Vertiv Liebert iCOM DP400/500 Installer/User Manual page 155

Table B.3 User Menu Alarm Settings by Line ID (continued)
Line Parameter Default
Range
ID Name Setting
0 =
Disabled
Remote
1 = Com
U219 Sensor Disabled
Set
Alarms
2 = Sep
Set
34 -
210°F
High Remote
90 °F
Temperature
1.0 -
99.0 °C
U220
34 -
210°F
Low Remote
55 °F
Temperature
1.0 -
99.0 °C
34 -
210°F
High Remote
90 °F
01-10
1.0 -
99.0 °C
U224-
U233
34 -
210°F
Low Remote
55 °F
01-10
1.0 -
99.0 °C
Static
Disabled
U235 Pressure Disabled
Enabled
Messages
High Static 0.010 -
1.284
Pressure 1.405
inWC
(inWC) inWC
U236
High Static
2 - 350
Pressure 320 Pa
Pa
(Pa)
Low Static 0.000 -
0.000
Pressure 1.395
inWC
(inWC) nWC
U237
Low Static
0 - 348
Pressure 0 Pa
Pa
(Pa)
SP Messages
No
U238 During Unit No
Yes
Off
SP Messages
No
U239 on Fan No
Yes
Adjust
Description
Enables or disables the remote sensor alarms. When enabled, the remote temperature values will be
compared to a high and low setting.
Enables or disables remote sensor temperature alarms. When enabled, the high and low remote
temperature alarm will allow a user to adjust the point at which the actual remote temperature activates a
High/Low temperature alarm. This parameter is used when common alarm points will be shared by all
sensors. Otherwise, the remote sensors can be set individually.
Sets the high and low remote temperature sensor alarm points individually for each sensor when the
parameter separate thresholds is set to disabled
Enables or disables static pressure messages.
Sets the pressure at which the High Static Pressure Alarm is activated (inWC, Pa)
Sets the pressure at which the Low Static Pressure Alarm is activated (inWC, Pa)
Enables or disables Static Pressure messages when the unit is OFF
Enables or disables the static pressure messages when the fan as been adjusted due to special events.
These events include an adjustment for heating, humidification, dehumidification, motor overload / EC fan
fault or loss of airflow.
