P106 HDMI_DDC_SDA
P107 HDMI_DDCCEC
P108 CSI1_PWEN_B/GPIO3_25
P109 CSI2_PWEN_B/GPIO3_20
P110 CSI1_RST_B/GPIO3_19
P111 CSI2_RST_B/GPIO3_21
P112 HDA_RST_B/GPIO1_09
P113 PWM3_OUT/GPIO5_03
P114 TACHIN/GPIO5_05
P115 CODEC_INT_B/GPIO4_29
P116 VDCDC_5V_EN/GPIO1_03
P117 TP_INT_B/GPIO4_10
P118 TP_RST_B/GPIO4_27
P119 TP_EN_B/GPIO4_21
P120 GND
P121 I2C4_SCL
P122 I2C4_SDA
P123 BOOT_SEL0/GPIO1_05
P124 BOOT_SEL1/GPIO1_06
P125 NC
P126 RESET_OUT_B
P127 RESET_IN_B
P128 ONOFF_B
P129 UART2_TXD
P130 UART2_RXD
P131 UART2_RTS
P132 UART2_CTS
P133 GND
P134 UART3_TXD
P135 UART3_RXD
P136 UART4_TXD
P137 UART4_RXD
RP-103-SMC User Manual
HDMI I/F
HDMI I/F
I/O: Camera Module Power
control, Active Low
I/O: Camera Module Power
control, Active Low
I/O: Camera Module Reset
control, Active Low
I/O: Camera Module Reset
control, Active Low
I/O: HAD I2S Reset, Active
Low
I/O: PWM Output
I/O: Tachometer input
detect
I/O: Codec I2C IRQ detect,
Active Low
I/O: 5V power control,
Active High
I/O: CapTouch panel IRQ
detect, Active Low
I/O: CapTouch panel Reset
conrol, Active Low
I/O: CapTouch panel
control, Active Low
Ground
I2C I/F
I2C I/F
I/O: Bootup mode detect,
Active Low
I/O: Bootup mode detect,
Active Low
-
System Reset output,
Active Low
System Reset Input, Active
Low
System Power ON/OFF
control, Active Low
UART2 I/F
UART2 I/F
UART2 I/F
UART2 I/F
Ground
UART3 I/F
UART3 I/F
UART4 I/F
UART4 I/F
Carrier Board Design Guide
-
-
-
-
-
-
Output
High
1.8V
Output
High
1.8V
Output
High
1.8V
Output
High
1.8V
Output
High
1.8V
Output
Low
1.8V
Input
-
1.8V
Output
High
1.8V
Output
Low
1.8V
Input
Low
1.8V
Output
Low
1.8V
Output
Low
1.8V
-
-
-
Output
-
1.8V
Bidirectional
-
1.8V
Input
Low
1.8V
Input
Low
1.8V
-
-
-
Output
Low
Input
Low
Input
Low
Output
-
1.8V
Input
-
1.8V
Input
-
1.8V
Output
-
1.8V
-
-
-
Output
-
1.8V
Input
-
1.8V
Output
-
1.8V
Input
-
1.8V
Can be used as GPIO for
other Carrier board
Can be used as GPIO for
other Carrier board
Can be used as GPIO for
other Carrier board
Can be used as GPIO for
other Carrier board
Can be used as GPIO for
other Carrier board
Can be used as GPIO for
other Carrier board
Can be used as GPIO for
other Carrier board
Can be used as GPIO for
other Carrier board
Can be used as GPIO for
other Carrier board
Can be used as GPIO for
other Carrier board
Can be used as GPIO for
other Carrier board
Can be used as GPIO for
other Carrier board
Can be used as GPIO for
other Carrier board
Can be used as GPIO for
other Carrier board
Can be used as GPIO for
other Carrier board
Can be used as GPIO for
other Carrier board
Can be used as GPIO for
other Carrier board
Can be used as GPIO for
other Carrier board
Can be used as GPIO for
other Carrier board
Can be used as GPIO for
other Carrier board
Can be used as GPIO for
other Carrier board
Can be used as GPIO for
other Carrier board
73
