B.2 Line IDs for Alarm Setting Parameters
Table B.3 User Menu Alarm Settings by Line ID
Line Parameter
ID Name
Return
Disabled
U202 Sensor
Alarms
High Return
U203
Temperature
Low Return
U204
Temperature
High Return 1.0 -
U205
Humidity 99.0 %
Low Return 1.0 -
U206
Humidity 99.0 %
Sensor A Disabled
U207
Alarms
34 -
High
210°F
U208 Temperature
1.0 -
Sensor A
99.0 °C
34 -
Low
210°F
U209 Temperature
1.0 -
Sensor A
99.0 °C
High
1.0 -
U210 Humidity
99.0 %
Sensor A
Low
1.0 -
U211 Humidity
99.0 %
Sensor
Supply
Disabled
U213 Sensor
Alarms
34 -
210°F
High Supply
U214
Temperature
1.0 -
99.0 °C
34 -
210°F
Low Supply
U215
Temperature
1.0 -
99.0 °C
146
Default
Range Description
Setting
Enables or disables the return sensor alarms. When enabled, the return temperature and humidity values
Enabled
Enabled will be compared to a high & low setting.
34 -
210°F
Allows a user to adjust the point at which the acual return temperature activates a High Temperature
100 °F
Alarm.
1.0 -
99.0 °C
34 -
210°F
Allows a user to adjust the point at which the actual return temperature activates the Low Temperature
65 °F
Alarm.
1.0 -
99.0 °C
65.0% Allows a user to adjust the point at which the actual return humidity activates the High Humidity Alarm.
35.0% Allows a user to adjust the point at which the actual return humidity activates the Low Humidity Alarm.
Enables or disables the alarms for reference Sensor A. When enabled, the Sensor A temperature and
Disabled
Enabled humidity values will be compared to a high and low setting.
Allows a user to adjust the point at which the actual Sensor A temperature activates a High Temperature
90 °F
Alarm.
Allows a user to adjust the point at which the actual Sensor A temperature activates a Low Temperature
55 °F
Alarm.
70.0% Allows a user to adjust the point at which the actual Sensor A humidity activates a High Humidity Alarm.
30.0% Allows a user to adjust the point at which the actual Sensor A humidity activates a Low Humidity Alarm.
Enables or disables the supply sensor alarms. When enabled, the supply temperature value will be
Disabled
Enabled compared to a high and low setting.
75 °F Sets the temperature at which the High Supply Temperature Alarm is activated.
50 °F Sets the temperature at which the Low Supply Temperature Alarm is activated.
