1.3.2 Powering On the Thermal Management Unit

NOTE: Depending on the operating state, there are start/stop priority switches that may prevent the cooling unit from
operating even though power to the unit is switched on and you have turned it on via iCOM.
The cooling unit operates only when all switches are closed. For example, even though you have turned on the unit
through iCOM, if the BMS remote monitoring system is sending a command to turn off the unit, the cooling unit
remains off.
NOTE: You must be logged in to access the menu options. See
on the previous page.
To power-on the unit:
1. Touch
2. Touch Turn Unit On. The cooling unit starts and the operating status is displayed as shown in Figure 1.4 below.
Figure 1.4 Unit Status on iCOM Display
Table 1.4 Cooling Unit Statuses Displayed
Unit Status
Description
Text
ALARM OFF An alarm forced the unit to turn off. See
MANUAL Controlled by a service technician. See
DISPLAY OFF
Unit is turned Off at the iCOM display. See
ALARM
In stand-by because of an active alarm on the unit. See
STANDBY
1 Getting Started with iCOM™
, then >Turn Unit On. The TURN UNIT ON dialog opens.
Item Description
1 Current status of the unit. See Table 1.4 below.
2 Teamwork icon. See Viewing Teamwork, Standby, and Cascade Status
Viewing Unit Alarms
Enabling Manual Mode for Diagnostics
Powering On the Thermal Management Unit
Powering On iCOM and Logging In/Unlocking Controls
on page 18.
on page 14.
on page 95.
.
above
Viewing Unit Alarms on page 14.
