4 MANAGING EVENTS: ALARMS, WARNINGS AND MESSAGES
NOTE: Your Liebert® DSE™ Packaged Solution does not offer humidification or dehumidification functions. Please
disregard those settings/fields when mentioned in this guide or displayed on the iCOM controller.
Events are notifications of operating status for the cooling unit, its components, and auxiliary devices. All events are
recorded in the Event Log, and alarm and warning events are also displayed on the Alarms panel (See
Log on page 16, and
In some cases, depending on configuration, an alarm event may power off the cooling unit, but not always. However, if a
standby unit is configured, all alarm events stop the faulty unit and start the standby unit. Message and warning events do
not.

4.1 Event Properties

The ALARMS & EVENTS panel lists all events available on the system. You can view and modify events and the criteria that
trigger visual/audible alarms including:
• Critical thresholds
• Time delays
• Enable/disable
• Event type
• Adding custom events
NOTE: Not all event properties may be adjusted, depending on the criticality of the event, which is factory set.

4.1.1 To Open the Panel

Touch , then
NOTE: Depending on the type of thermal-managment unit, included components, and control settings of your system,
the options on your iCOM display may differ.
4.1.2 Alarms & Events Panel Fields
Property
Lists groups of events, expanding displays the events in each group. See
on the next page.
Type
Event type. See
4 Managing Events: Alarms, Warnings and Messages
Viewing Unit Alarms on page 14.)
> Alarm/Event Setup.
Selecting Event Type and Setting Alarm/Warning Notification
Viewing the Event
Enabling Events and Editing Event Settings
on page 45.
