Table B.4 Service Menu Alarm Settings by Line ID (continued)
Line Parameter
ID Name
Event Delay Time
(sec)
S253 Event Enabled
Event: CIRCUIT 1
LOW PRESS
Event Delay Time
(sec)
S254 Event Enabled
Event: CIRCUIT 2
LOW PRESS
Event Delay Time
(sec)
S255 Event Enabled
Event: CIRCUIT 1
PUMPD. FAIL
Event Delay Time
(sec)
S256 Event Enabled
Event: CIRCUIT 2
PUMPD. FAIL
Event Delay Time
(sec)
S257 Event Enabled
Event: DIG SCROLL1
HIGH TEMP
Event Delay Time
(sec)
S258 Event Enabled
Event: DIG SCROLL2
HIGH TEMP
Event Reset Type
Event Delay Time
(sec)
S259
Event Enabled
Event: EL HEAT
HIGH TEMP
154
Default
Range
Setting
‒ ‒
Disabled Enabled Enabled
MESSAGE WARNING
ALARM
ALARM
‒ ‒
Disabled Enabled Enabled
MESSAGE WARNING
ALARM
ALARM
‒ ‒
Disabled Enabled Enabled
MESSAGE WARNING
ALARM
ALARM
‒ ‒
Disabled Enabled Enabled
MESSAGE WARNING
ALARM
ALARM
‒ ‒
Disabled Enabled Enabled
MESSAGE WARNING
ALARM
ALARM
‒ ‒
Disabled Enabled Enabled
MESSAGE WARNING
ALARM
ALARM
0 = AR
0 (AR)
1 = MR
10 - 9999 sec 10 sec
Disabled Enabled Enabled
MESSAGE WARNING
ALARM
ALARM
Description
Circuit 1 Low Pressure
Circuit 2 Low Pressure
Circuit 1 Pump down Failure
Circuit 2 Pump down Failure
Digital Scroll 1 High Temperature
Digital Scroll 2 High Temperature
Electric Heat High Temp AR = Auto Reset, MR = Manual Reset
