Strip line
Layer Trace width/space
3,4 5.5
3,4 4.5/4/4.5
3,4 4/4.5/4
3,4 4/7/4
Layer Glass Style & Cu Wt.
L1 0.5OZ plating to 1OZ
P.P 3313
L2 0.5OZ
CORE 0.102 FR-4
L3 0.5OZ
P.P 7628
CORE 0.71 FR-4
P.P 7628
L4 0.5OZ
CORE 0.102 FR-4
L5 0.5OZ
P.P 3313
L6 0.5OZ plating to 1OZ
Total thickness 62.8mil 1.595mm
RP-103-SMC User Manual
Carrier Board Design Guide
Single-End Differential
50 +/- 10 %
85 +/- 10 %
90 +/- 10 %
100 +/- 10 %
Thickness
1.4
3.6
0.65
4
0.65
7.1
28
7.1
0.65
4
0.65
3.6
1.4
