Table 4.4 Events Specific to Liebert EconoPhase (continued)
Event Description
Ethernet communications failure. Pump not shut down.
PB1
COMMUNICATE
USB communications failure. Pump not shut down.
FAIL
Ethernet communications failure. Pump not shut down.
PB2
COMMUNICATE
USB communications failure. Pump not shut down.
FAIL
Temperature variance from condenser 1 output to pump 1 input exceeds allowed parameters. Pump shut down.
PB1 COND TO
PUMP TEMP
Temperature variance from condenser 2 output to pump 2 input exceeds allowed parameters. Pump shut down.
PB2 COND TO
PUMP TEMP
Liebert® EconoPhase operating in Mixed Mode has failed to control cooling 10 times in 6 hours.
MM Cycle Lock
Out
Liebert® EconoPhase in Pump Mode has failed to control cooling 5 times consecutively at full-pump-capacity temperature conditions.
PB Cycle Lock
Out

4.4 Enabling the Audible Alarm Notification

1. Touch
The UNIT DISPLAY panel opens.
2. Touch the Alarm Buzzer Pattern value, and select a pattern from the drop-down list.
• Selecting None disables the audible notification.
3. Touch Save to save the property settings.
• Touch Cancel to discard changes.

4.5 Remote Alarm Device and Customer Input Events

Remote alarm devices are various sensors and detectors outside the cooling unit that provide information about conditions
and situations that may affect operation. Remote alarm devices (RAD) include smoke detectors, filter condition, valve status.
Included in the RADs option are up to four customer input events depending on cooling unit configuration. In some cases,
two additional, optional customer input events are available. See
RAD and customer input notifications are set in the same way as other events. See
Setting Alarm/Warning Notification
52
• Event is reset when condition clears.
• Event is reset when condition clears.
• Event is reset when condition clears.
• Event is reset when condition clears.
• Event is reset when iCOM requests a new startup.
• Event is reset when iCOM requests a new startup.
• Mixed Mode operation is disabled until the event is manually reset.
• EconoPhase operation is disabled until the event is manually reset.
, then > Display Options > Display Properties.
on page 45.
Setting Up Customer Input Events
Selecting Event Type and
on the facing page.
