color Status Indication

    1.2.1 Dial Background Color Status Indication The background color of the dial indicates whether or not the unit is powered on, and it also responds to threshold settings of the control-sensor reading, see Figure 1.3 below. Table 1.3 below describes the background color displayed if the selected sensor reading has threshold limits set.

  • Page 14: Control Header

    2. Touch the numbers/characters for your password, then touch Depending on the password entered and your level of access, the User and/or Service options, and view only access to the Advanced menu are accessible. See Accessing the User, Service. and Advanced Menus page 10. Vertiv™ | Liebert® iCOM™ Installer/User Guide...

  • Page 15: Powering On The Thermal Management Unit

    1.3.2 Powering On the Thermal Management Unit NOTE: Depending on the operating state, there are start/stop priority switches that may prevent the cooling unit from operating even though power to the unit is switched on and you have turned it on via iCOM. The cooling unit operates only when all switches are closed.

  • Page 16: Powering Off The Thermal Management Unit

    If one is off/open, the unit turns off. MONITORING Turned-off by remote monitoring system. Check the remote monitoring device or call Vertiv™ technical support for assistance. BACK-DRAFT Unit is non-operational, but EC fan is operating as a back draft damper.

  • Page 17: Setting The Date And Time

    5. When the LED begins flashing, remove your finger. Cross hairs appear in each corner and in the center of the display. 6. Touch the center of each cross hair ONCE ONLY. (Touching more than once interrupts the calibration and you must start over at step 3.) Cross hairs disappear and the display reboots when calibration is complete.

  • Page 18: About Icom Version

    • Customize Layout: See Customizing Main Display Views on page 104. • Custom Labels: See Customizing Parameter and Field Labels on page 106. • Date & Time: See Setting the Date and Time on the previous page. Vertiv™ | Liebert® iCOM™ Installer/User Guide...

  • Page 19: Service Menu

    Total Run Hours Opens the RUN HOURS panel. See Managing Run Hours for a Component on page 17. EconoPhase Opens the ECONOPHASE - PUMP MODE panel. About Opens the ABOUT panel. See About iCOM Version on the previous page. Turn Unit On/Off Depending on unit’s status, open the TURN UNIT ON or TURN UNIT OFF dialog.
  • Page 20 Turn Unit On/Off Depending on unit’s status, open the TURN UNIT ON or TURN UNIT OFF dialog. See Powering On the Thermal Management Unit on page 7, or Powering Off the Thermal Management Unit on page 8. Vertiv™ | Liebert® iCOM™ Installer/User Guide...

  • Page 21: User Operation

    2 USER OPERATION 2.1 Viewing and Editing Setpoints for the Cooling Unit NOTE: User level access allows viewing and editing only a limited number of setpoints. To view or adjust all setpoints, you must have service level access. See Editing Setpoints for the Cooling Unit on page 19.

  • Page 22: Viewing Unit Alarms

    2. Touch an alarm to display the ALARM DETAILS panel. Alarm fields Alarm Name of the event. Date Date event was logged. Time Time event was logged Alarm Detail Fields Alarm Name of the event. Vertiv™ | Liebert® iCOM™ Installer/User Guide...

  • Page 23: Silencing An Audible Alarm

    Alarm Type Number representing the event type. • 1: Warning • 2: Alarm Date/Time Date and time the event was logged. Duration Time elapsed since event was logged. Threshold Sensor reading at which an event is triggered. Unit Cooling unit to which the alarm applies. Value The current value to which the threshold is compared.

  • Page 24: Viewing The Event Log

    Red dot Unacknowledged alarm event. See Acknowledging Alarms on the previous page. White dot with check mark overlay Acknowledged event, the cause still exists. White circle Acknowledged event, the cause is cleared. Vertiv™ | Liebert® iCOM™ Installer/User Guide...

  • Page 25: Viewing Sensor Data

    2.4 Viewing Sensor Data The Sensor Data panel lists the standard and optional sensors monitored by iCOM and the current reading of each sensor. • Touch , then > Sensor Data. The SENSOR DATA panel opens. A secondary panel displays the DAILY SENSOR READING SUMMARY, which shows temperature, humidity and dew point readings for the cooling unit.

  • Page 26: Viewing Teamwork, Standby, And Cascade Status

    NOTE: You must be logged in with the Service PIN to edit teamwork mode. See Powering On iCOM and Logging In/Unlocking Controls on page 6. Figure 2.1 Teamwork Icons Item Description No teamwork. Mode 1 - Parallel teamwork Mode 2 - Independent teamwork Mode 3 - Optimized aisle teamwork Vertiv™ | Liebert® iCOM™ Installer/User Guide...

  • Page 27: Service Operation

    3 SERVICE OPERATION NOTE: Your Liebert® DSE™ Packaged Solution does not offer humidification or dehumidification functions. Please disregard those settings/fields when mentioned in this guide or displayed on the iCOM controller. 3.1 Editing Setpoints for the Cooling Unit Setpoints are the means by which cooling unit operation is controlled. NOTE: Depending on the type of thermal management unit, included components, and control settings of your system, all of the options listed may not be available on your iCOM display.
  • Page 28 100% in three minutes. NOTE: Three to five minutes of integration time is adequate for most applications. See Considerations when Using PI Temperature Control on page 23. NOTE: Only used when Temperature Control Type is PI. Vertiv™ | Liebert® iCOM™ Installer/User Guide...

  • Page 29: Temperature Control - Temperature Setpoints And Cooling Operation

    Temperature Proportional Band Adjusts the activation point of cooling components based on deviation from setpoint by placing half of the selected value on each side of the temperature control setpoint. A smaller number causes faster reaction to temperature changes. NOTE: Setting this too low causes short cycling of compressors. Temperature Setpoint Temperature that the unit maintains via cooling.
  • Page 30 Like the proportional band, the deadband is also divided evenly on each side of the setpoint. • 0% cooling capacity is required from 69° to 71°. • At 71°, the system operates according to the temperature proportional band. Vertiv™ | Liebert® iCOM™ Installer/User Guide...

  • Page 31: Compressor Control By Cooling Requirement

    Figure 3.2 Temperature Control with a Deadband Description ½ of proportional band. ½ of proportional band. Deadband. Considerations when Using PI Temperature Control Several factors, such as room heat load, external heat gains, and component specific performance can affect the PI control loop.
  • Page 32 • This results in 66% cooling. Essentially, the compressor is partially loaded. Figure 3.3 Digital Scroll Compressor Operation to Provide 66% Cooling Capacity Description Solenoid de-energized. Solenoid energized. Percent loaded. 15 second capacity modulation cycle. Vertiv™ | Liebert® iCOM™ Installer/User Guide...
  • Page 33 Dual Digital Scroll Compressors In a two digital scroll system, the compressors operate in a lead lag configuration: • The lead compressor starts when the cooling demand is at least 25% (calculated from temperature proportional band) and operates at 50% capacity (valve open 7.5 seconds/closed 7.5 seconds) for an initial period set in Winter Start Delay, see Setting Low Pressure Time Delay on page 40, after which it operates per...
  • Page 34 2 on the inner coil as shown in the example in Figure 3.5 below. Figure 3.5 Dual Circuit, Tandem Digital Scroll Compressors in a Liebert DSE Description In iCOM, tandem compressors us the following naming convention: Vertiv™ | Liebert® iCOM™ Installer/User Guide...

  • Page 35: Setting Temperature Compensation

    • Compressor 1A is digital-scroll and Compressor 1B is fixed, standard-scroll. These comprise tandem- compressor set 1. • Compressor 2A is digital-scroll and Compressor 2B is fixed, standard-scroll. These comprise tandem- compressor set 2. Selecting Event Type and Setting Alarm/Warning Notification on page 45 describes the alarm events associated with the tandem compressors.

  • Page 36: Configuring High/Low Limit Setpoints

    Configures fan speed control to operate independent of compressor loading (de-coupled mode). Touch , then > Setpoints > Fan Control. The FAN CONTROL secondary panel opens. 2. Adjust the setpoint options, then touch Save. The setpoint is updated. • Touch Cancel to discard the changes. Vertiv™ | Liebert® iCOM™ Installer/User Guide...
  • Page 37 NOTE: Depending on the type of thermal management unit, included components, and control settings of your system, all of the options listed may not be available on your iCOM display. Fan Control Options Airflow Calibration Maximum allowed fan output voltage. Fan Control Sensor Selects the sensor that controls automatic fan-speed, see Automatic Fan Speed Control...

  • Page 38: Manual Fan Speed Control

    NOTE: Set the fan speed via BMS by writing to the Fan Speed Maximum Set Point monitoring point. For details, see SL-28170 IntelliSlot Reference Guide found at https://www.vertiv.com/en-us/support/. NOTE: Local adjustments to fan speed are overridden when remote/BMS fan-speed control is set.

  • Page 39: Automatic Fan Speed Control

    3.1.9 Automatic Fan Speed Control Temperature sensors can control fan speed using one of three modes based on the type of sensor selected as the fan control sensor: supply, return, or remote. See Table 3.3 below. Control is based on the selected sensor for both fan control and temperature control and their setpoints as follows: •...

  • Page 40: Scheduling Condenser Low-Noise Operation

    Enable/disable noise reduction. When checked, the schedule is run. When not checked, the scheduling parameters are ignored. Status Indicates if low noise operation is active or inactive. Whole Day Selects whole days for which noise reduction operation is available for the condenser fan. Vertiv™ | Liebert® iCOM™ Installer/User Guide...

  • Page 41: Scheduling Condenser Fan Reversal

    3.2.2 Scheduling Condenser Fan Reversal Condenser fan reversal schedules a reversal of the condenser fans, reversing air flow to help remove dust, paper, leaves and such from the suction side of the condenser coil. Touch , then > Scheduler > Condenser Fan Reversal Schedule. The TASK PROPERTIES panel opens.

  • Page 42: Setting General Thermal Management Unit Options

    Teamwork Control Options on page 64. Free Cool Capacity Transition Filter Selects how quickly capacity changes between modes of operation to avoid overshooting during the transition. • Only a factory trained service technician should adjust this setting. Vertiv™ | Liebert® iCOM™ Installer/User Guide...

  • Page 43: Configuring Quick Start

    K11 Active On Selects the action of the activated K11 (warning) relay. Options are: • Dehum: Dehumidification is on. • Warning: A warning is active. • Emergency Pwr: Emergency power is on. • Freecooling: Freecooling is on. • FC Start: Freecooling is in the start phase or is on. Loss of Power Autoreset Delay Selects the length of time that a Loss of Power event (that triggers after a power cycle that occurs when the cooling unit is operating) is active when power is restored.
  • Page 44 Delay before quick start activates after power is restored (0 to 180 sec). NOTE: When using DX quick start, you must configure a minimum of 40 seconds to allow time for global condenser communication to establish before the compressors are powered on. Vertiv™ | Liebert® iCOM™ Installer/User Guide...

  • Page 45: Automatic Restart After Power Failure

    Quick Start Fan Analog Output Fan speed percentage during quicktart operation. Quick Start Overlap Time Length of time quick start fan speed overlaps normal fan speeds settings. After fully booted, normal fan speed control resumes when this time expires. 3.3.3 Automatic Restart after Power Failure Set the cooling unit to return to the status at which it was operating when input power returns after a power failure.
  • Page 46 Selects the rate and which the fan speed changes during deceleration. Maximum Fan Speed Maximum speed at which the fan will operate. MIN at CFC for EC Fan Cooling deviation at which the fan will operate at minimum speed. Vertiv™ | Liebert® iCOM™ Installer/User Guide...

  • Page 47: Setting Compressor Options

    Minimum Fan Speed Minimum speed at which the fan will operate. No Power Fan Speed Speed at which the fans operate when using emergency power. STD at CFC for EC Fan Cooling deviation at which the fan will operate at maximum speed. 3.3.5 Setting Compressor Options Touch , then...

  • Page 48: Setting Q15 Options

    , then > Options Setup > Q15 Settings. The Q15 SETTINGS panel displays. 2. Make adjustments as needed and click Save. The option settings are updated. • Touch Cancel to discard the changes without saving. Vertiv™ | Liebert® iCOM™ Installer/User Guide...
  • Page 49 Q15 Settings Options Damper Switch Feedback Timer If output function is Damper and End Switch, the length of time iCOM waits for the feedback signal from the damper motor, that is, if it is open or closed. Fan Delay for Damper Length of time that must elapse during damper opening/closing.
  • Page 50 Q15 Temp Actual Current value of the sensor selected as the Q15 Output Sensor. Q15 Temp Output Threshold Temperature threshold above or below which Q15 output activates. Vertiv™ | Liebert® iCOM™ Installer/User Guide...

  • Page 51: Managing Events: Alarms, Warnings And Messages

    4 MANAGING EVENTS: ALARMS, WARNINGS AND MESSAGES NOTE: Your Liebert® DSE™ Packaged Solution does not offer humidification or dehumidification functions. Please disregard those settings/fields when mentioned in this guide or displayed on the iCOM controller. Events are notifications of operating status for the cooling unit, its components, and auxiliary devices. All events are recorded in the Event Log, and alarm and warning events are also displayed on the Alarms panel (See Viewing the Event on page 16, and...

  • Page 52: Enabling Events And Editing Event Settings

    NOTE: To edit the event type and notification, see Selecting Event Type and Setting Alarm/Warning Notification on the facing page. 3. Use the EDIT panel to adjust the settings for the selected event or group of events. Vertiv™ | Liebert® iCOM™ Installer/User Guide...

  • Page 53: Selecting Event Type And Setting Alarm/Warning Notification

    4.3 Selecting Event Type and Setting Alarm/Warning Notification Setting notification delays and disabling visual notification prevents nuisance notifications. Customize to notify of critical events on your cooling system. NOTE: If the event includes a safety function, such as high pressure, low pressure, main fan overload, etc., the safety function executes regardless of event type or notification setting.
  • Page 54 Fixed to WRN LOW HUM SENSOR A 1 min. after fan on 30 sec/0 – 9999 Fixed to WRN COMP 1 OVERLOAD Internal Calc. COMP 2 OVERLOAD Internal Calc. COMP 1 HIGH PRESSURE Internal Calc. Vertiv™ | Liebert® iCOM™ Installer/User Guide...
  • Page 55 Table 4.2 Event Notification Defaults (continued) Default Delay/Range Event Internal Delay Type for Adjustment COMP 2 HIGH PRESSURE Internal Calc. COMP 1 LOW PRESSURE Internal Calc. COMP 2 LOW PRESSURE Internal Calc. COMP 2 PUMPDOWN FAIL Internal Calc. DIG SCROLL1 HIGH TEMP Internal Calc.
  • Page 56 0 sec ENABLED/DIS - ENAB Table 4.3 on the facing page, describes events available with a Liebert® MC Condenser. NOTE: A CANbus connection between the Liebert® MC condenser and iCOM is required to trigger these events. Vertiv™ | Liebert® iCOM™ Installer/User Guide...
  • Page 57 Table 4.3 Events Specific to Liebert MC Condenser Event Description • The Liebert® iCOM board cannot establish communication with the Liebert® MC condenser board for 10 seconds consecutively. • Alarm notification displayed for the corresponding circuit. CAN GC 1 or 2 •...
  • Page 58 Event is reset when iCOM requests a new startup. Pump outlet-refrigerant temperature fell below a lower threshold and pump was shut down. PB1 LO OUTLET TEMP • Event is reset when iCOM requests a new startup. Vertiv™ | Liebert® iCOM™ Installer/User Guide...
  • Page 59 Table 4.4 Events Specific to Liebert EconoPhase (continued) Event Description Outlet refrigerant-pressure-sensor failure. Pump shut down. PB1 OUT PRES SEN FAIL • Event is reset when condition clears. Outlet refrigerant-temperature-sensor failure. Pump shut down. PB1 OUT TEMP SEN FAIL • Event is reset when condition clears.

  • Page 60: Enabling The Audible Alarm Notification

    See Setting Up Customer Input Events on the facing page. RAD and customer input notifications are set in the same way as other events. See Selecting Event Type and Setting Alarm/Warning Notification on page 45. Vertiv™ | Liebert® iCOM™ Installer/User Guide...

  • Page 61: Setting Up Customer Input Events

    4.5.1 Setting Up Customer Input Events Input devices must be wired to Terminal 24 through a dry contact to locations 50, 51, 55 and 56 for alarms 1 through 4 respectively, (For the terminal location, refer to the cooling unit electrical schematic and installation manual). Table 4.5 below, maps the customer input to the RADs Table 4.5 Customer Input Terminals to RAD Terminals Customer Input...
  • Page 62 No event, but switches to the second setpoint. Emergency Power Event + Disables unit. Event + Activates humidifier-problem Alarm and stop filling bottle when full. COND 1 FAIL Event only. COND 2 FAIL Event only. Vertiv™ | Liebert® iCOM™ Installer/User Guide...
  • Page 63 Table 4.6 Customer Input Options (continued) Input Action/Description D-SCROLL RED Event + Reduces requested compressor capacity by 20%. No event -Active X valve closes and Y opens/Inactive Y closes and X opens. See 7.3 - Custom Dual Chilled Water Valve SWAP VALVE Staging.
  • Page 64 This page intentionally left blank Vertiv™ | Liebert® iCOM™ Installer/User Guide...

  • Page 65: Unit To Unit Networking

    5 UNIT TO UNIT NETWORKING NOTE: Your Liebert® DSE™ Packaged Solution does not offer humidification or dehumidification functions. Please disregard those settings/fields when mentioned in this guide or displayed on the iCOM controller. iCOM controlled thermal management units connected in an Ethernet unit to unit (U2U) network are able to efficiently cool and control humidity in the conditioned space by exchanging data in several modes of operation.
  • Page 66 Figure 5.1 Example Layout Standby/Operating Unit Address Assignment Item Description 1 to 10 Assigned address of the thermal-management unit. Operating units. Units on standby. Network switch. Vertiv™ | Liebert® iCOM™ Installer/User Guide...

  • Page 67: Configuring U2U Network Settings

    5.2 Configuring U2U Network Settings NOTE: Always change and save the control board settings first. If you change the display settings first, you could lose access to the control board via iCOM. The U2U NETWORK SETTINGS configure iCOM’s unit to unit communication and includes information buttons, , that display pop-up field descriptions.
  • Page 68 U2U Target Address The address of the control board targeted by the display. • The unit’s U2U target address must match the contro -board U2U address. Vertiv™ | Liebert® iCOM™ Installer/User Guide...

  • Page 69: Troubleshooting Network Settings Issues

    5.2.3 Troubleshooting Network Settings Issues At the bottom of the U2U NETWORK SETTINGS panel, an Issues button indicates whether or not there are problems with the network settings. The button indicates the number of issues and changes color when a problem exists, see Table 5.1 below. Table 5.1 Issues Button Status Colors Color Description...
  • Page 70 This page intentionally left blank Vertiv™ | Liebert® iCOM™ Installer/User Guide...

  • Page 71: Teamwork, Standby And Rotation For Cooling Units

    6 TEAMWORK, STANDBY AND ROTATION FOR COOLING UNITS NOTE: Your Liebert® DSE™ Packaged Solution does not offer humidification or dehumidification functions. Please disregard those settings/fields when mentioned in this guide or displayed on the iCOM controller. iCOM unit to unit communication via private network and additional hardware allows the following operating features for the cooling units.
  • Page 72 Length of time in minutes to delay the activation of a stand-by unit after the previously activated unit starts, to prevent staged cascaded units from starting too close together or at the same time. Cascaded Units Min Run Length of time in minutes that an cascade on unit must run before powering-off. Vertiv™ | Liebert® iCOM™ Installer/User Guide...

  • Page 73: No Teamwork-Multiple Zones In One Room

    Cascaded Units Off Delay Length of time, in minutes, to delay powering-off a cascaded unit after fan speed drops below the Stop   Next Unit @ SYS Fanspeed setting. Cascaded Units Quick Start After a power cycle of the master unit, identical to Cascaded Units Delay except that it should be shorter to get units to start more quickly after a power cycle.

  • Page 74: Teamwork Mode 1-Parallel Operation

    Variable capacity compressors in the cooling unit. • Variable speed fans in the cooling unit. • Supply control air temperature sensors. In addition, specific settings for wired remote (rack) sensors and setpoints are needed as described in the following steps. Vertiv™ | Liebert® iCOM™ Installer/User Guide...

  • Page 75: Assigning Cooling Units To Standby (Lead/Lag)

    To Set Up Optimized Aisle Operation Set wired remote sensor function and mode: • Touch , then > Auxiliary Device Setup > Sensors > Wired Remote Sensors. • Touch each sensor name, and select Control or Reference in Function based on rack setup or preference, then touch Save.

  • Page 76: To Set Up Lead/Lag Operation

    > BMS & Teamwork Setup > Teamwork / Standby. The TEAMWORK/STANDBY panel opens. 2. Touch Unit Rotation. The UNIT ROTATION CONTROL panel displays. 3. Adjust the settings, then touch Save. • Touch Cancel to discard the changes. Vertiv™ | Liebert® iCOM™ Installer/User Guide...

  • Page 77: Unit Rotation Options

    6.4.1 Unit Rotation Options Lead Lag Overlap Timer Length of time in minutes that cooling units operate in parallel when one begins operating (from standby) and the other goes into standby. Rotate At Selects exact time at which rotation occurs. Adjustable, based on a 24 hour clock where minutes are 0 to 59 and hours are 0 to 23.
  • Page 78 > BMS & Teamwork Setup > Teamwork / Standby. The TEAMWORK/STANDBY panel opens. 3. Touch Unit Rotation. The UNIT ROTATION CONTROL panel displays. 4. Touch Rotate Now, then touch Save. The operating and standby units are rotated. Vertiv™ | Liebert® iCOM™ Installer/User Guide...

  • Page 79: Configuring Economizer Operation

    7 CONFIGURING ECONOMIZER OPERATION NOTE: Your Liebert® DSE™ Packaged Solution does not offer humidification or dehumidification functions. Please disregard those settings/fields when mentioned in this guide or displayed on the iCOM controller. Use iCOM to configure the economizer installed on your cooling unit. NOTE: Depending on customization to your cooling system, one of two types of economizer may be installed, Liebert®...

  • Page 80: Overriding Fluid Economizer Operation

    Save. Table 7.1 Economizer Property Status Indicators Indicator color Definition Green The air or fluid meets the requirements for use. Yellow The air or fluid does not meet requirements and is ineligible for use. Vertiv™ | Liebert® iCOM™ Installer/User Guide...
  • Page 81 NOTE: Depending on the type of economizer with your system, all of the options listed may not be available on your iCOM display. Fluid Economizer Set Up Options DT Between Room and Fluid Type Selects the glycol/chilled water temperature input used by the comparator circuit to determine if the differential temperature (DT) warrants use of secondary cooling.

  • Page 82: Temperature Control With A Fluid Economizer

    NOTE: The compressor control method is not affected by economizer operation and operates across the assigned proportional band based on the compressor configuration of your system (1-step, 2-step, 4-step, or digital-scroll). See Compressor Control by Cooling Requirement on page 23, for a description compressor-control methods. Vertiv™ | Liebert® iCOM™ Installer/User Guide...
  • Page 83 Secondary Cooling Temperature Control with 2-Step Compressor When the fluid temperature meets the set up requirements, secondary cooling provides temperature control as follows. If the fluid is not cold enough, primary, compressorized cooling operates as normal. NOTE: The compressor control method is not affected by economizer operation and operates across the assigned proportional band based on the compressor configuration of your system (1-step, 2-step, 4-step, or digital-scroll).
  • Page 84 ½ of proportional band assigned (Compressor 1 in dual-compressor configuration, Unloaded in single-compressor to valve operation. configuration.) Scroll compressor step 2. Fluid control valve closed. (Compressor 2 in dual-compressor configuration, Loaded in single-compressor configuration.) Fluid control valve fully-open. Vertiv™ | Liebert® iCOM™ Installer/User Guide...

  • Page 85: Viewing Fluid Economizer Statuses

    7.1.5 Viewing Fluid Economizer Statuses Display the status of the economizer features installed in the cooling unit. • Touch , then > Economizer > Status. The STATUS panel opens. • If the status indicators are not all green, the economizer is not used to condition the unit. To adjust the settings, see Setting Up Fluid Economizer Operation on page 72.
  • Page 86 This page intentionally left blank Vertiv™ | Liebert® iCOM™ Installer/User Guide...

  • Page 87: External Monitoring And Building Management Systems

    8 EXTERNAL MONITORING AND BUILDING MANAGEMENT SYSTEMS NOTE: Your Liebert® DSE™ Packaged Solution does not offer humidification or dehumidification functions. Please disregard those settings/fields when mentioned in this guide or displayed on the iCOM controller. iCOM controlled cooling units are equipped with Liebert® IntelliSlot™ plug in slots for optional communication cards to communicate with external monitoring systems including Building Management Systems (BMS), Network Monitoring Systems (NMS) and Liebert®...

  • Page 88: Configuring Bms Communication With Intellislot Card

    Monitoring Address Address used by an optional, installed IntelliSlot card. The factor default is 3. • Do not modify the monitoring address unless directed to do so by Vertiv™ technical support. Monitoring Protocol Protocol used for communication with BMS. Options are: •...

  • Page 89: Setting Bms Backup Setpoints

    NOTE: Depending on the type of thermal management unit, included components, and control settings of your system, all of the options listed may not be available on your iCOM display. BMS Control Settings Options BMS is Connected To • Velocity •...
  • Page 90 This page intentionally left blank Vertiv™ | Liebert® iCOM™ Installer/User Guide...

  • Page 91: Configuring Auxiliary Devices

    9 CONFIGURING AUXILIARY DEVICES NOTE: Your Liebert® DSE™ Packaged Solution does not offer humidification or dehumidification functions. Please disregard those settings/fields when mentioned in this guide or displayed on the iCOM controller. With iCOM, you can manage and control many devices that work with your thermal-management unit(s). 9.1 Power Monitoring Up to six power meters may be connected to each cooling unit.

  • Page 92: Fluid Temperature Monitoring

    • May be a positive or negative value. 9.3 Configuring Analog Input Devices Touch , then > Auxiliary Device Setup > Analog Input. The ANALOG INPUTS and ANALOG INPUT PROPERTIES panels open. Vertiv™ | Liebert® iCOM™ Installer/User Guide...
  • Page 93 Analog Input. The ANALOG INPUT PROPERTIES for that device displays. 5. Select the configuration and touch Save.The analog input is configured. NOTE: The Airflow, Static Pressure and Fluid Flow analog-input settings configure factory options and require special instruction. Contact Vertiv™ Technical Support at 1-800-543-2778. 9 Configuring Auxiliary Devices...

  • Page 94: Wired Remote Sensors

    Maximum: Use the highest temperature reading of the two thermistors. • Average: Use the average of the readings from the two thermistors. Max Rack Temp Highest temperature reading from the unit remote sensors. REM Sensors set to Control Number of sensors set to control. Vertiv™ | Liebert® iCOM™ Installer/User Guide...

  • Page 95: Wired Remote Sensor-Sensor Property Options

    Unit Remote Sensors Mode When controlling at the unit level, selects the method of using the inlet-rack temperature readings from the control sensors to control fan speed. Options are: • Maximum: Use the highest temperature reading of the sensors set to Control. •...

  • Page 96: Supply Sensors

    (valve pulse, cooling filters and return compensation) can be used to enhance the supply air control. The valve pulse and cooling filter timer can be adjusted to prevent oscillation around the supply setpoint and still allow for rapid cooling-capacity adjustments to compensate for heat load changes. Contact Vertiv™ technical support for adjustments.

  • Page 97: Administering Firmware, Settings And Security

    The CONTROL BOARD UPGRADE panel shows the firmware version of the control board of the cooling unit. It also includes settings to use while performing the upgrade. NOTE: Only personnel who have completed Vertiv™ training should perform a control board update. The iCOM Service Tool (iST) is required to update control board firmware. Contact technical support at 1-800-543-2778 for information on control board updates.
  • Page 98 If changes are made to the settings after the control board is locked for firmware upgrade, use the following steps to unlock the board and execute the changes. In the Lock for Upgrade field on the FIRMWARE UPGRADE PARAMETERS panel, select Unlock, then select Yes. 2. Touch Save. The changes are executed. Vertiv™ | Liebert® iCOM™ Installer/User Guide...

  • Page 99: Backing Up, Importing, Exporting, And Restoring Display Settings

    10.2 Backing Up, Importing, Exporting, and Restoring Display Settings iCOM display settings may be saved to a local disk or USB drive (Setpoint parameters cannot be exported, only iCOM display settings). The saved files may be imported to restore iCOM if it is replaced or if a problem occurs and to transfer settings to another iCOM.

  • Page 100: Managing Access Permission And Passwords

    When a password is changed, make sure you record the new password and inform authorized users. If problems arise, passwords can be reset by Vertiv™ Technical Support, visit https://www.vertiv.com/en-us/support/. Two four-digit passwords provide two levels of permission to access iCOM menus and are set with factory-default values.

  • Page 101: Control Board Back Up And Restore Options

    When a password is changed, make sure you record the new password and inform authorized users. If problems arise, passwords can be reset by Vertiv™ Technical Support, visit https://www.vertiv.com/en-us/support/. Two four-digit passwords provide two levels of permission to access iCOM menus and are set with factory-default values.

  • Page 102: Configuring With The Start Up Wizard

    Calibrating the Touchscreen on page 8. Language Selects the display language. Import Imports previously saved display settings. Next Continues configuration using the set up wizard. Skip Closes the start up wizard and uses the factory default settings. Vertiv™ | Liebert® iCOM™ Installer/User Guide...

  • Page 103: Performing Diagnostics

    11 PERFORMING DIAGNOSTICS NOTE: Depending on the type of thermal management unit, included components, and control settings of your system, all of the options listed may not be available on your iCOM display. NOTE: Your Liebert® DSE™ Packaged Solution does not offer humidification or dehumidification functions. Please disregard those settings/fields when mentioned in this guide or displayed on the iCOM controller.

  • Page 104: Disabling Diagnostics Manual Mode

    Motors Enables/disables fan motor during manual/diagnostic mode. Status Airflow Status of Air Safety Switch: Open or Closed.. Status Filter Status of the air filter. Status Remote Shutdown Indicates whether remote shutdown is On or Off. Vertiv™ | Liebert® iCOM™ Installer/User Guide...

  • Page 105: Diagnosing Compressor Circuit Issues

    11.4 Diagnosing Compressor Circuit Issues Touch , then > Diagnostic/Service > Diagnostics > Compressor Circuit N (where N is the circuit number) in the Category list. The COMPRESSOR CIRCUIT panel displays. 2. Refer to Diagnostics—Compressor Circuit Options below, for descriptions of diagnostic options. NOTE: Depending on the type of thermal management unit, included components, and control settings of your system, all of the options listed may not be available on your iCOM display.

  • Page 106: Resetting High Pressure Alarm Code

    > Diagnostic/Service > Diagnostics > Electronic Expansion Valve N in the Category list. The ELECTRONIC EXPANSION VALVE panel displays. 2. Refer to Diagnostics—Electronic Expansion Valve Options on the facing page for descriptions of diagnostic options. Vertiv™ | Liebert® iCOM™ Installer/User Guide...

  • Page 107: Diagnostics-Electronic Expansion Valve Options

    NOTE: Depending on the type of thermal management unit, included components, and control settings of your system, all of the options listed may not be available on your iCOM display. 11.5.1 Diagnostics—Electronic Expansion Valve Options Current SH Setpoint Setpoint for superheat. EEV Batt Fail Counter C1 Number of battery test failures for the valve control board.

  • Page 108: Resetting Electronic Expansive Valve Battery Failure Counter

    Current outlet pressure reading , where N is the pump number. Pump N Speed Current pump speed, where N is the pump number. Pump N Test Results Results of board test, where N is the pump number. Vertiv™ | Liebert® iCOM™ Installer/User Guide...

  • Page 109: Diagnosing Digital Output Issues

    11.7 Diagnosing Digital Output Issues Touch , then > Diagnostic/Service > Diagnostics > Digital Outputs in the Category list. The DIGITAL OUTPUTS panel displays. 2. Refer to Diagnostics—Digital Output Options below for descriptions of diagnostic options. NOTE: Depending on the type of thermal management unit, included components, and control settings of your system, all of the options listed may not be available on your iCOM display.
  • Page 110 This page intentionally left blank Vertiv™ | Liebert® iCOM™ Installer/User Guide...

  • Page 111: Customizing Your Icom Display

    12 CUSTOMIZING YOUR iCOM DISPLAY NOTE: Your Liebert® DSE™ Packaged Solution does not offer humidification or dehumidification functions. Please disregard those settings/fields when mentioned in this guide or displayed on the iCOM controller. 12.1 Setting General Display Properties NOTE: You must be logged in to adjust the settings. See Powering On iCOM and Logging In/Unlocking Controls page 6.

  • Page 112: Customizing Main Display Views

    3. Touch an object to select it (highlighted green), touch and drag a handle to resize the object. See Figure 12.1 on the facing page. Vertiv™ | Liebert® iCOM™ Installer/User Guide...

  • Page 113: Adding And Adjusting Content

    Figure 12.1 Add/Remove Content Icons and Resizing Handles Item Description Content adjustment icon Resizing handles Remove content icon 12.2.3 Adding and Adjusting Content You can add a variety of content to the main display. Touch , then 2. Touch in the upper-right corner of the display and just below the control header, then touch menu of content options opens, described in Table 12.1 on the next page.

  • Page 114: Removing Content

    Once you know where they are, you’ll be able to find them in the categories on the Customize Labels panel. 2. Touch , then > Display Options > Custom Labels. The CUSTOM LABELS panel opens. The labels are divided into “categories” that represent the names of menus, sub-menus and screen panels. Vertiv™ | Liebert® iCOM™ Installer/User Guide...
  • Page 115 3. Locate the category that contains the label(s) to customize that you determined in step 1, and touch to expand 4. In the Custom Text column, touch the text box to edit, make changes and touch . See Figure 12.2 below, for an example of changing the column names for Property and Value (in the Analog Inputs panel) to Input and Configuration.

  • Page 116: Exporting, Importing, And Customizing Labels Using A Text Editor

    NOTE: You must use an editor that interprets Linux line endings, otherwise all of the lines will run together. For example, Microsoft WordPad will interpret the Linux line endings, but Microsoft Notepad will not. analog_input/row_customer_analog_inputs=Unit A Inputs analog_input_properties/header_property=Property analog_input_properties/header_value=Value Vertiv™ | Liebert® iCOM™ Installer/User Guide...
  • Page 117 6. To customize, type a new label name to the right of =, and save the text file. The following example will result in the same custom labels shown in Figure 12.3 on the previous page. analog_input/row_customer_analog_inputs=Unit A Inputs analog_input_properties/header_property=Input analog_input_properties/header_value=Configuration 7.

  • Page 118: Hardware Installation

    Each sensor requires a unique address in the CANbus loop connected to the cooling unit. We recommend that you set the DIP-switch sensor-number setting to correspond to the sensor’s location on the CANbus run. If settings are incorrect, the control will not operate properly. Vertiv™ | Liebert® iCOM™ Installer/User Guide...
  • Page 119 NOTE: Sensors are connected in a daisy chain via CANbus cabling to the cooling-unit control board. You can extend the sensor network (up to 10) by adding sensors to the end of the chain and adjusting the termination settings. Do not run individual wires from the sensors to the cooling unit.

  • Page 120: Terminating The Last Sensor On The Canbus Link

    Figure 12.7 on the facing page, shows an example CANbus arrangement. NOTE: To add sensors, unterminate final sensor, add sensors to the chain, and terminate the new final sensor. Vertiv™ | Liebert® iCOM™ Installer/User Guide...
  • Page 121 Figure 12.7 Example Sensor CANbus Arrangement Item Description CANbus communication loop iCOM control board 2T sensor 2T sensor 2T sensor 2T sensor Terminated sensor To terminate the last sensor: Locate the sensor that will be last on the network. NOTE: The last sensor on the network will be the sensor with only 1 CAN cable after all sensors are connected to the CANbus network.
  • Page 122 Figure 12.8 Termination Jumper on 2T Circuit Board Item Description Position 1 (P3 jumper) Position 2 (P3 jumper) Position 3 (P3 jumper) Unterminated Terminated Rear of sensor, cover removed P3 termination jumper Vertiv™ | Liebert® iCOM™ Installer/User Guide...

  • Page 123: Installing 2T Sensors In The Racks To Monitor

    13.1.3 Installing 2T Sensors in the Racks to Monitor Tools required: • Medium, flat head screw driver to open electric panel dead front • Cutting tool to trim cable ties The cooling units and rack sensors in Figure 12.9 below are symbol coded to show how interlacing sensors from different cooling units provides redundancy and effective operation by sharing sensor data from the cooling units in Teamwork mode.
  • Page 124 Description To cable entry in cooling unit First probe, 12 in. (305 mm) from top Second probe, in approximate center of rack and in front of the equipment 2T sensor with label visible Hot aisle Cold aisle Vertiv™ | Liebert® iCOM™ Installer/User Guide...

  • Page 125: Connect The Canbus Cable And Ground

    NOTE: Both probes on the 2T sensor must be installed on the same rack. 2. Install the 2T sensor probes the front door of the rack: a. Using a cable tie, secure the sensor wire so that a probe is approximately 12 in. (305 mm) from the top and in the center of the front door.
  • Page 126 Avoid using excess cable between sensors. • Make sure that cables have the correct pin-out. Mismatched pins at the RJ2 connection will damage the CAN device. Figure 12.11 CANbus and Ground Connection on 2T Sensor Vertiv™ | Liebert® iCOM™ Installer/User Guide...

  • Page 127: Installing A Fluid Temperature Sensor

    2. Terminate the ground wire to a field-installed ground ring in the low-voltage electrical panel, as shown in Figure 12.12 below. 3. Connect the CANbus cable to the cooling unit. On most cooling units, the connection points for the CANbus link are P66 and P67.
  • Page 128 • If inlet and outlet temperature readings in iCOM are reversed based on the field measurements, use Fluid Sensor 1/2 Placement to swap the readings. 5. Touch Save. The fluid temperature sensor settings are saved. Vertiv™ | Liebert® iCOM™ Installer/User Guide...

  • Page 129: Installing Supply Control Sensors

    Place the sensor in an area that is influenced only by the unit to which it is connected to provide an accurate reading: 5 ft. to 15 ft. (1.5 m to 4.5 m) from the cooling unit, Figure 12.15 below. NOTE: A 50 ft. (15 m) extension cable is available from Vertiv™ if the sensor must be more than 15 ft. (4.5 m) from the iCOM unit.

  • Page 130: Installing Aggregated Supply Air Temperature Sensors

    If the hole is not present, or the settings are difficult to make through the hole, remove the cover by removing the Phillips head screws (typically three). NOTE: Use the non-conductive DIP switch tool (included) or a similar tool to set switches. Do not insert any metal object into the sensor case. Vertiv™ | Liebert® iCOM™ Installer/User Guide...
  • Page 131 Figure 12.16 DIP Switch Opening/DIP Switches Inside of 2T Sensor Item Description Hole in sensor housing Cover removed 3. Referring to Table 12.4 below, and using the non-conductive tool, set the DIP switches for each sensor to its number in the chain (from sticker applied in step 1). Figure 12.17 on the next page, shows a representation of the DIP switches.
  • Page 132 3. Remove the black jumper from pins 1 and 2, and install it on pins 2 and 3 as shown in Figure 12.18 on the facing page. 4. Replace the sensor cover. The 2T sensor is terminated in the CANbus link. 5. If installing in an existing CANbus link, remember to unterminate the sensor that was previously last. Vertiv™ | Liebert® iCOM™ Installer/User Guide...

  • Page 133: Installing Analog Input Devices

    External sensors and analog devices may be connected to iCOM using an electrical connection on the iCOM control board to a required, factory supplied plug, harness and terminal strip. (Contact Vertiv™ technical support for parts.) When equipped, devices as follows can be connected to terminals 41, 42, 43 and 44, 45 and 46, or 47 and 48. Table 12.5 below, lists available analog inputs depending on the type of cooling unit.

  • Page 134: Installing The Unit To Unit Network

    Do not deform cables when hanging or securing in bundles. • Do not exceed 25 lb (11 kg) of tension when pulling cables to avoid stretching. • Do not damage cables when securing them. Use only approve hangers, such as telephone wire/RG-6 coaxial- wire hangers. Vertiv™ | Liebert® iCOM™ Installer/User Guide...

  • Page 135: U2U Wiring Connection

    Preparing for U2U Group Set Up on page 57, and Configuring U2U Network Settings on page 59. – or – Contact Vertiv™ Technical Support at 1-800-543-2778 or https://www.vertiv.com/en-us/support/. U2U Network Requirements The network must be private: • Isolated from other network traffic. •...

  • Page 136: Wiring Cooling Units Without Wall Mount Displays

    Connect a crossover CAT5 cable to the ETH-2 connector on the rear of each display as shown in Figure 12.19 below. Figure 12.19 Connection between Only Two Cooling Units—No Network Switch Needed Item Description Touchscreen (rear view) Ethernet cable (field-supplied) Ethernet cable (factory-supplied) iCOM I/O board Vertiv™ | Liebert® iCOM™ Installer/User Guide...
  • Page 137 To connect two or more cooling units into one group (maximum 32 units per group, up to 99 groups), a network switch is required: • On each unit, connect one plug on the CAT5 cable to ETH-2 on the rear of the display, and the other to the network switch, see Figure 12.20 below.

  • Page 138: Wiring Cooling Units With Wall Mount Displays

    To connect wiring: On each wall mount display (32 max.), connect one plug of a straight-through Ethernet cable to port P64 on the rear of the display. 2. Connect the other end to the U2U network switch. Vertiv™ | Liebert® iCOM™ Installer/User Guide...

  • Page 139: Appendices

    APPENDICES Appendix A: Technical Support and Contacts A.1 Technical Support/Service in the United States Vertiv Group Corporation 24x7 dispatch of technicians for all products. 1-800-543-2378 Liebert Thermal Management Products 1-800-543-2778 Liebert Channel Products 1-800-222-5877 Liebert AC and DC Power Products 1-800-543-2378 A.2 Locations...
  • Page 140 This page intentionally left blank Vertiv™ | Liebert® iCOM™ Installer/User Guide...

  • Page 141: Appendix B: Setpoints And Alarm Settings By Line Id

    Appendix B: Setpoints and Alarm Settings by Line ID These tables list the parameters by the line identification assignments employed before the iCOM touchscreen. The tables include range/options of the parameter, the factory default setting, and a description of the parameter function. The line IDs are not listed in the User or Settings menus, only in the parameter directory.
  • Page 142 If the return compensation value is set to 80 °F and the - 40.0 °C °C Setpoint actual return temperature falls to 75 °F, then the controlling temperature setpoint will be increased and will reflect in the "Control Temp Act" parameter. Vertiv™ | Liebert® iCOM™ Installer/User Guide...
  • Page 143 Table B.2 Service Menu Setpoints by Line ID Line Parameter Default Range Description Name Setting Supply Sensor Selects which sensor will be controlling/influencing the cooling capacity. Cooling Capacity is Return Temperature Return either the Chilled Water Valve, Compressor, Free Cooling Valve, or Air Economizer. Unloading S102 Sensor Control Sensor...
  • Page 144 Temp/Hum sensor and can calculate the dew point based on iCOM' s internal S124 Sensor Return Control Sensor Sensor lookup table. If a sensor other than the return sensor is selected, the Liebert iCOM will Sensor Vertiv™ | Liebert® iCOM™ Installer/User Guide...
  • Page 145 Table B.2 Service Menu Setpoints by Line ID (continued) Line Parameter Default Range Description Name Setting calculate the corresponding RH% based on that sensors actual temperature. 41 - 65 ◦F 48 °F Dew Point Selects a humidity level that the cooling unit will maintain by removing or adding moisture to Setpoint 5.0 - 18.3 ◦C 8.9 °C...
  • Page 146 Prevents frost from building up on the free cooling pipes when the outdoor ambient 32 °F Lockout FC at S141 -15.0 - temperature is extremely low by turning OFF the free-cooling circuit when the water Fluid Below 0.0 °C temperature is too low. +10.0°C Vertiv™ | Liebert® iCOM™ Installer/User Guide...
  • Page 147 Table B.2 Service Menu Setpoints by Line ID (continued) Line Parameter Default Range Description Name Setting Supply Sensor Remote Fan Control Return Controls the fan speed for modulation. If MANUAL is selected, then the fan speed can be S146 Sensor Return Sensor Sensor controlled from the local display or through a building management system.
  • Page 148 Coupled BMS speed. The control will use the slower value. COUPLED will set the fan speed to follow the Backup Set cooling capacity. BACKUP SET will use the BMS Backup Setpoint to drive fan speed. Vertiv™ | Liebert® iCOM™ Installer/User Guide...
  • Page 149 Table B.2 Service Menu Setpoints by Line ID (continued) Line Parameter Default Range Description Name Setting Allow BMS to S164 change No Yes Enables or disables BMS fan speed control. When this parameter is disabled, the BMS will not Fanspeed have write capability to this point.
  • Page 150 1.0 - 200.0 S186 Cycle Time 1.0 sec Set at the factory and should be changed only by an authorized Vertiv/Liebert technician. S187 SCR Factor 1.0 - 10.0 Set at the factory and should be changed only by an authorized Vertiv/Liebert technician.
  • Page 151 Table B.2 Service Menu Setpoints by Line ID (continued) Line Parameter Default Range Description Name Setting SP Pause time at deadband 2 - 180 sec 60 sec% maximum SP Pulse Time S194 2 - 15 sec 3 sec Sets the pulse time that the speed filter will be performed to the fan analog output. inside Deadband 0.010 - 1.003 0.020...
  • Page 152 Signal U2U Aggregated S1C7 0 - 100 % Signal Calibration XDU.006 Leaving Air +/-18°F 0°F Calibrate Supply Air Leaving Temperature sensor reading Temperature Calibration XDU.008 +/-18°F 0°F Calibrate Entering Fluid Temperature sensor reading Entering Fluid Vertiv™ | Liebert® iCOM™ Installer/User Guide...
  • Page 153 Table B.2 Service Menu Setpoints by Line ID (continued) Line Parameter Default Range Description Name Setting Temperature Calibration XDU.007 Leaving Fluid +/-18°F 0°F Calibrate Leaving Fluid Temperature sensor reading Temperature Fluid Flow XDU.009 Rateat Full 10 - 1000 l/m 115 l/m Fluid Flow Rate atFull Scale (20mA) Scale (20mA) Fluid Flow Rate...
  • Page 154 Sets the temperature at which the High Supply Temperature Alarm is activated. Temperature 1.0 - 99.0 °C 34 - 210°F Low Supply U215 50 °F Sets the temperature at which the Low Supply Temperature Alarm is activated. Temperature 1.0 - 99.0 °C Vertiv™ | Liebert® iCOM™ Installer/User Guide...
  • Page 155 Table B.3 User Menu Alarm Settings by Line ID (continued) Line Parameter Default Range Description Name Setting Disabled Remote 1 = Com Enables or disables the remote sensor alarms. When enabled, the remote temperature values will be U219 Sensor Disabled compared to a high and low setting.
  • Page 156 55 °F Temperature Alarm 1.0 - 99.0 °C Sets the temperature threshold when Sensor A High/Low S206 Temperature alarm will occur 34 - 210 °F Sensor A High 90 °F Temperature Alarm 1.0 - 99.0 °C Vertiv™ | Liebert® iCOM™ Installer/User Guide...
  • Page 157 Table B.4 Service Menu Alarm Settings by Line ID (continued) Line Parameter Default Range Description Name Setting Sensor A Low 1.0 - 99.0% 30.0% Humidity Alarm Sets the temperature threshold when Sensor A High/Low S207 Humidity alarm will occur Sensor A High 1.0 - 99.0% 70.0% Humidity Alarm...
  • Page 158 1 = Shutdown Selects function to occur if the temperature control sensor fails. S22A Full = Full Operation on Sensor 0 = Full CFC Hold = hold last CFC Failure Cooling Mode 0 (Full) 1 = Hold Vertiv™ | Liebert® iCOM™ Installer/User Guide...
  • Page 159 Table B.4 Service Menu Alarm Settings by Line ID (continued) Line Parameter Default Range Description Name Setting 0 = Smoke 1 = Water Alarm 2 = C PMP Alarm 3 = Flow Alarm 4 = Stdby G Pump 5 = Stdby Unit 6 = C-Input 1 7 = C-Input 2 1 (Water...
  • Page 160 Event: LOW ROOM MESSAGE WARNING WARNING ALARM Event Delay Time 10 - 9999 sec 30 sec (sec) S243 Event Enabled Disabled Enabled Disabled High Temperature Sensor A Event: HIGH TEMP MESSAGE WARNING WARNING SENSOR A ALARM Vertiv™ | Liebert® iCOM™ Installer/User Guide...
  • Page 161 Table B.4 Service Menu Alarm Settings by Line ID (continued) Line Parameter Default Range Description Name Setting Event Delay Time 10 - 9999 sec 30 sec (sec) S244 Event Enabled Disabled Enabled Disabled Low Temperature Sensor A Event: LOW TEMP MESSAGE WARNING WARNING SENSOR A...
  • Page 162 Event Delay Time 10 - 9999 sec 10 sec (sec) S259 Electric Heat High Temp AR = Auto Reset, MR = Manual Reset Event Enabled Disabled Enabled Enabled Event: EL HEAT MESSAGE WARNING ALARM HIGH TEMP ALARM Vertiv™ | Liebert® iCOM™ Installer/User Guide...
  • Page 163 Table B.4 Service Menu Alarm Settings by Line ID (continued) Line Parameter Default Range Description Name Setting Event Delay Time 10 - 9999 sec 10 sec (sec) S262 Event Enabled Disabled Enabled Enabled Working HRS Exceeded Event: UNIT HRS MESSAGE WARNING WARNING EXCEEDED ALARM...
  • Page 164 Event: CUSTOMER MESSAGE WARNING ALARM INPUT 3 ALARM Event Delay Time 10 - 9999 sec 10 sec (sec) S278 Event Enabled Disabled Enabled Enabled Customer Input 4 Event: CUSTOMER MESSAGE WARNING ALARM INPUT 4 ALARM Vertiv™ | Liebert® iCOM™ Installer/User Guide...
  • Page 165 Table B.4 Service Menu Alarm Settings by Line ID (continued) Line Parameter Default Range Description Name Setting Event Delay Time 10 - 9999 sec 10 sec (sec) S279 Event Enabled Disabled Enabled Enabled Call Service Event: CALL MESSAGE WARNING ALARM SERVICE ALARM Event Delay Time...
  • Page 166 Disabled Enabled Enabled Compressor 1 Short Cycle Event: COMP 1 MESSAGE WARNING WARNING SHORT CYCLE ALARM Event Delay Time 10 - 9999 sec 10 sec (sec) S289 Compressor 2 Short Cycle Event Enabled Disabled Enabled Enabled Vertiv™ | Liebert® iCOM™ Installer/User Guide...
  • Page 167 Table B.4 Service Menu Alarm Settings by Line ID (continued) Line Parameter Default Range Description Name Setting Event: COMP 2 MESSAGE WARNING WARNING SHORT CYCLE ALARM Event Delay Time 10 - 9999 sec 10 sec (sec) S290 Event Enabled Disabled Enabled Enabled Emergency Power Event: EMERGENCY...
  • Page 168 Event Delay Time 10 - 9999 sec 30 sec (sec) S2A7 Event Enabled Disabled Enabled Enabled Low Remote Sensor MESSAGE WARNING ‒ WARNING ALARM Event Delay Time S2A8 10 - 9999 sec 10 sec Power A Failure Vertiv™ | Liebert® iCOM™ Installer/User Guide...
  • Page 169 Table B.4 Service Menu Alarm Settings by Line ID (continued) Line Parameter Default Range Description Name Setting (sec) Event Enabled Disabled Enabled Enabled Event: POWER ' A ' MESSAGE WARNING ALARM FAILURE ALARM Event Delay Time 10 - 9999 sec 10 sec (sec) S2A9...
  • Page 170 Event: STAT PRES 4 MESSAGE WARNING ALARM SENS FAIL ALARM Event Delay Time 10 - 9999 sec 10 sec (sec) S2D1 Event Enabled Disabled Enabled Enabled Compressor 1A Overload Event: COMP 1A MESSAGE WARNING ALARM OVERLOAD ALARM Vertiv™ | Liebert® iCOM™ Installer/User Guide...
  • Page 171 Table B.4 Service Menu Alarm Settings by Line ID (continued) Line Parameter Default Range Description Name Setting Event Delay Time 10 - 9999 sec 10 sec (sec) S2D2 Event Enabled Disabled Enabled Enabled Compressor 1B Overload Event: COMP 1B MESSAGE WARNING ALARM OVERLOAD ALARM...
  • Page 172 C2 Freeze Protection Event: C2 FREEZE MESSAGE WARNING ALARM PROTECTION ALARM Event Delay Time 10 - 9999 sec 10 sec (sec) S2E9 Event Enabled Disabled Enabled Enabled Damper Failure Event: DAMPER MESSAGE WARNING ALARM FAILURE ALARM Vertiv™ | Liebert® iCOM™ Installer/User Guide...
  • Page 173 Table B.4 Service Menu Alarm Settings by Line ID (continued) Line Parameter Default Range Description Name Setting ‒ ‒ ‒ Event Enabled Disabled Enabled Enabled SF2F BMS Disconnected Event: BMS MESSAGE WARNING WARNING DISCONNECTED ALARM Phase Loss MB01 0 = No 1 (Yes) shuts unit down 1 = Yes...
  • Page 174 XDU Pump Inverter Fail 2 Event: PUMP MESSAGEWARNINGALARM ALARM INVERTER FAIL 2 Event Delay Time 1 - 9999 sec 10 sec (sec) Event Enabled DisabledEnabled Enabled XDU Pump Flow Fail 1 Event: PUMP FLOW MESSAGEWARNINGALARM ALARM FAIL 1 Vertiv™ | Liebert® iCOM™ Installer/User Guide...
  • Page 175 Table B.4 Service Menu Alarm Settings by Line ID (continued) Line Parameter Default Range Description Name Setting Event Delay Time 1 - 9999 sec 10 sec (sec) Event Enabled DisabledEnabled Enabled XDU Pump Flow Fail 2 Event: PUMP FLOW MESSAGEWARNINGALARM ALARM FAIL 2 Event Delay Time 1 - 9999 sec...
  • Page 176 QS Delay disable. Cascaded Units Once a standby unit has been cascaded ON; the amount of time that must surpass before the normal S518 0 - 30 min 5 min Control Delay unit control is used. Vertiv™ | Liebert® iCOM™ Installer/User Guide...
  • Page 177 Table B.5 Service Menu Cascade Parameters by Line ID (continued) Line Parameter Default Range Description Name Setting Cascaded Units 0 - 360 This timer starts to count down once a cascaded ON system has received an OFF request from the S519 0 min OFF Delay...
  • Page 178 This page intentionally left blank Vertiv™ | Liebert® iCOM™ Installer/User Guide...
  • Page 179 Vertiv™ | Liebert® iCOM™ Installer/User Guide...
  • Page 180 Vertiv.com | Vertiv Headquarters, 1050 Dearborn Drive, Columbus, OH, 43085, USA © 2019 Vertiv Group Corp. All rights reserved. Vertiv and the Vertiv logo are trademarks or registered trademarks of Vertiv Group Corp. All other names and logos referred to are trade names, trademarks or registered trademarks of their respective owners.
