Table B.4 Service Menu Alarm Settings by Line ID (continued)
Line Parameter
ID Name
Event Delay Time
(sec)
S2D2 Event Enabled
Event: COMP 1B
OVERLOAD
Event Delay Time
(sec)
S2D3 Event Enabled
Event: COMP 2A
OVERLOAD
Event Delay Time
(sec)
S2D4 Event Enabled
Event: COMP 2B
OVERLOAD
Event Delay Time
(sec)
S2D5 Event Enabled
Event: COMP 1A
HIGH TEMP
Event Delay Time
(sec)
Event Enabled
S2D6
Event: COMP 1B
HIGH TEMP
Event Delay Time
(sec)
S2D7 Event Enabled
Event: COMP 2A
HIGH TEMP
Event Delay Time
(sec)
S2D8 Event Enabled
Event: COMP 2B
HIGH TEMP
Event Delay Time
(sec)
S2D9
Event Enabled
Default
Range
Setting
10 - 9999 sec 10 sec
Disabled Enabled Enabled
MESSAGE WARNING
ALARM
ALARM
10 - 9999 sec 10 sec
Disabled Enabled Enabled
MESSAGE WARNING
ALARM
ALARM
10 - 9999 sec 10 sec
Disabled Enabled Enabled
MESSAGE WARNING
ALARM
ALARM
10 - 9999 sec 10 sec
Disabled Enabled Enabled
MESSAGE WARNING
ALARM
ALARM
10 - 9999 sec 10 sec
Disabled Enabled Enabled
MESSAGE WARNING
ALARM
ALARM
10 - 9999 sec 10 sec
Disabled Enabled Enabled
MESSAGE WARNING
ALARM
ALARM
10 - 9999 sec 10 sec
Disabled Enabled Enabled
MESSAGE WARNING
ALARM
ALARM
10 - 9999 sec 10 sec
Disabled Enabled Enabled
Description
Compressor 1B Overload
Compressor 2A Overload
Compressor 2B Overload
Compressor 1A High Temperature
Compressor 1B High Temperature
Compressor 2A High Temperature
Compressor 2B High Temperature
Compressor 1A Short Cycle
