1. H24-4 mini slip rings are mounted on the inside of the roll drive shaft on aft end
inside center weldment. These are gold contacts and rings. No maintenance
required.
1-2P Joysticks/Throttle and UGC/USB HAAP Box Interface
There are two flight joysticks and two throttle's installed within the cockpit area. These
units interface to the HAAP controller's (two) installed between the seats inside center console.
The signals are transferred to the on-board CPU via a USB cable connector by way of dual USB
controller on mother board or PCI board mounted to the mother board.
1-2Q Bose 5.1 surround sound system
The sound system consists of a 5.1 surround speaker system. It is installed within
the cockpit area above the heads of patrons, in front and back of cockpit. A base
response speaker is mounted under the right patron seat. A remote volume and tone
control are located on backside of left lower cockpit. Audio is obtained from the onboard
computer mother board when games are played.

1-2U Remote Wireless Camera

A wireless type camera is mounted inside the cockpit top left corner by front
screen. Transmitter is mounted under right seat frame. Receiver is mounted top right
cabinetry just behind flat screen TV. Used to observe the patrons during the ride. Signal
can be used to record and copy to CD for sale to patrons.
1-3 Mechanical
1. A-frame - two each, right and left.
2. Center weldment.
3. Pitch arms two
Joystick located on center console. Inside
console are the two USB HAAP control
41
circuit boards.
